Home Accents Holiday 1001 539 382 Manuale utente

Christmas Tree

Model: TG90M3ACDL17

Sku # 1001 539 382

Pre-Assembly

Assembling the tree stand

Assembly

Step 1.

Choose a location near a wall outlet.

Step 2.

Unfold the legs of the tree stand (D) and lay the stand on

the floor.

Step 3.

Slide the locking disk of the tree stand (D) down until it

snaps into place.

This tree assmebles with Quick Set

technology ---Set up and

light up your tree in less than 10 minutes!

Step 1.

Remove the protective caps from the tree bottom (C) and

insert the pole into the tree stand (D).

Step 2.

Remove the protective caps from the tree center (B) and

insert the pole into the tree bottom (C) .

Step 3.

Insert the tree top (A) into the tree center (B).

Step 4.

Shape the branches to your preference by working from the

bottom to the top. When adjusting branches, ensure that all

wires are free of branch hinges.

Step 5.

Inplug the adapter into the wall outlet. All your lights should

now be lit.

Step 6.

Shape the tree from the bottom to the top. Start with the

branches farthest from the pole – fan out in a star shape,

and continue until the entire tree is shaped.

Step 7.

When finished shaping the branches, slightly upsweep all

branch tips for a uniform look.

Assembling the tree

Adapter

To Be Plugged

Into Wall

Outlet

100S

50S

100S

50S

Package Contents

Tree top

Tree center, sticker 2

Tree bottom, sticker 1

Tree stand

Quantity

Part Description

Top view Side view

Control box Foot Pedal

on/off Switch

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

a. READ AND FOLLOW ALL

SAFETY INSTRUCTIONS.

When using electrical products, basic precautions should always

be followed, including the following:

NEED HELP?

DO NOT RETURN TO STORE. Call: 1-877-527-0313

Form 8am to 5pm EST, Monday through Friday.

b. Do not use seasonal products outdoors unless marked suitable for

indoor and outdoor use. When products are used in outdoor

applications,

connect the product to a Ground Fault Circuit Interrupting (GFCI)

outlet. If one is not provided, contact a qualified electrician for proper

installation.

c. This seasonal product is not intended for permanent installation or use.

d. Do not mount or place the product near gas or electric heaters,

fireplaces, candles, or other similar sources of heat.

e. Do not secure the wiring of the product with staples or nails, or place on

sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when retiring for the

night, or if left unattended.

h. This is an electric product and not a toy! To avoid risk of fire, burns,

personal injury and electric shock it should not be played with or

placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire, or light string.

k. Do not close doors or windows on the product or extensions cords as

this may damage the wire insulation.

l. Do not cover the product with cloth, paper, or any material that is not

a part of the product when in use.

m. The lamps of this product are not replaceable. Do not attempt to

change or modify the lamps.

n. Read and follow all instructions that are on the product or provide with

the product.

SAVE THESE INSTRUCTIONS

Align both arrows

in a straight line

before sliding

down to insert

Open the

cap cover

Do Not Tamper

Internal Parts

Tree top

Sticker 2

Sticker 1

Christmas Tree

Model: TG90M3ACDL17

Sku # 1001 539 382

NOTE: If some bulbs do not light or flicker, search for any loose

plugs and/or provided in order to maintain the performance and

life expectancy of your tree.

Step 1. Connect the light strings of the tree together and plug the

adapter into a wall outlet.

Step 2. If the tree comes with a foot pedal, step on the On/Off

button.

Operation

Turning on the tree

This tree package includes hinge pins, washers for any replacement

or repair that you need to perform on your tree. If extra parts are

needed, contact the Customer Service Team at 1-877-527-0313

between the hours of 8 am and 5 pm EST, Monday through Friday.

Repairing Loose Hinges

Step 1.

Place the branch into the slot of the bracket.

Step 2.

Insert a new hinge pin through the holes of the bracket

and secure with a washer.

Maintenance

Spare parts

1. Before using or reusing, inspect product carefully. Discard any

products that have cut, damaged or frayed wire insulation or

cords, cracks in the lampholders or enclosures, loose

connections, or exposed copper wire.

2. Before disassembling the tree, unplug the tree and remove all

ornaments and decorations.

3. Gently lift the tree top straight up to remove from the center

section and fold all branches towards the pole.

4. Repeat this step for the center and bottom tree sections.

5. When storing the product, carefully remove the product from

wherever it is placed, including tree, branches, or bushes, to

avoid anyundue strain or stress on the product conductors,

connections, and wires. Cover the

protective cap on the poles to avoid

damaging the internal parts.

6. When not in use, store neatly in a cool,

dry location protected from sunlight.

Use and Care Instructions

CAUTION:Use only power adapter that was provided

with this product. Using a different power adapter will damage

the lights and cause fire, electrical shock hazard.

Troubleshooting

Problem Solution

The tree does

not light

Ensure that all tree sections are plugged

into each other and that the tree is

plugged into the wall. If your tree came

with a foot pedal, step on the On/Off

button.

HOW TO USE THE DUAL COLOR LIGHT CONTROLLER:

Press the selector button on the “Light Controller”

to select among:

(1) SLOW FADING

(2) TWINKLE

(3) FAST FADING

(4) COMBINATION

(5) STEADY ON

User servicing instructions

Light

Controller

Selector

Button

To activate the DEMO mode:

1. With the tree plugged in, press and hold the FUNCTION button of

the in-line controller/receiver for 5 seconds.

2. The Clear Lights will blink 3 times. The tree is now in DEMO mode.

3. Within DEMO mode, the tree will display the COMBO pattern at all

time unless the function button is pressed to change the flashing

pattern. The tree will return to COMBO pattern whenever the

controller is idle for 30 seconds.

To deactivate the DEMO mode:

1. With the tree plugged in and in DEMO mode, press and hold the

FUNCTION button of the in-line controller/receiver for 5 seconds.

2. The multi-light will flash 5 time indicating that DEMO mode is off

(Clear lights will flash 5 times with single color LED trees).

3. The tree is now in normal mode. Flashing pattern can be set to

whichever desired and the tree will remember the last setting.

*IN-LINE CONTROLLER/RECEIVER

*Controller

Tree Comes with Demo Mode Not Activated
