Hoshizaki KM-151BAH Manuale utente

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com

CCBBEERR DDIIMMEENNSSIIOONNSS

W x D x H

KM-151BAH

4/08

Item # 13210

SELF-CONTAINED C BER WITH B ILT-IN STORAGE BIN

Warra ty

Valid in United States, Canada, uerto Rico, & U.S. Territories. Contact factory for warranty in

other countries.

Three Year - arts & Labor on entire machine.

Five Year - arts & Labor on: Evaporator.

Five Year - arts on: Compressor, air-cooled condenser coil.

KM-151BAH

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

KM-151BAH

233/4 x 28 x 39*

* with 6" legs

*AutoCad available on KCL

KM-151BAH

Air-Cooled

Shown

•Up to 146 lbs. of ce product on per 24 hours

• Up to 78 lbs. of bu lt- n storage capac ty

• Ind v dual crescent cube

•Durable sta nless steel exter or

• CycleSaver®Des gn

• EverCheck®alert system

• Front n, front out a rflow

• Sta nless steel evaporator

• Sl de n door

• Removable a r f lter

• Power sw tch access ble w thout panel removal

• Bu lt- n nstallat on poss ble

• Compl es w th Cal forn a Energy Comm ss on (CEC)

• R-134a Refr gerant

* The KM-151BAH is ENERG STAR certified.

Hoshizaki

DIMENSIONS

W x D x H

KM-151BAH

233/4 x 28 x 39*

*with 6" legs

©HOSHIZAKI AMERICA, INC.

KM-151BAH

SELF-CONTAINED CUBER WITH BUILT-IN STORAGE BIN

UTILITY CONSUMPTION

Mo el Number Ice Pro uction

Per Cycle

KWH per

100 LBS.

Potable

Water

Gal. per

100 lbs.

Lbs. Cubes

KM-151BAH

SPECIFICATIONS

Mo el Number Con enser Amperage Min. Circuit

Ampacity Shipping

Weight

7.0 15A 150 lbs.

KM-151BAH

8.4 17.8

Air-Cooled

2.75 130

Con enser

Water

Gal. per

100 lbs.

N/A

O P E R AT I N G L I M I T S

• Ambient Temp Range 45 - 100˚F

• Water Temp Range 45 - 90˚F

• Water ressure 10 - 113psig

• Voltage Range 104 - 127V

ELECTRICAL&PLUMBING/KM-151BAH

• 115V/60/1

• 15 amp Max Fuse/HACR Breaker Size

• 3/8” OD copper or equivalent independent potable water supply

• 3/4” independent drain connection

• 1/2” F T Water Inlet

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com Printed in U.S.A.

KM CUBE DIMENSIONS

• Air-cooled

AIR-COOLED

70˚

50˚ 70˚

146

90˚

80˚

90˚

Air Temp˚ F.

Water Temp˚ F.

140

139

129

119

111

121

FRONT DIMENSIONS

BACK DIMENSIONS

SIDE DIMENSIONS
