Hoshizaki KM-250BWF Manuale utente

•Up to 233 lbs. of ice productio per 24 hours

•Built-i 100 lbs. ice storage

•I dividual cresce t cube

•Protected by HoshiGuard A timicrobial Age t

•CycleSaver®Desig

•EverCheck®alert system

•Stai less steel evaporator

•Corrosio -resista t stai less a d PVC exterior surfaces provide lo ger life

•Stai less steel evaporator

•Removable air filter

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com

CUBER DIMENSIONS

WxDxH

KM-250BWF

4/08

Item # 13201

CRESCENT CUBER WITH BUILT-IN STORAGE BIN

Warranty

Valid in nited States, Canada, Puerto Rico, & .S.Territories. Contact factory for warranty in

other countries.

Three Year - Parts & Labor on entire machine.

Five Year - Parts & Labor on: Evaporator.

Five Year - Parts on: Compressor, air-cooled condenser coil.

KM-250BWF

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

KM-250BWF

25 x 28 x 39

*AutoCad available on KCL

KM-250BWF

Water-Cooled

Shown

KM-250

Hoshizaki

DIMENSIONS

WxDxH

©HOSHIZAKI AMERICA, INC.

KM-250BWF

CRESCENT CUBER WITH BUILT-IN STORAGE BIN

UTILITY CONSUMPTION

Model Num er

Ice Production

Per Cycle

KWH per

100 LBS.

Pota le

Water

Gal. per

100 l s.

L s. Cu es

KM-250BWF

SPECIFICATIONS

Model Num er Condenser Amperage Shipping

Weight

7.5 190 lbs.

Water-Cooled

KM-250BWF

90/70

Condenser

Water

Gal. per

100 l s.

O P E R AT I N G L I M I T S

• Ambient Temp Range 45 - 100˚F

• Water Temp Range 45 - 90˚F

• Water Pressure 10 - 113psig

• Voltage Range 104 - 127V

ELECTRICAL&PLUMBING/KM-250BWF

• 115V/60/1

• 1/2” ODcopper or equivalent independent potable water supply

• 3/4” FPT independent drain connection

• 1/2” FPT Water inlet

SE R I C E

• Panels easily removed and all components

accessible for service.

• Removable/cleanable air filters

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com Printed in U.S.A.

KM-250BWF

25 x 28 x 39*

*with adj. 6” legs

WATER-COOLED

70˚

50˚ 70˚

233

90˚

80˚

90˚

Air Temp˚ F.

Water Temp˚ F.

227

225

215

212

200

192

207

9.9 39.5

3.98 200 136

SIDE VIEW

REAR VIEW

FRONT VIEW

• Water-cooled
