Hostess IM01A Manuale utente

Ice Maker

Instruction Manual

Model: IM01A

- 2 -

1. Important Safety Instructions

Please read these instructions thoroughly before using this product and retain them for

future use.

WARNING: This appliance must be earthed.

-This Ice Maker is intended for household use only.

-If the power cord is damaged a replacement must be obtained from the manufacturer.

-Hold the plug firmly when removing it; do not pull the power cord.

-Do not place the appliance near an open flame, cooking or heating appliance, or hot

surface.

-For indoor use only.

-To avoid electric shock do not open the casing. There are no user serviceable parts

inside.

-Switch off the power and remove the plug when cleaning the appliance and when the

appliance is not in use.

-Do not operate the appliance if it has been damaged in any way.

-This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

-Children should be supervised to ensure that they do not play with the appliance.

-The appliance must not be transported at an inclined angle greater than 45°.

-Do not turn the Ice Maker upside down; as this could cause the compressor or

refrigerating system to malfunction.

-A clearance of 150mm should be provided around the appliance to allow air to circulate.

-Thoroughly clean the Water Tank and Ice Container before and after use.

-Change the water regularly to ensure the quality of the ice cubes.

-NOTE: Only use still, potable water in the Ice Maker.

-Do not fill the Water Tank above the ‘Full’ level mark.

-If the power is switched off whilst the appliance is operating, please wait 3 minutes before

switching the power back on again.

-Before storing the Ice Maker, drain out the water and dry out the Water Tank and Ice

Container.

-The appliance contains flammable insulation foam and refrigeration gases, please

dispose of the appliance properly, inline with local recycling regulations.

NOTE: Please clean the inside of the ice maker thoroughly before use. (See Section 3)

NOTE: The first batches of ice cubes produced may not be full size. A batch of 10 full sized

ice cubes will be produced after approximately 25 minutes. Subsequent batches of ice

cubes will be produced every 7-10 minutes, depending on the ice size selected.

NOTE: Before using the Ice Maker for the first time, please stand it upright for approximately

2 hours to allow the cooling system to stabilise, following transportation.

- 3 -

2. Operation

a) Ice Making Cycle

The ice making cycle has 5 steps:

1. Pumping water from the water tank up to the water tray.

2. Operating the refrigeration system to create the ice cubes.

3. Emptying the excess water from the water tray.

4. Releasing the ice cubes into the ice container.

5. Returning the water tray to its upright position.

This cycle continues until the ice container is full of ice cubes or there is insufficient water in

the water tank.

b) Control Panel

‘START’ and ‘STOP’ buttons:

When the power is connected, the unit will go into standby mode. (One of the ice size

indicators will be flashing). When the ‘START’ button is pressed the selected ice size

indicator will remain on and the ice making cycle begins. When the ‘STOP’ button is pressed

the ice making cycle will stop. The water tray will empty the water back into the water tank

and any ice cubes will be released into the ice container, before the unit goes back into

standby mode.

‘ICE SIZE’ button:

Press this button to select the required size of ice cubes. (The default size is small) The ice

size indicator will cycle between small-medium-large and back to small, each time the button

is pressed.

Note: If the Ice Maker is operated in a cool ambient, it is recommended that ‘Small’ ice

cubes are selected.

Large Size Indicator (green): When this light is on, it indicates that the unit is making

large ice cubes and the cycle time will be the longest.

Medium Size Indicator (green): When this light is on, it indicates that the unit is

making medium size ice cubes.

Small Size Indicator (green): When this light is on, it indicates that the unit is making

small ice cubes and the cycle time will be the shortest.

- 4 -

Ice Full Indicator (red): When the Ice Container is full of ice cubes, the indicator will

turn red. The ice making cycle will stop after the next batch of ice cubes have been released

into the container. The unit will then go into standby mode. Remove the ice cubes before

pressing the 'STOP' and then 'START' buttons to restart the ice making cycle.

Low Water Indicator (red): The Ice Maker will automatically check the water level in

the Water Tank. If the water level is too low, the red light will come on and the ice making

cycle will stop. When water is added to the Water Tank, the ‘Low Water Indicator’ will go off

and the unit will automatically restart.

c) Moving the Unit

When unpacking or moving the Ice Maker, please note that the unit should not be tilted over

45°. Keep the appliance upright at all times. There are ‘handles’ at the rear edges of the

casing which should be used when moving the Ice Maker. (See picture C)

ABC

d) Locating the Unit

Position the Ice Maker on a sturdy flat surface so that there is a clearance of 150mm all

around. (See picture below)

≥

150mm

≥150mm

- 5 -

e) Electrical Connection

Connect the supply cord to the socket at the rear of the Ice Maker. Insert the 3-pin plug into

a 13A socket. Ensure that the supply is 220-240V 50Hz. Switch off the supply and remove

the plug when cleaning the appliance or the appliance is not in use. (See picture below)

WARNING: This appliance must be earthed.

f) Drip Tray

Position the Drip Tray provided under the front edge of the appliance. This will then collect

any drops of water that may run down the front of the appliance when the Ice Container is

pulled out.

g) Removing the Ice Cubes

Slide the Ice Container forwards and use the Ice Scoop provided to remove the ice cubes.

Push the Ice Container back fully into position when the ice cubes have been removed. (See

picture below)

- 6 -

h) Adding Water

Slide the Ice Container fully forwards and then tilt it up slightly to remove it from the unit. Use

the jug provided to pour potable water into the Water Tank. Note: Do not overfill the Water

Tank above the ‘Full’ level. (See picture below). Return the Ice Container into its fully

inserted position.

FULL

i) Draining the Unit

The drain point is located underneath the unit, at the left hand side. Carefully position the

unit over a sink/drain and unscrew the plastic cap. Remove the rubber bung and allow the

Water Tank to empty. Slightly tilt the unit to the left hand side to ensure that all the water is

removed. Replace the rubber bung and the plastic cap. (See picture below).

Note: The unit should be drained if it will not be used for some time and before the unit is

stored.

- 7 -

3. Cleaning and Maintenance

Note: Please clean the Ice Maker regularly.

-Before cleaning the unit, switch off the power and remove the plug. Remove any ice

cubes from the Ice Container and drain all the water from the Water Tank.

-Use a dilute mild detergent in water to clean the inside and outside of the Ice Maker with a

soft cloth. Rinse and dry thoroughly. Do not spray any liquids onto the appliance.

-Do not use any acidic or abrasive detergents.

-When cleaning the inside of the appliance, take care not to damage the sensing probes.

-If the Ice Maker will not be used for some time, please remove any ice cubes, drain the

water from the Water Tank and thoroughly clean and dry the inside of the appliance.

4. Technical Specification

Model IM01A

Climate Type N

Ice Making Capacity 12kg/24h

Ice Storage 700g

Water Tank Capacity 1.5L

Rated Voltage / Frequency 220-240V / 50Hz

Rated Current 0.9A

Input Power 140W

Shock Protection Class I

Refrigerant R134a/52g

Insulation Layer EPS

Dimensions 332(h) x 260(w) x 335(d) mm

Net Weight 10kg

5. Environmental Note

This symbol on the product indicates that it must not be discarded as general

household waste. Instead it should be handed over to the applicable collection

point for the recycling of electrical and electronic equipment. Disposal must be

carried out in accordance with local environmental regulations for waste

disposal.

- 8 -

6. Trouble Shooting

Problem Possible Cause Possible Solution

The compressor

makes a strange noise

Too low voltage

Turn off the Ice Maker.

Ensure the voltage is normal and

restart.

Room temperature is

too low

Remove the Ice Container. Wait

several minutes before replacing the

container and then restart the

machine.

Ice blocking trouble Please clean the Ice Container and

restart the unit. If the Ice Full

Indicator fails to go off then the unit

will need to be replaced.

Ice Full Indicator is on

but there is no ice in

the Ice Container

The sensor is broken Please contact Customer Service

The sensor is broken Please contact Customer ServiceLow Water Indicator is

on but Water Tank is

full of water Water conductivity is

low

Add a small amount of salt to the

water

Water conductivity is

low

Drain the unit and clean the Water

Tank; especially the screw heads at

the rear of the Tank, as these detect

the water level. Add water and

restart the appliance.

Whether there is no

water or just a little

water in the Water

Tank, but the Low

Water Indicator

remains off. The sensor is broken Please contact Customer Service

Unit is not plugged in

properly

Check that the unit is properly

plugged in and the supply switched

on.

Ice Size Indicator is off

when the unit is

powered up. The fuse on the PCB

has blown.

Please contact Customer Service

7. Customer Service

If you encounter any problems with your Hostess Ice Maker, please contact the appropriate

Service Department. If the Ice Maker was bought in the UK, please contact:

Hostess Customer Service Department,

Crosslee plc,

Halifax,

West Yorkshire,

United Kingdom HX3 8DE

Telephone: 01422 203963

If the Ice Maker was bought outside the UK, please contact your retailer.

4213 194 09101
