Honeywell HD5 Series Manuale utente
Document 800-04763 – Rev B – 08/09
User Guide
HD5
Pendant or Ceiling Mount
Fixed Dome Camera
2
Revisions
Issue Date Revisions
A 07/09 New document to replace 800-03526 Rev
A; changed the DIP switch settings for
configuring a 540 TVL camera
B 08/09 New Revision created to include the
missing Table of Contents
Document 800-04763 Rev B 3
08/09
Warnings
WARNING! The Use of CSA Certified/UL Listed Class 2 power
adapters is required to ensure compliance with
electrical safety standards.
WEEE (Waste Electrical and Electronic Equipment). Correct disposal of
this product (applicable in the European Union and other European
countries with separate collection systems). This product should be
disposed of, at the end of its useful life, as per applicable local laws,
regulations, and procedures.
Read Instructions All the safety and operating instructions should be read
before the equipment is operated.
Retain Instructions The safety and operating instructions should be
retained for future reference.
Cleaning Do not use liquid aerosol cleaners. Use a damp soft cloth.
Attachments Never add any attachments and/or equipment without the
approval of the manufacturer as such additions may result in the risk of fire,
electric shock, or injury.
Water and/or Moisture This is an indoor rated product. To prevent fire or
shock hazard, do not expose this camera to rain or moisture.
Do not use this equipment near water or in contact with water.
4
Accessories Wall or shelf mounting should follow the manufacturer’s
instructions, and should use a mounting kit approved by the manufacturer.
Power Sources This equipment should be operated only from the type of
power source indicated on the marking label. If you are not sure of the type
of power, please consult your equipment dealer or local power company.
Servicing Do not attempt to service this equipment yourself. Refer all
servicing to qualified service personnel.
Field Installation This installation should be made by a qualified
service person and should conform to all local codes.
Explanation of Graphical Symbols
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF
ELECTRIC SHOCK IS PRESENT
WITHIN THE UNIT.
THIS SYMBOL INDICATES THAT
IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS
ACCOMPANY THIS UNIT.
CAUTION
Document 800-04763 Rev B 5
08/09
FCC Compliance Statement
Information to the User: This equipment has been tested and found
to comply with the limits for a Class A digital device. Pursuant to Part
15 of the FCC Rules, these limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Caution Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003
du Canada.
6
Manufacturer’s Declaration of
Conformance
The manufacturer declares that the equipment supplied with this guide is
compliant with the essential protection requirements of the EMC directive
2004/108/EC and the Low Voltage Directive (LVD) 2006/95/EC, conforming
to the requirements of standards EN 55022 for emissions, EN 50130-4 for
immunity, and EN60065 for Electrical Equipment safety.
Document 800-04763 Rev B 7
08/09
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Description . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Camera Model Configurations . . . . . . . . . . . . . . . . 10
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . 13
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installing the Lens . . . . . . . . . . . . . . . . . . . . . . . 17
Housing Installation . . . . . . . . . . . . . . . . . . . . . . 19
Installing without a Back Box . . . . . . . . . . . . 19
Installing a Pendant Dome . . . . . . . . . . . . . 20
Installing with a Back Box (ceiling or wall mount). . 22
Setting Up the Camera. . . . . . . . . . . . . . . . . . . . . . 24
Connecting a Spot Monitor . . . . . . . . . . . . . . . . . . 24
Adjusting the Field of View and Focus . . . . . . . . . . . . 25
Adjusting the Field of View (FOV) . . . . . . . . . . 25
Focusing the Lens . . . . . . . . . . . . . . . . . . 26
Configuring the Camera. . . . . . . . . . . . . . . . . . . . 27
Configuring a 540 TVL Camera . . . . . . . . . . . 28
Configuring a WDR Camera . . . . . . . . . . . . . 30
Configuring a DNR Camera . . . . . . . . . . . . . 41
Installing the Turret . . . . . . . . . . . . . . . . . . . . . . 50
Attaching the Safety Lanyard . . . . . . . . . . . . . . . . . 51
Installing the Lower Dome. . . . . . . . . . . . . . . . . . . 52
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 58
8
Document 800-04763 Rev B 9
08/09
Introduction
Description
The HD5 series of stationary dome cameras is ideal for discreet fixed
camera surveillance where high-quality video is a necessity. Each unit
combines a high-performance camera and a full-sized lens into a 5" dome.
Features
The HD5 series includes the following features:
• Easy dome installation into a standard 4" x 4" x 2-1/8" electrical box
• Black or white trim-ring finishes available
• Simple installation and maintenance
• Adjustable camera mount (included with camera/lens)
• NTSC and PAL versions; ETL, EMC, and EU (CE) certified
• Vari-focal lenses available:
Auto iris lenses: 2.7–13.5 mm or 5–50 mm
or
Manual iris lenses: 2.7–13.5 mm or 5–50 mm
• Optional UTP (CAT5) video transmission
• 4-pin Auto Iris connector standard
10
Camera Model Configurations
There are three camera models (HD5CH, HD5U, or HD5SD), two
connection format choices, (Coaxial or UTP), four lens choices, four lower
dome choices, and two video format choices (NTSC or PAL). The part
number of your camera indicates what choices have been made.
