Home Accents Holiday 21PG90231 Manuale utente

Pre-Assembly

Package Contents

Part Description Quantity

A Tree top 1

B Tree center, Sticker 2 1

C Tree center, Sticker 1 1

D Tree stand 1

Christmas Tree

Model: 21PG90231

Sku # 1006 215 608

Tree top

Section 2

Section 1

Control box

Adapter

To Be Plugged

Into Wall

Outlet

Foot Pedal

on/off Switch

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

a. READ AND FOLLOW ALL

SAFETY INSTRUCTIONS.

When using electrical products, basic precautions should always

be followed, including the following:

b. Do not use seasonal products outdoors unless marked suitable for

indoor and outdoor use. When products are used in outdoor

applications,

connect the product to a Ground Fault Circuit Interrupting (GFCI)

outlet. If one is not provided, contact a qualified electrician for proper

installation.

c. This seasonal product is not intended for permanent installation or use.

d. Do not mount or place the product near gas or electric heaters,

fireplaces, candles, or other similar sources of heat.

e. Do not secure the wiring of the product with staples or nails, or place on

sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when retiring for the

night, or if left unattended.

h. This is an electric product and not a toy! To avoid risk of fire, burns,

personal injury and electric shock it should not be played with or

placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire, or light string.

k. Do not close doors or windows on the product or extensions cords as

this may damage the wire insulation.

l. Do not cover the product with cloth, paper, or any material that is not

a part of the product when in use.

m. This product is equipped with push-in type lamps. Do not twist lamps.

n. Read and follow all instructions that are on the product or provide with

the product.

SAVE THESE INSTRUCTIONS

Align both arrows

in a straight line

before sliding

down to insert

Open the

cap cover

Do Not Tamper

Internal Parts

NEED HELP?

DO NOT RETURN TO STORE. Call: 1-877-527-0313

Form 8am to 5pm EST, Monday through Friday.

Assembly

80S

100S

70S

100S

50S

100S

Step 1. Pull apart the legs of the stand so that they are snapped

into an x-shape, place the tree stand on a level surface.

To close the stand, press the metal button and fold the legs together.

Assembling the tree

This tree assmbles with Quick Set® technology

---Set up and light up your tree in less than 10 minutes!

Step 1. Remove the protective caps from the tree bottom and

insert the pole into the tree stand.

Step 2. Continue by inserting the upper tree section(s) to the

lower section(s) until inserting the tree top.

Step 3. Shape the branches to your preference by working from

the bottom to the top. When adjusting branches, ensure

that all wires are free of branch hinges.

Step 4. Insert the adapter into the wall outlet. All your lights

should now be lit.

Step 5. Shape the tree from the bottom to the top. Start with the

branches farthest from the pole – fan out in a star shape,

and continue until the entire tree is shaped.

Step 6. When finished shaping the branches, slightly upsweep

all branch tips for a uniform look.

Assembling the tree stand

Click

Top view Side view

Step 1.

Grasp the power adapter or power cord plug,

and than unplug from the power outlet.

Do not pull the power cord.

LAMP REPLACEMENT

Step 2.

Lift up lamp lock tab, then pull the

lamp and plastic lamp base

straight out of the lamp-holder.

Step 3.

Replace with a new spare lamp

provided with this product.

(Reference figure only)

This tree package includes hinge pins, washers and bulbs for any

replacement or repair that you need to perform on your tree. If

extra parts are needed, contact the Customer Service Team at

1-877-527-0313 between the hours of 8 am and 5 pm EST,

Monday through Friday.

Repairing Loose Hinges

Step 1. Place the branch into the slot of the bracket

Step 2. Insert a new hinge pin through the holes of the

bracket and secure with a washer.

Maintenance

Spare parts

Turning on the tree

NOTE: If some bulbs do not light or flicker, search for any loose

plugs and/or broken, loose, or missing bulbs. Replace bulbs

promptly with the replacement bulbs provided in order to

maintain the performance and life expectancy of your tree.

Step 1. Connect the light strings of the tree together and plug

the adapter into a wall outlet.

Step 2. If the tree comes with a foot pedal, step on the On/Off

button.

Operation

1. Before using or reusing, inspect product carefully. Discard any

products that have cut, damaged or frayed wire insulation or

cords, cracks in the lampholders or enclosures, loose

connections, or exposed copper wire.

2. Before disassembling the tree, unplug the tree and remove all

ornaments and decorations.

3. Gently lift the tree top straight up to remove from the center

section and fold all branches towards the pole.

4. Repeat this step for the center and bottom tree sections.

5. When storing the product, carefully remove the product from

wherever it is placed, including tree, branches, or bushes, to

avoid anyundue strain or stress on the product conductors,

connections, and wires. Cover the

protective cap on the poles to avoid

damaging the internal parts.

6. When not in use, store neatly in a cool,

dry location protected from sunlight.

Use and Care Instructions

To activate the DEMO mode:

1. With the tree plugged in, press and hold the FUNCTION button of

the in-line controller/receiver for 5 seconds.

2. The Clear Lights will blink 3 times. The tree is now in DEMO mode.

3. Within DEMO mode, the tree will display the COMBO pattern at all

time unless the function button is pressed to change the flashing

pattern. The tree will return to COMBO pattern whenever the

controller is idle for 30 seconds.

To deactivate the DEMO mode:

1. With the tree plugged in and in DEMO mode, press and hold the

FUNCTION button of the in-line controller/receiver for 5 seconds.

2. The multi-light will flash 5 time indicating that DEMO mode is off.

3. The tree is now in normal mode. Flashing pattern can be set to

whichever desired and the tree will remember the last setting.

*IN-LINE CONTROLLER/RECEIVER

*Controller

Tree Comes with Demo Mode Not Activated

CAUTION:

Use only power adapter that was provided with this product.

Using a different power adapter will damage the lights and cause

fire, electrical shock hazard.

Christmas Tree

Model: 21PG90231

Sku # 1006 215 608

Press the selector button on the “Light Controller” to select among:

(1) WARM WHITE - MULTI: FADING

(2) WARM WHITE: FADING

(3) WARM WHITE - MULTI: ALTERNATING

(4) WARM WHITE: STEADY

(5) WARM WHITE - MULTI: SLOW FADING

(6) MULTI: STEADY

(7) MULTI: FADING

(8) COMBINATION

HOW TO USE THE DUAL COLOR LIGHT CONTROLLER:

User servicing instructions

Light

Controller

Selector

Button

Troubleshooting

Problem Solution

The tree does not

light

Ensure that all tree sections are plugged into

each other and that the tree is plugged into

the wall. If your tree came with a foot pedal,

step on the On/Off button.

Check for loose, broken, or missing bulbs and

replace

as needed with the replacement

bulbs provided

Christmas Tree

Model: 21PG90231

Sku # 1006 215 608

Not Full?

Spread Branches

Tree is in Demo Mode

Run Extension Cord

Tree Topper? Lights Cycle Through

Functions?

Branch Hanging Low?

Bend up

No Lights Working?

Check For Loose Connection

Ensure pole fully connected

Section Out?

Other Issue? Call 1-877-527-0313

To deactivate:

Press & hold until multicolor

lights blink 5 times

To activate:

Press & hold until warm white

lights blink 3 times

Function

button
