Honeywell FBII OMNI 624 Istruzioni per il montaggio

N9967V3 4/04 Rev. A

FBII Security System

Security SystemSecurity System

Security System

OMNI®624

Version 2.X

Installation and Setup Guide

THANK YOU for your purchase of the

OMNI624 Security System.

The purpose of this manual is to give you a brief overview of the OMNI®624 control panels, and

provides instructions for installing a basic system. Honeywell is always available to serve YOU.

Our SALES and TECHNICAL SUPPORT staff are available to assist you in any way possible.

World Wide Web Address ..........................................http://www.honeywell.com/security

FAX ............................................................................................................... 516-921-4327

Sales

Inside the United States ..................................................................... 800-645-5430

Outside the United States................................................................... 516-921-8666

Technical Support: (8 a.m.-8 p.m. E.S.T.)

Inside the United States ..................................................................... 800-645-7492

Outside the United States................................................................... 516-921-8666

Before you call Technical Support, PLEASE be sure you:

•Check the wiring diagram and verify your connections.

•Check all fuses.

•Assure that the transformer and backup battery voltages are supplying the proper voltage

levels.

•Verify your programming information.

•Read this manual thoroughly.

•Consult the Troubleshooting Section of this manual.

•Note the proper model number of this product, and the version level (if known) along with any

documentation that came with the product.

•Have your company name and telephone number ready.

This information will allow us to service you more quickly and effectively. Please, remember to

BE PATIENT while waiting on the telephone; your call will be answered as soon as possible.

FOR YOUR CONVENIENCE, a separate Programming Guide is included with this manual. It

provides space for listing entries for each programming question.

NEW FEATURES OF VERSION 2.X

•

Wireless Jamming Detection Processing

•

Crystal Controlled Real-Time Clock

•

Silent Zone, RF Jam, and Keypad Tamper

Triggers

•

Keypad Tamper to Detect Keypad Removal

•

Activate Dial Delay if Armed-Stay Option

•

Keypad Supervision and Zone Unbypass

Logged

iii

Table of Contents

•••••••••••••••••••••••••••••••••••••••••••

SECTION 1 – CENTRAL STATION REPORTING FORMATS....................................................... 1–1

System Features .................................................................................................................................. 1–1

Special Notes........................................................................................................................................ 1–2

SECTION 2 – SYSTEM WIRING AND HOOKUP .............................................................................. 2–1

System Wiring Diagram ...................................................................................................................... 2–1

Terminal Connections.......................................................................................................................... 2–2

Auxiliary Device Current Draw Worksheet........................................................................................ 2–5

Wiring Information for Keypads & Other Devices............................................................................. 2–6

SECTION 3 – PC BOARD AND KEYPAD MOUNTING ................................................................... 3–1

Mounting the OMNI624 PC Board ..................................................................................................... 3–1

Mounting the RF Expander Module ................................................................................................... 3–2

Mounting the Zone Expander Module ................................................................................................ 3–2

Keypad Mounting Instructions ........................................................................................................... 3–2

SECTION 4 – SYSTEM CONFIGURATION ....................................................................................... 4–1

Partitioning .......................................................................................................................................... 4–1

Hardwire Zones and Zone Expansion Module.................................................................................... 4–1

Wireless Transmitters ......................................................................................................................... 4–2

Relay/Trigger Outputs......................................................................................................................... 4–3

Paging Feature..................................................................................................................................... 4–4

SECTION 5 – SYSTEM OPERATION.................................................................................................. 5–1

Power Up/System Reset....................................................................................................................... 5–1

Keypads ................................................................................................................................................ 5–1

Keypad Sounder................................................................................................................................... 5–3

Keypad Backlight Timer...................................................................................................................... 5–4

Keypad Addressing .............................................................................................................................. 5–5

Arming the System .............................................................................................................................. 5–5

User Code Programming ..................................................................................................................... 5–8

User Deletion ..................................................................................................................................... 5–10

Keypad Emergency Conditions ......................................................................................................... 5–10

Quick Command Modes..................................................................................................................... 5–11

SECTION 6 – SYSTEM PROGRAMMING .......................................................................................... 6–1

Programming Methods ........................................................................................................................ 6–1

System Default..................................................................................................................................... 6–1

Keypad Programming.......................................................................................................................... 6–2

Installer Modes Summary ................................................................................................................... 6–5

Data Entry via Keypads ...................................................................................................................... 6–9

Summary of System Programming ................................................................................................... 6–11

Programming Submode 1: SYSTEM OPTIONS ............................................................................... 6–11

Programming Submode 2: ZONE PROGRAMMING / REPORT CODES ....................................... 6–45

Programming Submode 3: WIRELESS TRANSMITTER PROGRAMMING.................................. 6–51

Programming Submode 4: DESCRIPTOR PROGRAMMING ......................................................... 6–53

SECTION 7 – SUMMARY OF KEYPAD FUNCTIONS ..................................................................... 7–1

User Functions..................................................................................................................................... 7–1

Installer Modes .................................................................................................................................... 7–2

SECTION 8 – CENTRAL STATION REPORTING FORMATS....................................................... 8–1

General Information ............................................................................................................................ 8–1

Standard (3x1 or 4x1) .......................................................................................................................... 8–1

Extended (3x1 Ext. or 4x1 Ext.) .......................................................................................................... 8–2

Partial Extended (3x1 Part. Ext. or 4x1 Part. Ext.) ........................................................................... 8–2

3x2 or 4x2 ............................................................................................................................................. 8–3

FBII Superfast (4x3x1) ........................................................................................................................ 8–3

ADEMCO 4x1 Express ........................................................................................................................ 8–4

ADEMCO 4x2 Express ........................................................................................................................ 8–4

ADEMCO Contact ID .......................................................................................................................... 8–5

SECTION 9 – TROUBLESHOOTING.................................................................................................. 9–1

SECTION 10 – REGULATORY/LIMITATIONS STATEMENTS................................................... 10–1

SECTION 11 – CE LOW VOLTAGE DIRECTIVE............................................................................ 11–1

Conventions Used in This Manual

•••••••••••••••••••••••••••••••••••••••••••

Before you begin using this manual, it is important that you understand the meaning of the following

symbols (icons) and text note.

ULThese notes include specific information that must be followed if you are installing this system

for a UL Listed application.

These notes include information that you should be aware of before continuing with the

installation, and which, if not observed, could result in operational difficulties.

This symbol indicates a critical note that could seriously affect the operation of the system, or

could cause damage to the system. Please read each warning carefully. This symbol also

alerts the user to the possibility of physical harm if instructions are not followed as written

Note: These text notes are provided throughout the manual to provide informative information and

shortcut tips for the installer.

1–1

SECTION 1

Introduction

•••••••••••••••••••••••••••••••••••••••••••

System Features

The OMNI®624 is a state-of-the-art microprocessor-based control/communicator that provides 2

partitions and supports both hardwire and wireless zones. Programming can be performed through any

of the compatible keypads, or the system can be uploaded and downloaded remotely using the Compass

Downloader Software. Additionally, the software can be programmed to control remote actions, such as

arming, disarming, bypassing, etc. Programming options are stored in an Electrically Erasable

Programmable Read Only Memory (EEPROM). The EEPROM is nonvolatile, meaning that

programmed instructions will not be lost in the event of a loss of power.

Features of the OMNI624 include:

•2 independent partitions

•Up to 24 zones that may be comprised of a

combination of hardwire and wireless or

wireless zones

•6 hardwire zones (all fully programmable,

including keyswitch), expandable to 8

additional hardwire zones using optional plug-

in OMNIEXP8 Expansion module

•Hardwire zones can be configured as standard

or double-balanced, or can be set for zone

doubling (providing up to 24 hardwire zones if

zone expander is used)

•Up to 24 wireless protection zones plus up to 8

wireless keys

•Cross-zoning capability

•32 User Codes (either 4-digit or 6-digit codes

can be used)

•Up to 12 keypads (OMNI-LCD, OMNI-LCD-US,

XK7LC, OMNI-KP, OMNI-KP-US)

•OMNI-LCD, OMNI-KP, and XK7LC keypads

are not for sale in the USA.

•XK108 keypads may also be used;

however, the system can only have XK108

type keypads attached and the system must

be set up as having one partition.

•Keypad programming and remote programming

via PC and modem

•3 emergency keypad conditions (Panic, Fire, &

Auxiliary)

•128 Event History Log (alarms, troubles, low

battery, bypasses, central station (CS) test,

openings & closings) and keypad events

•20 programmable relay outputs (using optional

XL4705 modules)

•4 built-in programmable trigger outputs (2

triggers if relay module is used)

•Real-time clock (displays time & date via LCD

keypad) with reminder when clock needs to be

set

•CS test timer by event, time or both (1 hour, 1,

7, 27, 60, 90 Days)

•Customer control of Chime mode and Pager

mode

•Quick Arming, Quick Bypass, and Quick Force

Arming

•CS reporting by zone

•False alarm prevention features: Crossed

Zones, Exit Error, Recent Close, Swinger

Shutdown

•Cancel Code & System Stabilization during

power-up

•Arming by keyswitch in Away or Stay mode

•Keypad Tamper/Lockout with optional CS

reporting

•Restore transmission options: After Loop or

After Bell

OMNI624 Installation and Setup Guide

1–2

•Upload/download and remote commands

•3 methods of uploading/downloading: PC,

operator-initiated, and unattended

•Paging (audio format) capabilities

•Auto-arming at a specific time of day with

capability to arm in either Away, Stay, or

Instant modes

•Dual entry timers

•Fire zone reset through keypad

•Glassbreak reset through keypad

•Bell Test, Low Battery Test, AC loss and

communications failure

•Input power: 16.5VAC, 25VA; 12VDC, 4-7AH

•Output power: 12VDC, 500mA

•Bell output power: 12VDC, 1A

Special Notes

IMPORTANT - Failure to install and program this unit in accordance with the UL

requirement is a violation of the listing mark. For more information on UL Listings,

contact Underwriters Laboratories, Progress Department, 333 Pfingsten Road,

Northbrook, IL 60062.

UL Listings

The OMNI624 is the Residential (Household) version of the control panel, and has been Listed by

Underwriters Laboratories for the following applications:

•UL 1023 Household Burglary

•UL 985 Household Fire Warning

FCC Registration Number: 5GBUSA-44003-AL-E

References to Programming Questions

Programming questions are grouped into 4 installer programming submodes, as follows:

1 – System Options

2 – Zone and Report Code Programming

3 – Wireless Zone/Keyfob Programming

4 – Zone Descriptor Programming

Throughout this manual, programming question references without a submode designation pertain to

questions in submode 1 (system options). Programming questions for other submodes include the

appropriate submode number.

2–1

SECTION 2

System Wiring and Hookup

•••••••••••••••••••••••••••••••••••••••••••

System Wiring Diagram

OMNI624 Installation and Setup Guide

2–2

SYSTEM STABILIZATION MODE: When powering up a system that was previously armed when

power was removed, the system will enter a 2-minute stabilization period. This 2-minute interval is

used to allow motion detectors to stabilize. “PLEASE STAND BY” and “POWER UP DELAY” are

displayed on the OMNI-LCD, OMNI-LCD-US and XK7LC keypads. “PL” is displayed on the OMNI-

KP and OMNI-KP-US keypads, and the Armed LEDs on both types of keypads are lit. All LEDs on

the XK108 keypad are lit.

Terminal Connections

1 & 2 — TRANSFORMER: Connect the 16.5VAC 25VA transformer, utilizing 18AWG (1mm dia.) or

larger wire at a distance not to exceed 15 feet (4.5m) from the panel, to an unswitched source of

AC mains power (120 or 220VAC).

The system can supply up to 1.8 amps of total current.

For US installations, use an ADEMCO No. 1321 transformer or for Canadian installations, use an

ADEMCO No. 1321CN transformer. For all other installations, use a transformer that complies

with the above specifications. Do not use any other rating transformer, as this may result in

improper operation or damage to the unit.

The “AC/LOW BAT” keypad LED remains ON while AC power is present. If an AC loss occurs, the

“AC/LOW BAT” LED turns off immediately. If AC power remains OFF for 15 minutes, the system

pulses the keypad buzzer and transmits a power-loss message to the central station, if programmed

to do so. THE KEYPAD BUZZER CAN BE SILENCED by entry of any valid user code. When AC

restores, the “AC/LOW BAT” LED lights immediately, and a Restore code is reported, if

programmed.

3(+) & 4(–) — BELL OUTPUT: The total output power available for sounding devices is 1 amp (650 mA

for UL installations) at 11.5 - 13.1VDC. These terminals will deliver CONSTANT output on

BURGLARY, AUDIBLE PANIC, and BELL TEST. On a FIRE condition, a PULSED or TEMPORAL

output can be generated. There are separate bell cutoff times programmable for burglary and fire

conditions within the programming sequence. For UL Household Fire Warning System

installations, the speaker must be mounted indoors for best audibility. Also, for UL installations,

use only one speaker.

NOTE: Before connecting sounding devices, please consult their specifications for proper current

draw. Otherwise, the bell fuse (F1) may be blown.

NFPA 72 REQUIREMENT: All the

interconnecting pathways (cable,

wire, etc.) between the alarm

system initiating device (control

panel) and the signaling device

(bell, speaker, siren, etc.) shall be

monitored for an occurrence of an

open circuit, which prevents the

normal operation of the system. An

occurrence of an open circuit shall

be indicated by a distinctive trouble

signal.

BELL SUPERVISION (Bell) - To meet the NFPA 72

requirement, program Question 12, Location 3, in

Programming Submode 1 for bell supervision. The bell is then

supervised for an open circuit (not a short circuit) across the

bell output terminals; the keypad will indicate that a bell

supervision condition has occurred and fire trouble is reported

to the CS if enabled. If the bell is already ringing, the

supervision will not take effect until after bell cutoff time. Refer

to the following diagrams:

Indice

Altri manuali Honeywell Sistema di sicurezza

Honeywell

Honeywell 5800WAVE - Ademco Wireless Siren Istruzioni per il montaggio

Honeywell

Honeywell ADEMCO VISTA-15PSIA Istruzioni per il montaggio

Honeywell

Honeywell VISTA-128BPEN Istruzioni per il montaggio

Honeywell

Honeywell VISTA-128BP Manuale utente

Honeywell

Honeywell Ademco Vista-48LA Istruzioni per il montaggio

Honeywell

Honeywell ADEMCO Vista-12C Istruzioni per il montaggio

Honeywell

Honeywell Tuxedo Touch Manuale utente

Honeywell

Honeywell Friedland FGGA04 Series Manuale utente

Honeywell

Honeywell Accenta Series Guida rapida

Honeywell

Honeywell LYNX Touch SIA Manuale utente

Honeywell

Honeywell VISTA-128BP Istruzioni per il montaggio

Honeywell

Honeywell VISTA-128FBP Manuale utente

Honeywell

Honeywell Frieland FGGA06 Series Manuale utente

Honeywell

Honeywell V4000 Manuale utente

Honeywell

Honeywell Fire-Lite Alarms W-BG12LX(A) Manuale utente

Honeywell

Honeywell Lynx Plus Series Manuale utente

Honeywell

Honeywell Ademco Lynx Touch Manuale utente

Honeywell

Honeywell Fire-Lite Alarms ANN-80 Series Manuale tecnico

Honeywell

Honeywell AlarmNet 7845GSM Manuale utente

Honeywell

Honeywell NOTIFIER PAN1-PLUS Manuale utente

Honeywell

Honeywell ADEMCO LYNXR Series Manuale utente

Honeywell

Honeywell Ademco Vista-12D Istruzioni per il montaggio

Honeywell

Honeywell Friedland GlobalGuard Manuale utente

Honeywell

Honeywell NOTIFIER DSE3-23 Series Manuale utente

Manuali Sistema di sicurezza popolari di altre marche

Inner Range

Inner Range Concept 2000 Manuale utente

Climax

Climax Mobile Lite R32 Istruzioni per il montaggio

CADDX

CADDX NX-6 Manuale utente

FBII

FBII XL-31 Series Manuale utente

Johnson Controls

Johnson Controls PENN Connected PC10 Manuale utente

Aeotec

Aeotec Siren Gen5 Manuale utente

Blaupunkt

Blaupunkt SA 2700 Manuale utente

IDEAL

IDEAL Accenta Manuale del proprietario

AJAX

AJAX DoubleButton Manuale utente

Swann

Swann SW-P-MC2 Manuale utente

Ecolink

Ecolink Siren+Chime Manuale utente

Digital Monitoring Products

Digital Monitoring Products XR150 Manuale utente

EDM

EDM Solution 6+6 Wireless-AE Manuale utente

Highway Safety Group

Highway Safety Group EA401 Manuale utente

Siren

Siren LED GSM Manuale utente

Detection Systems

Detection Systems 7090i Istruzioni per il montaggio

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuale utente

Siemens

Siemens FDM273 Manuale utente
