How to assemble the battery holder

1.Material and tools needed:

- Battery holder, LED bulb,

tape, screw driver and 2 piece

AAA size battery(not provided)

2. Use screw driver and

take the lid off from the

battery holder.

3. Insert the battery take

notes on the polarity.

4. Connect the red wire

to grey wire. Connect

the black wire to white

wire.

5.Wrap the exposed wire

with the tapes.

6. Place the box lid and

fastness with screw driver.

1.Picures shown on the package may be slightly different from the actual product.

2.All the materials are taken in the operation step, put the remaining materials back into

the original pocket until the installation is completed.(Avoid material loss during installation)

3.The dimensions indicated in the step diagram are“cm”.

4.If there have template paper material, please cut the material according to the template

to avoid mistakes..

5.According to the part rule example at the bottom of this page, refer to the part on the part

number drawing, find the material object and compare with the material list, confirm and

install.(Wooden parts only)

6.Glue should not be applied too much, so as not to dry longer, overflow will affect the effect

of the finished product.

7..Part shapes may differ from the photographs depending on he production batch

Be sure to test the LED lights before making the lighting,

note that the LED white wire to the negative, gray wire

to the positive reference to the following figure

operation test.

1 2

Tips for assembling

Testing on LED function

DO NOT contact the

LED wire end direct

to the battery cell.

Use the provide battery

holder. Make sue the

correct polarity.

Thumbnail of material list (reference only)

Thumbnail of printing paper & template paper (reference only)

Details of minature

Welcome to the DIY world,

Let's follow me to do it now!

Name Material package

Printing paper A package of A16 all printed paper is concentrated on A16 paper

accessories ( )7 sheets of A4 single side

Small dining car

E bag + H bag + printing paper

Beef offal car

Postbox

counter

easel

Street sign

bed

Potted plants

light

Hanging Board

Roman column

window of first floor

memorial arch

outer frame

Table & Chair

Sugar-coated haws

E bag + G bag + H bag+ printing paper

F bag + printing paper

A bag+ F bag + G bag + H bag + printing paper

F bag + G bag + printing paper

F bag + G bag+ H bag

H bag + J bag

H bag+ G bag+ printing paper

B bag + G bag + H bag+ printing paper

C bag

A bag + B bag + J bag+ printing paper

A bag+ B bag + C bag+ D bag + G bag

+ J bag + printing paper

A bag + F bag + G bag+ printing paper

G bag + H bag + printing paper

A bag + B bag+ C bag+ printing paper

Stairs of first floor Page 9

Page 10

Page10-14

Symbol description used

Install parts

in the opposite

direction

Install the same

parts on both

sides

Pay attention to the direction of installation material B stick to

material A

Pay attention to the direction of installation material A stick to

material B

Fold in half

according

to dotted lin

fold double

edge to center

dotted line

Fold four sides

to the middle 123

combination part

according so on.

Page 9

Page7-8

Page6-7

Page 6

Page5-6

Page 5

Page4-5

Page 4

Page3-4

Page 3
