Hotpoint HLD4000 Series Manuale utente

Panel

Thickness

Kit A B C

GPF525 25-1/4" 23-1/2" N/A 1/4"

GPF575 25-1/2" 23-5/8" 1/4" 3/4"

• The rough cabinet opening must be at least 24" deep,

24" wide and approximately 34-1/2" high from floor to

underside of the countertop.

5" 5"

Figure A

Floor MUST be Even

With Room Floor

Cabinets

Square

and

Plumb

This Wall Area

must be Free

of Pipes or

wires

24"

Min.

24"

Min.

34-1/2"1/4"

Underside of

Countertop

to Floor

Plumbing and Electric Service

Must Enter Inside This Area

MAX.

20-1/2

4 (Adjustable)

33-3/4" MIN.

adj. to 35"

27-1/2

See Detail E for 3/4" Panel Detail E for 3/4 panel only

Door insert ABack ViewFront View

1-7/8 1-7/8

Section E-F

3/8

3/4

See Detail E for 3/4" Panel Detail E for 3/4 panel only

Door insert ABack ViewFront View

1-7/8 1-7/8

Section E-F

3/8

3/4

Electrical Rating

Voltage AC............................................... 120

Hertz........................................................ 60

Total connected load amperage............. 10

Calrod®heater watts max................... 875

For use on adequately wired 120-volt, 15-amp circuit

having 2-wire service with a separate ground wire.

This appliance must be grounded for safe operation.

Note: The rough cabinet opening must be at least

24" deep, 24" wide and approximately 34-1/2"

high from floor to underside of the countertop.

Dishwasher must not be installed more than 10

feet from sink for proper drainage. All plumbing

and electrical work must be in accordance with

local codes. The power cord and connections must

comply with the National Electrical Code Section

422 and/or local codes and ordinances. The cord

must be no longer than 6 ft. from the junction box to

the receptacle.

Installation Information: Before installing, consult

installation instructions packed with product for

current dimensional data.

Dishwasher Dimensions (in inches)

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Listed by

Underwriters

Laboratories

HLD4000/40N – Hotpoint Built-In Dishwasher

Specification Created 9/06

450151

Features and Benefits

• Full-Length Flat Door - Blends almost seamlessly with adjacent cabinetry

• Electronic Controls with 4 Cycles/4 Options - Make it easy to select a wide

range of wash cycles

• Giant Tub with Deluxe Capacity Racking - Washes up to 14 place settings at once

• 4-Level BrilliantClean™Towerless Wash System - Reduces water and energy

needs, with four wash levels and two wash arms that quietly direct water onto

dishes for a powerful clean

• 100% Triple Water Filtration - Water stays clean, so just-washed dishes do, too

• 2/4-Hour Delay Start - Makes it easier than ever to wash dishes at any hour taking

advantage of reduced energy rates or washing dishes even when the family's asleep

• Deluxe Silverware Basket - Provides convenient space and capacity to clean silverware

efficiently and effectively

• Squeeze Latch - Opens and closes the door with a light touch

• Model HLD4000NWW – White on white

• Model HLD4000NBB – Black on black

• Model HLD4040N – Silver metallic

HLD4000NWW/BB

HLD4000/40N – Hotpoint Built-In Dishwasher

Specification Created 9/06

450151
