Homelabs Nugget Manuale utente

Nugget

Ice Maker

Thank you for purchasing our appliance.

Please be sure to read the entirety of

this user manual carefully prior to using

this appliance. If you have any questions

regarding the use of this product,

please contact Customer Service

at homelabs.com/help

or help@homelabs.com.

SKU: HME010694N

Compact and

Portable

Table of Contents

Important Safety Instructions .................. 5

Parts Overview ............................................. 6

Operation ...................................................... 7

Cleaning and Maintenance....................... 11

Speciﬁcations.............................................. 11

Daily Cleaning ............................................12

Monthly Cleaning .......................................13

Troubleshooting......................................... 14

Warranty.......................................................15

Manufacturing Information ......................15

Warning.........................................................15

Before First Use

To prevent any internal damage, it is very important to

keep the unit upright throughout its journey. Please leave it standing

upright and outside the box for 24 HOURS before plugging it in.

In the event this product malfunctions, or you believe it is

defective, please contact Customer Service at homelabs.com/help

or [email protected] and hold onto the defective product

(pending further instruction). A defective product should

be clearly marked or stored where it cannot be used by mistake.

Failure to keep the product in its original quality from the time of

receipt may impede hOmeLabs’s ability to correct any legitimate

problem and may limit the extent to which hOmeLabs

may provide recourse.

Before First Use

We recommend running the cleaning

program (See > Page 8) prior to

making ice for the ﬁrst time.

4 5

Don’t forget to register your product at homelabs.com/reg

for updates, coupons, and other relevant information.

Although greatly appreciated, product registration

is not required to activate any warranty.

on bringing home your new appliance!

Congratulations

When using electrical appliances, basic safety precautions should be followed to reduce the

risk of ﬁre, electrical shock, and injury to persons or property. Read all instructions before

using this appliance.

• Do not use appliance for anything other than its intended use.

• Do not operate this or any other appliance with a damaged cord.

Leave a space of at least 6 inches around the appliance.

• If the supply cord is damaged, it must be replaced by the manufacturer

or a similarly qualiﬁed person in order to avoid potential safety hazards.

• This appliance has to be positioned so that the plug is accessible after installation

or assembly.

• Connect to properly grounded outlets only. No other appliance should be plugged

into the same outlet. Be sure that the plug is fully inserted into the receptacle.

• Do not run the Power Cord over carpeting or other heat insulators. Do not cover

the cord. Keep the cord away from high trafﬁc areas. Do not submerge in water.

• We do not recommend the use of an extension cord as it may overheat and become

a ﬁre hazard. If you have to use an extension cord, use No. 14 AWG minimum size

and rated no less than 1875 Watts.

• Unplug the appliance before any cleaning, repairing or servicing. Always grasp the

power plug to remove it from the wall outlet. Do not pull on the power cord itself.

• Exercise caution and provide supervision when this appliance is used in the

presence of children.

• Do not use the appliance outdoors. Place the appliance away from direct sunlight.

• Only use water to make ice.

• Do not clean the appliance with ﬂammable ﬂuids. The fumes can create

a ﬁre hazard or cause an explosion.

• Do not let this appliance tip over.

• If the appliance is brought inside from the cold, please let it warm to

room temperature before plugging it in.

• To avoid hazards due to instability, the appliance must be placed on a ﬂat surface. This

appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the appliance by a person

responsible for their safety. Children should be supervised to ensure that they

do not play with the appliance.

WARNING

• This appliance should be properly grounded for your safety. The Power Cord of this

appliance is equipped with a grounding plug which mates with standard grounding

wall outlets to minimize the possibility of electrical shock.

• Improper use of the grounded plug can increase the risk of electrical shock.

If the Power Cord is damaged, please contact Customer Service.

• Plug your appliance into an exclusive, properly installed, grounding wall outlet.

Do not damage the grounding means of the plug under any circumstances. Any questions

concerning power and/or grounding should be directed toward a certiﬁed electrician.

• This appliance requires a standard 110–120 V, 60 Hz electrical outlet with good

grounding means.

  

SAVE THESE INSTRUCTIONS

For Household Use Only

6 7

Drainpipe

After cleaning, you

can collect dirty water

from the Drainpipe

(there are two pipes.

One connects to the

evaporator. The other

connects to the Water

Tank under the Drawer).

Metal Housing

Control Panel

Ice Drawer Handle

Transparent Window

View stored ice level

Water Drain Cap

Ice Drawer

Water Tank

Hot Air Outlet

Power Cord

Cooling Vents

Parts Overview

Drip Tray

Operation

PREPARING BEFORE USE

1. Remove the exterior and interior packaging and check if all the accessories are included.

If any part is missing, please contact Customer Service.

2. Clean the interior with warm water, diluted detergent, and a soft cloth.

See the “Cleaning and Maintenance” > Page 11.

3. Place your Ice Maker on a dry, ﬂat, and sturdy surface. Leave a clearance

of 6 inches (15cm) on each side of the Ice Maker for proper ventilation.

4. Allow 24 hours for the refrigerant ﬂuid to settle down before plugging in your Ice Maker.

5. Discard the ﬁrst few batches of ice when using this appliance for the ﬁrst time

or after an extended period of time.

6. The power plug must be easily accessible.

“WATER

SHORTAGE”

“ICE” “CLEAN” “LIGHT”

“POWER”

“ICE

F U L L”INDICATORS

BUTTONS

CONTROL PANEL

NOTE:

• The Ice Maker should be far from direct sunlight and other sources of

heat (e.g.: stove, furnace, or radiator).

• Some types of under-cabinet lamps can be hot enough to cause

damage to your appliance top’s appearance.

8 9

FILLING THE WATER TANK

The Water Tank is under the Ice Drawer.

1. Remove the Ice Drawer and pour 0.58 gallon (2.2 liters) potable water into the Water Tank.

Slide in the Ice Drawer.

2. Put the Drip Tray in position.

Operation

IMPORTANT NOTE:

• Use ﬁltered water for better tasting ice and less scale buildup in the Ice Maker.

• For consistently clean and fresh ice, change the water in the tank every 24 hours.

Before storing or non-use for an extended period of time, drain the water from the

tank and wipe it dry.

• To avoid damage to this Ice Maker, ﬁll the Water Tank with room temperature or

cooler water. Do not use hot or boiling water.

• Monitor the water level in the tank and replenish the water periodically. When the

Water Tank has insufﬁcient water, the “Water Shortage” indicator will light up and

the unit enters standby mode. After replenishing water, touch the “ICE” button

twice to start the ice making. If you prefer, wait 15 minutes, the Ice Maker will

resume to work automatically.

Drinking

Water

HOW TO MAKE AND USE ICE

1. Before starting, check the Drainpipe behind the Ice Maker. Ensure the Water Drain Cap is

properly inserted into the Drainpipe.

2. Touch the “ICE” button. The “ICE” indicator will light up. After 5 seconds, the unit will

start ﬂashing and begin making ice. If you touch the “ICE” button again, the unit will stop

making ice. You can check the ice quantity in the Ice Drawer through the Transparent

Window.

3. When the Ice Drawer is full, the “ICE FULL” indicator will light up and the unit will stop

making ice automatically.

4. While the Ice Maker is on, check the water level periodically. When the “WATER

SHORTAGE” indicator lights up, ﬁll the Water Tank.

5. To Open the Ice Drawer: Hold the handle gently and pull it out horizontally until the back

of the Drawer contacts the front panel, then gently push it down. The Drawer will hang

at a slight angle.

6. To Close the Ice Drawer: Reverse the process. Hold the handle and place the Drawer

horizontally, then gently push it in place.

Operation

STARTING THE CLEANING PROGRAM

It is highly recommended to run the cleaning program before ﬁrst use (or when the unit has

been unused for an extended period). This cleaning process will take about 20 minutes.

1. Plug in the Power Cord. The “POWER” indicator will light up.

2. Check the Drainpipe behind the unit. Ensure the Water Drain Cap is inserted into the

Drainpipe or the appliance will not work properly.

3. Touch the “CLEAN” button. “CLEAN” indicator will light up and ﬂash after 5 seconds.

It will take at least 20 minutes to run the cleaning program. To stop the program, just

touch the “CLEAN” button again.

4. After the cleaning program is complete, move the unit to the edge of the surface while

making sure that the appliance is stable. Place a bowl or container under the appliance.

Release the Drainpipe from the back of the unit and pull out the plug from the Drainpipe.

This will cause the water in the tank under the Drawer and the evaporator to drain into

the water container. Reinsert the Drainpipe plug and replace the Drainpipe.

10 11

To Remove / Reload the Drawer: Hold the handle gently then pull the Drawer outwards

horizontally until the back of the Drawer contacts the front panel. Gently lift the Drawer

up at an angle (as shown) and pull it out. To reload the Drawer, reverse the steps. Tilt the

Drawer in the same direction at an angle (as shown). Put the back of the Drawer into the

unit’s front panel, slowly ﬂatten the Drawer, then gently push it in place.

LIGHT ON/OFF

Touch the “LIGHT” button to illuminate the Ice Drawer interior. To turn off the light, touch

the “LIGHT” button again.

NOTE:

• Always use the scoop to remove the ice from the machine. Do not use your hands

to remove the ice to avoid contamination.

• To maintain a clean and sanitary unit, do not return ice into the Ice Maker once it

has been removed.

ATTENTION:

• Empty the Drawer and Water Tank before turning the unit off, otherwise the water

may overﬂow.

Operation

COMMON OPERATING NOISES

Your new Ice Maker may make unfamiliar sounds. Most of these sounds are normal. Hard

surfaces like the ﬂoor, walls, and countertops can amplify these sounds.

Here are the sounds you may hear and their potential source:

• WHIR – When the appliance is ﬁrst turned on, you may notice the condenser

fan spinning.

• BUZZ – When the water pump ﬁrst turns on, it may be dry and slightly noisy.

Once it is ﬁlled with water, the noise reduces signiﬁcantly.

• RATTLE – Rattling noises may be produced from the ﬂow of the refrigerant.

These noises should reduce signiﬁcantly once the refrigerant system has stabilized.

• GURGLE – When the refrigerant system shuts off, there may be a brief gurgle

as the refrigerant stops ﬂowing.

• HUM – The compressor is a motor. It produces a low hum when running.

• CLICK – As nugget ice is produced, it drops into the Ice Drawer. You will hear the

loudest sounds when the ﬁrst nuggets impact with the empty ice bin. As the bin ﬁlls,

this noise reduces signiﬁcantly.

Cleaning and Maintenance

To keep your ice tasting fresh and your Ice Maker looking great, clean your Ice Maker regularly.

Unplug the unit before cleaning or maintenance.

Ice Drawer

Remove the Ice Drawer. Clean the interior with diluted detergent, warm water,

and a soft cloth.

Ice Scoop

Clean regularly with warm, soapy water. Dry the scoop before use.

Exterior and Interior

Remove the Water Drain Cap on the back. Drain out any water in the Drainpipes.

Use room temperature water and mild detergent with a soft cloth to clean the interior

of the Ice Maker. Rinse with water. Run 3 cycles of ice with new water and discard the

ice each time.

Dry the interior and exterior with a soft cloth.

Cooling Fan

Regularly check the cooling fan for dirt or dust buildup. With the power OFF,

use a soft, dry brush to gently remove buildup from the outside of the fan cover.

Cooling Vents

Regularly check the Cooling Vents for dirt or dust buildup.

With the power OFF, use a soft, dry brush to gently remove buildup from the vents.

Collect Dirty Water

After clearing the Drainpipes, you can collect dirty water for other uses

(it is non-potable). (See visual in Parts Overview > Page 6)

1. Remove the Drain Cap from the Drainpipe on the back of the appliance.

2. To collect dirty water, empty the Water Tank under the Ice Drawer.

3. Reinsert the Drain Cap and then the Drainpipe.

4. Wash the Water Tank and reinsert it.

Storage Requirements

If the unit will remain unused for an extended period, dump any remaining ice, and drain all

the water from the Water Tank. Completely dry the Ice Drawer and Water Tank. Once dry,

reinsert them into the appliance.

Store the Ice Maker upright in a dry, well-ventilated location.

Speciﬁcations

• Vesicant: C₅H₁₀

• Voltage/Current: 115 V~ 60 Hz, 2.7 A

• Net Weight: 33.73 lb

• Dimensions: L 16.1 × W 9.8 × H 16.5 in

NOTE: Do not immerse Ice Maker.

12 13

1. Unplug the Nugget Ice Maker.

2. Take off the drain cap and drain out the

water to a sink. See the ﬁgure below.

3. Replace the drain cap. See the ﬁgure

below.

4. Mix cleaning solution by diluting one

teaspoon of household bleach with ﬁve

cups of water for daily cleaning.

5. Pour the solution into the water reservoir,

up to the “MAX” water level. See the ﬁgure

below.

6. Plug in the Nugget Ice Maker and press

the “Clean” button to initiate the cleaning

process (20 mins). See the ﬁgure below.

7. When the “cleaning” indicator lights turns

off, take off the drain cap and drain out

the water to a sink.

8. Repeat steps 5 through 7 with fresh water

for two more cycles to rinse the inside.

9. Replace the drain cap. See the ﬁgure

below.

10.When completed, ﬁll the unit with fresh

water and press the “Ice” button to start

ice making process. See the ﬁgure below.

Monthly Cleaning

1. To remove mineral deposits, use white

vinegar instead of bleach-water solution

used for daily cleaning.

2. Fill the water reservoir halfway with

distilled white vinegar.

3. Plug in the Nugget Ice Maker and press

the “Clean” button to initiate the cleaning

process. Let the cleaning process run for

approximately ﬁve (5) minutes. After

5 minutes, unplug the appliance and leave

the white vinegar in the unit for over

12 hours.

4. After 12 h period take off the drain cap

and drain the vinegar in to a sink.

5. Repeat steps 5 through 7 with fresh water

for two more cycles to rinse the inside.

6. Replace the drain cap. See the ﬁgure

below.

7. When completed, ﬁll the unit with fresh

water and press the “Ice” button to start

ice making process. See the ﬁgure below.

Replace

the drain

cap

Daily Cleaning

Take off

the drain

cap

Untie

the

rope

Remove

the drain

tubes

upward

Take off

the drain

cap

Take off

the drain

cap

Replace

the drain

cap

Replace

the drain

cap

14 15

PROBLEM POSSIBLE CAUSE SOLUTION

No ice cubes

inside

There is an obstruction

inside the appliance

Remove the obstruction inside,

orclean the interior surface of the

Drawer. Unplug the unit and restart it.

“LIGHT” and “ICE”

icons ﬂashing

The ambient temperature

or water temperature in

the inner tank is too high

Run the Ice Maker below 90°F and pour

colder water into the tank.

Refrigerant liquid leakage Touch the “ICE” button twice to restart

the ice making program then wait for

50 minutes. If this problem reoccurs,

contact Customer Service.

Cover motor is broken

The cooling system pipe is

blocked

Slow ice

production

Hot Air Outlet has been

blocked

Hot Air Outlet must be guaranteed to

have more than 5.9 inches of clearance

for ventilation.

Water temperature in

inner tank is too high

Water temperature should be between

45–90°F.

Malfunctioning

refrigeration system

Contact Customer Service.

Water leakage Drain Cap is not in place Put the Drain Cap in place.

Loose pipe joint Contact Customer Service.

The seal has reached the

end of its service life

Contact Customer Service.

Mold Various causes If you notice mold or other residue

buildup on the Ice Maker, turn the unit

off then give it a thorough cleaning.

Use room temperature water and mild

detergent with a soft cloth to clean all

interior surfaces, rinse with water, then

run 3 cycles of ice making with new

water each time, discarding the ice.

Ideally, use a professional ice machine

descaler and sanitizing solution, while

following the manufacturer’s speciﬁc

instructions for use.

If the water, scoop, ice machine, and

immediate environment are kept clean

and hygienic, mold formation should be

avoided.

The water

indicator ﬂashes

when the water

tank is ﬁlled

The Ice Maker is started

before being ﬁlled with

water

Touch the “ICE” button twice to restart

the appliance.

hOmeLabs offers a limited one-year warranty (“warranty period”) on all of our products

purchased new and unused from hOmeLabs, LLC or an authorized reseller, with an original

proof of purchase and where a defect has arisen, wholly or substantially, as a result of

faulty manufacturing, parts, or workmanship during the one-year warranty period. The

warranty does not apply where damage is caused by other factors, including, but without

limitation to: (a) normal wear and tear; (b) abuse, mishandling, accident, or failure to follow

operating instructions; (c) exposure to liquid or inﬁltration of foreign particles; (d) servicing or

modiﬁcations of the product other than by hOmeLabs; (e) commercial or non-household use.

The hOmeLabs warranty covers all costs related to restoring the proven defective product

through repair or replacement of any defective part and necessary labor so that it conforms

to its original speciﬁcations. A replacement product may be provided instead of repairing a

defective product. hOmeLabs’s exclusive obligation under this warranty is limited to such

repair or replacement.

A receipt indicating the purchase date is required for any claim, so please keep all

receipts in a safe place. We recommend that you register your product on our website:

homelabs.com/reg. Although greatly appreciated, the product registration is not required

to activate any warranty and product registration does not eliminate the need for the

original proof of purchase. The warranty becomes void if attempts at repair are made by

non-authorized third parties and/or if spare parts, other than those provided by hOmeLabs,

are used. You may also arrange for service after the warranty expires

at an additional cost.

These are our general terms for warranty service, but we always urge our customers to

reach out to us with any issue, regardless of warranty terms. If you have an issue with

a hOmeLabs product, please contact Customer Service at homelabs.com/help

or help@homelabs.com.

This warranty gives you speciﬁc legal rights, and you may have other legal rights which vary

from state to state, province to province, or country to country. The customer may assert

any such rights at their sole discretion.

Manufacturing Information

This manual covers all items with these model numbers:

SKU: HME010694N

Rated Voltage/Frequency: 115V~ 60Hz

WarrantyTroubleshooting

HME010694N

[email protected]

EMAIL US

homelabs.com/help

CHAT WITH US

WARNING:

Keep all plastic bags away from children.

Distributed by hOmeLabs™, LLC

350 Springﬁeld Avenue, Suite #200,

Summit, NJ 07901

help@homelabs.com

homelabs.com/help

Made in China.

For Household Use Only

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali homelabs Macchina per il ghiaccio

homelabs

homelabs HME010019N Manuale utente

Manuali Macchina per il ghiaccio popolari di altre marche

Hoshizaki

Hoshizaki KMD-460MWJ Manuale utente

Sub-Zero

Sub-Zero 315I Istruzioni per l’uso

Unold

Unold 48945 Manuale utente

Kenmore

Kenmore 2217402A Manuale utente

Cornelius

Cornelius WM600 Istruzioni operative

GE XPIO43SCSS Manuale utente

Hoshizaki

Hoshizaki KMD-901MAH Manuale utente

Whynter

Whynter FIM-450HA Manuale utente

U-Line

U-Line UMCR014-SC01A Manuale di installazione

Andrew James

Andrew James AJ000522 Manuale utente

Scotsman

Scotsman CME1356 Manuale utente

Scotsman

Scotsman ACM 25 Manuale utente

Kärcher

Kärcher IP 120 Manuale utente

U-Line

U-Line SS1095 Manuale utente

Maytag

Maytag MIM1554WRS - Ice Maker Manuale utente

Hoshizaki

Hoshizaki KM-630MAH Manuale utente

Princess

Princess Yonanas Manuale utente

Unold

Unold 48946 Manuale utente

homelabs Nugget Manuale utente

Manuali Macchina per il ghiaccio popolari di altre marche
