THANK YOU

to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home

improvement needs. Thank you for choosing Home Decorators Collection!

USE AND CARE GUIDE

RAINBROOK LARGE OUTDOOR WALL LANTERN

Questions, problems, missing parts? Before returning to the store,

call Home Decorators Collection Customer Service

8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday

1-800-986-3460

HOMEDEPOT.COM/HOMEDECORATORS

Item #1007199842

Model #13654

Table of Contents

Table of Contents ............................ 2

Safety Information............................ 2

Warranty ............................... . . . 2

Pre-Installation............................ . . 3

Planning Installation ............................... 3

Tools Required .................................... 3

Hardware Included................................. 3

Package Contents .................................4

Installation................................. 5

Operation.................................. 6

Care and Cleaning............................ 6

Troubleshooting ............................. 6

Safety Information

□

questions. CAUTION: Inspect the wire insulation for any cuts,

abrasions, or exposed copper that may have resulted during

shipping. If there is a defect in the wire, do not attempt

installation. Please call our Customer Service Team at

1-800-986-3460.

WARNING:

turning off the circuit breaker or by removing the fuse at the

fuse box.

Warranty

date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If

this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the

alterations, neglect, or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, set-up,

or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the

product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material

considered normal wear and tear. The manufacturer does not warrant and specially disclaims any warranty, whether express or implied,

shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor / expense costs involved in the

replacement or repair of said product.

Contact the Customer Service Team at 1-800-986-3460 or visit www.homedepot.com/homedecorators.

ﬁve (5) years from

3 HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Pre-Installation

PLANNING INSTALLATION

TOOLS REQUIRED

Ladder Safety

goggles

Electrical

tape

Phillips

screwdriver

Flat blade

screwdriver Pliers Wire

strippers

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.

AA BB

CC DD EE

Part Description Quantity

AA Mounting bracket 1

BB Mounting screw 2

CC Wire nut 3

DD Cap nut 2

EE Washer 2

□Read all instructions before installation.

□To avoid damaging this product, assemble it on a soft, non-abrasive surface, such as carpet or cardboard.

□Keep your receipt and these instructions for proof of purchase.

Pre-Installation (continued)

PACKAGE CONTENTS

Part Description Quantity

B 2Socket cover

A B

5 HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Installation

1 Attaching the mounting bracket to the

junction box

□Attach mounting unit (AA) to the junction box (not included)

with mounting screws (BB).

NOTE: The preinstalled support screws on the mounting

unit (AA) should protrude out away from the junction box

with approximately 1/8 in. of adjustability.

2 Making the electrical connections

□

mounting bracket (AA) by securing it with the preinstalled

ground screw.

□Connect the black to black (power), the white to white

(neutral) and copper wire to ground wire with the wire

NOTE:

attach the smooth wire to the black (positive) wire, attach

the ridged wire to the white (neutral) wire.

□

over the pre-installed screws on the mounting bracket (AA)

and securing it with the washers (EE) and cap nuts (DD).

NOTE: Maintain a tight waterproof seal between the

canopy and mounting surface.

4 Installing the light bulb

□Secure the socket covers (B) onto the light ﬁxture (A)

□Install two E12 candelabra 60-watt bulbs (not included).

Operation

□

Care and Cleaning

□Clean the lamp with a soft, dry cloth.

□Do not use any cleaners with chemicals, solvents, or harsh abrasives.

Troubleshooting

Problem Possible Cause Possible Cause

The bulb will not light. The bulb is burned out. Replace the light bulb.

The power is off. Ensure the power supply is On.

There is a faulty wire connection. Check the wiring.

The circuit breaker is off. Ensure the circuit breaker is in the ON position.

The fuse blows or circuit

breaker trips when the

light is turned on.

There are crossed wires or the

power wire is grounding out.

Check the wire connections.

1-800-986-3460.

Questions, problems, missing parts? Before returning to the store,

call Home Decorators Collection Customer Service

8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday

1-800-986-3460

HOMEDEPOT.COM/HOMEDECORATORS

Retain this manual for future use.
