Hoshizaki KM-1300SAH-E Manuale utente

• Up to 544 kgs. of ice production per 24 hours

• Durable stainless steel exterior

• Protected by HoshiGuard Antimicrobial Agent

• CycleSaver®design

•EverCheck®alert system

•Individual crescent cube

•Stainless steel evaporator

• Stackable for 1088 kgs. per 24 hour ice production in the same floor space

• Removable air filters

• R-404A Refrigerant

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com

CUBER DIMENSIONS

W x D x H

KM-1300SAH-E

9/06

Item # 13055

STACKABLE ICE CUBER

Warranty

Contact factory for warranty information.

KM-1300SAH-E

Hoshizaki reserves the right to change specifications without notice.

KM-1300SAH-E

Air-Cooled

Shown on an optional

B-900

KM-1300SAH-E

122 x 69.5 x 69.5cm

Item #

Project:

Qty:

*AutoCad available on KCL

Also available on Large Bins:

B-1150SS

B-1300SS

B-900

B-800

Hoshizaki

OPERATING LIMITS

• Ambient Temp Range 7 - 38˚C

• Water Temp Range 7 - 32˚C

• Water Pressure 0.7 - 8 kg/cm2

• Voltage Range 198 - 254V

ELECTRICAL & PLUMBING/KM-1300SAH-E

• 220 - 240V/50/1

• 20 amp Max Fuse

• 1.27cm OD copper or equivalent independent potable water supply

• 3/4” FPT independent drain connection

SERVICE

• Panels easily removed and all components

accessible for service.

• Removable/cleanable air filters.

DIMENSIONS

W x D x H

KM-1300SAH-E

122 x 69.5 x 69.5cm

ACKABLE ICE CUBER

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com Printed in U.S.A.

KM-1300SAH-E

STACKABLE ICE CUBER

UTILITY CONSUMPTION at 32ºC A/ 21ºC W

Model Number

21˚

10˚21˚

544

32˚

27˚

32˚

Ice Production

Per Cycle

KWH per

45 kgs.

Potable

Water

Liters per

45 kgs.

Kgs. Cubes

KM-1300SAH-E

Air Temp˚C.

Water Temp˚C.

SPECIFICATIONS

Model Number Condenser Amperage Min. Circuit

Ampacity

Shipping

Weight

11.5 20 143 kgs.

Air-Cooled

KM-1300SAH-E

5.5 126.4

512

502

446

448

395

346

13.7 1440

400

Condenser

Water

Liters per

45 kgs.

N/A

AIR - COOLED

STORAGE BINS

Model Number Application Capacity

• Air-cooled

FRONT VIEW SIDE VIEW

AIR-COOLED UNIT

ICE DROP ZONE

B-900 409 kgs.

B-1150 522 kgs.

B-800 364 kgs.

B-1500 681 kgs.

B-1650 749 kgs.

B-1300 590 kgs.
