RGB533WEH/CEH/BEK – Hotpoint 30" Free-Standing Gas Range

All Hotpoint ranges are equipped

with an Anti-Tip device. The

installation of this device is an

important, required step in the

installation of the range.

Installation Information: Before

installation, consult installation

instructions packed with product

for current dimensional data.

Optional gas range

accessory drip pans:

(Available at additional cost)

To order these accessory drip pans,

call toll-free 800-626-2002.

* Depth from wall to front of

closed oven door

Dimensions (in inches) 30" Gas Range Installation Information (in inches)

Specification Revised 7/05

430189

46-1/2

26-1/4*

46-3/8

36±1/4

L2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Recommended common area

for gas outlet and electrical

outlet for GE free-standing gas

range models

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

CERTIFIED

RGB533WEH/CEH/BEK – Hotpoint 30" Free-Standing Gas Range

Features and Benefits

• Extra-Large Oven Capacity – Provides a large oven interior ideal for cooking more items

at once.

• Sealed Cooktop Burners – Eliminate the space between the burners and the cooktop to help

contain spills and boil over liquids, ensuring easy cleanup.

• Performance Plus Burner – Provides a maximum output of 12,000 BTUs for fast heat-up

and boiling.

• Simmer Burner – Provides low, even heat distribution for delicate foods and sauces.

• All Purpose Burners – Deliver a wide range of heat output ideal for most cooking requirements.

• Electronic Clock and Timer – Features a convenient digital clock and easy-to-use timer with an

audible signal to help coordinate cooking times in the kitchen.

• Standard Grates – Provide a sturdy and convenient cookware surface for everyday cooking.

• Model RGB533WEHWW – White on white

• Model RGB533CEHCC – Bisque on bisque

• Model RGB533BEKBB – Black on black

Specification Revised 7/05

430189

RGB533WEH/CEH
