4800dr

Document Reader

Imaging Guide

Disclaimer

Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other infor-

mation contained in this document without prior notice, and the reader should in all cases consult HII to

determine whether any such changes have been made. The information in this publication does not rep-

resent a commitment on the part of HII.

HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or

consequential damages resulting from the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are reserved.

No part of this document may be photocopied, reproduced, or translated into another language without

the prior written consent of HII.

Other product names or marks mentioned in this document may be trademarks or registered trademarks

of other companies and are the property of their respective owners.

Web Address: www.honeywell.com/aidc

Product Agency Compliance

USA

FCC Part 15 Subpart B Class A

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. Operation

of this equipment in a residential area is likely to cause harmful interference, in which case the user

will be required to correct the interference at his own expense.

Use only shielded data cables with this system.

Caution: Any changes or modifications made to this equipment not expressly approved by Honeywell

may void the FCC authorization to operate this equipment.

UL Statement

UL listed: UL60950-1.

Canada

Industry Canada ICES-003

This Class A digital apparatus complies with Canadian ICES-003. Operation is subject to the following

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired operation.

Conformité à la règlementation canadienne

Cet appareil numérique de la Classe A est conforme à la norme NMB-003 du Canada. Son

fonctionnement est assujetti aux conditions suivantes :

1. Cet appareil ne doit pas causer de brouillage préjudiciable.

2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le brouillage pouvant causer un

fonctionnement indésirable.

cUL Statement

cUL listed: CSA C22.2 No.60950-1-03.

Europe

The CE mark indicates compliance to 2004/108/EC EMC Directive with Standards EN55022

CLASS A, EN55024, EN61000-3-2, EN61000-3-3. In addition, complies to 2006/95/EC Low

Voltage Directive, when shipped with recommended power supply.

For further information please contact:

Honeywell Imaging & Mobility Europe BV

Nijverheidsweg 9-13

5627 BT Eindhoven

The Netherlands

Honeywell shall not be liable for use of our product with equipment (i.e., power supplies, personal

computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.

Waste Electrical and Electronic Equipment Information

Honeywell complies with Directive 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE

COUNCIL of 27 January 2003 on waste electrical and electronic equipment (WEEE).

This product has required the extraction and use of natural resources for its production. It may contain

hazardous substances that could impact health and the environment, if not properly disposed.

In order to avoid the dissemination of those substances in our environment and to diminish the

pressure on the natural resources, we encourage you to use the appropriate take-back systems for

product disposal. Those systems will reuse or recycle most of the materials of the product you are

disposing in a sound way.

The crossed out wheeled bin symbol informs you that the product should not be disposed of along

with municipal waste and invites you to use the appropriate separate take-back systems for product

disposal.

If you need more information on the collection, reuse, and recycling systems, please contact your local

or regional waste administration.

You may also contact your supplier for more information on the environmental performances of this

product.

Germany

GS Mark

GS marked to EN60950-1 and EN60825-1.

Australia/New Zealand

C-Tick Statement

Conforms to AS/NZS 3548.

South Korea

MIC Class A EMC requirements.

Mexico

Conforms to NOM-019.

International

Eye Safety Statement: LED

This device has been tested in accordance with IEC60825-1: 1993+A1+A2 LED safety, and has been

certified to be a Class 1 LED device.

Laser Eye Safety Statement

This product is under the limits of a class 2 laser device.

This device has been tested in accordance with and complies with IEC60825-1: 1993+A1+A2 and 21

CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice No. 50, dated June 24,

2007.

LASER LIGHT, DO NOT STARE INTO BEAM, CLASS 2 LASER PRODUCT, 1.0 mW MAX OUTPUT:

650nM.

Caution: Use of controls or adjustments or performance of procedures other than those specified

herein may result in hazardous radiation exposure.

Patents

Please refer to the product packaging for a list of patents.

Solids and Water Protection

The 4800dr has a rating of IP40, immunity of foreign particles and dripping water.

Document Reader Identification

LASER LIGHT. DO NOT STARE INTO BEAM

CLASS 2 LASER PRODUCT

1.0 mW MAX OUTPUT: 650nM

IEC60825-1: 1993+A1+A2

Complies with 21 CFR 1040.10 and 1040.11

except for deviations pursuant to Laser

Notice No.50, dated June 24, 2007.

Compliance

Label location

Laser Light Emissions

Chapter 1 - Imaging Commands

Single-Use Basis..................................................................................................................1-1

Command Syntax ................................................................................................................1-1

Step 1 - Take a Picture Using IMGSNP .................................................................................1-1

Image Snap - IMGSNP ........................................................................................................1-1

IMGSNP Modifiers .........................................................................................................1-2

P - Imaging Style .....................................................................................................1-2

B - Beeper ...............................................................................................................1-2

T - Wait for Trigger ..................................................................................................1-2

L - LED State ...........................................................................................................1-2

A - Aimer Lines ........................................................................................................1-3

E - Exposure ...........................................................................................................1-3

G - Gain ...................................................................................................................1-4

W - Target White Value ...........................................................................................1-4

D - Delta for Acceptance .........................................................................................1-4

U - Update Tries ......................................................................................................1-4

% - Target Set Point Percentage ............................................................................1-5

Step 2 - Ship a Picture Using IMGSHP or IMGACP ..............................................................1-5

Image Ship - IMGSHP .........................................................................................................1-5

Image Auto Crop - IMGACP ................................................................................................1-5

IMGSHP/IMGACP Modifiers ..........................................................................................1-6

A - Infinity Filter .......................................................................................................1-6

C - Compensation ...................................................................................................1-7

D - Pixel Depth ........................................................................................................1-7

E - Edge Sharpen ....................................................................................................1-7

F - File Format .........................................................................................................1-8

H - Histogram Stretch ..............................................................................................1-8

I - Invert Image ........................................................................................................1-9

IF- Noise Reduction ................................................................................................1-9

IU - Image Adaptive Text Filter .............................................................................1-10

IS - Unsharp/Brighten Filter ...................................................................................1-11

J - JPEG Image Quality .........................................................................................1-11

K - Gamma Correction ..........................................................................................1-11

L, R, T, B, M - Image Cropping .............................................................................1-12

P - Protocol ...........................................................................................................1-12

S - Pixel Ship .........................................................................................................1-13

U - Document Image Filter ....................................................................................1-13

V - Blur Image .......................................................................................................1-14

W - Histogram Ship ...............................................................................................1-14

Intelligent Signature Capture - IMGBOX............................................................................1-15

IMGBOX Modifiers .......................................................................................................1-16

A - Output Image Width .........................................................................................1-16

B - Output Image Height .......................................................................................1-16

Table of Contents

D - Pixel Depth ...................................................................................................... 1-16

F - File Format ...................................................................................................... 1-16

H - Height of Signature Capture Area ................................................................... 1-16

K - Gamma Correction .......................................................................................... 1-17

R - Resolution of Signature Capture Area ............................................................ 1-17

S - Barcode Aspect Ratio ..................................................................................... 1-17

W - Width of Signature Capture Area ................................................................... 1-17

X - Horizontal Barcode Offset ............................................................................... 1-18

Y - Vertical Barcode Offset ................................................................................... 1-18

Chapter 2 - Serial Default Commands

Conventions......................................................................................................................... 2-1

Menu Command Syntax ...................................................................................................... 2-1

Query Commands.......................................................................................................... 2-1

Concatenation of Multiple Commands........................................................................... 2-2

Responses..................................................................................................................... 2-2

Examples of Query Commands..................................................................................... 2-2

Menu Commands ................................................................................................................ 2-3

Chapter 3 - Customer Support

Technical Assistance........................................................................................................... 3-1

Online Technical Assistance.......................................................................................... 3-1

Product Service and Repair................................................................................................. 3-1

Online Product Service and Repair Assistance ............................................................. 3-2

1 - 1

Imaging Commands

The document reader is like a digital camera in the way it captures, manipulates, and transfers images.

The following commands allow you to alter the way the document reader performs these functions.

Single-Use Basis

Imaging Commands with their modifiers send instructions to the document reader on a single-use basis,

and take effect for a single image capture. Once that capture is complete, the document reader reverts

to its imaging default settings. If you want to permanently change a setting, you must use the serial

default commands (see Chapter 2). When the serial default command is used, that selection becomes

the new, permanent setting for the document reader.

Command Syntax

Multiple modifiers and commands can be issued within one sequence. If additional modifiers are to be

applied to the same command, just add the modifiers to that command. For example, to add 2 modifiers

to the Image Snap command, such as setting the Imaging Style to 1P and the Wait for Trigger to 1T, you

would enter IMGSNP1P1T.

Note: After processing an image capture command (IMGSNP or IMGBOX), you must follow it with an

IMGSHP or IMGACP command if you want to see it on your terminal.

To add a command to a sequence, each new command is separated with a semicolon. For example, to

add the Image Ship command to the above sequence, you would enter IMGSNP1P1T;IMGSHP.

The imaging commands are:

Image Snap - IMGSNP (page 1-1)

Image Ship - IMGSHP (page 1-5)

Intelligent Signature Capture - IMGBOX (page 1-15)

The modifiers for each of these commands follow the command description.

Step 1 - Take a Picture Using IMGSNP

Image Snap - IMGSNP

An image is taken whenever the hardware button is pressed, or when the Image Snap (IMGSNP) com-

mand is processed.

The image snap command has many different modifiers that can be used to change the look of the

image in memory. Modifiers always begin with numbers and end with a letter (case insensitive). Any

number of modifiers may be appended to the IMGSNP command. For example, you can use the follow-

ing command to snap an image, increase the gain, and have the beeper sound once the snap is com-

plete:

IMGSNP2G1B

1 - 2

IMGSNP Modifiers

P - Imaging Style

This sets the Image Snap style.

0P Decoding Style. This processing allows a few frames to be taken until the exposure

parameters are met. The last frame is then available for further use.

1P Photo Style

(default).

This mimics a simple digital camera, and results in a visually

optimized image.

2P Manual Style. This is an advanced style that should only be used by an experienced user.

It allows you the most freedom to set up the document reader, and has no auto-exposure.

B - Beeper

Causes a beep to sound after an image is snapped.

0B No beep

(default)

1B Sounds a beep when the image is captured.

T - Wait for Trigger

Waits for a hardware button push before taking the image. This is only available when using Photo

Style (1P).

0T Takes image immediately

(default)

1T Waits for a button push, then takes the image

L - LED State

Determines if the LEDs should be on or off, and when. Ambient illumination (0L) is preferred for taking

pictures of color documents, such as ID cards, especially when the document reader is in a stand.

LED illumination (1L) is preferred when the document reader is hand held. LED State is not available

when using Decoding Style (0P).

0L LEDs off

(default)

1L LEDs on

Altri manuali per 4800dr - Document Camera

Indice

Altri manuali Honeywell Telecamera per documenti

Honeywell

Honeywell 4800dr - Document Camera Manuale utente

Manuali Telecamera per documenti popolari di altre marche

AVer

AVer AVerVision F35 Manuale utente

Lumens

Lumens PS760 Manuale utente

Genee World

Genee World GV8100 Manuale utente

Touchboards

Touchboards Vidifox DV 480 Manuale utente

Dukane

Dukane 210 Manuale utente

TTS

TTS Easi-View Pro Manuale utente

Lumens

Lumens dc153 Manuale utente

Avermedia

Avermedia AVerVision SPB350 Manuale utente

AVer

AVer TR311V2 Manuale utente

Inswan

Inswan INS-3 Manuale utente

Genee

Genee Vision 6100 Manuale utente

Rolls

Rolls DB14 - 02/10 Manuale utente

Lumens

Lumens DC-W80 Manuale utente

AVer

AVer AVerVision SPB350+ Manuale utente

Dukane

Dukane FASTFAX AV-P750U Manuale utente

Optoma

Optoma DC554 Manuale utente

Ipevo

Ipevo Ziggi Manuale utente

Vidifox

Vidifox PV 380 Manuale utente
