Washing Machine Programme Guide

7kg

Ultima

Wash Labels Explained

The number inside the wash tub shows the maximum water temperature,

in ˚C.

If there are no bars, the garment can be spun and rinsed as normal.

One bar indicates a reduced spin speed programme should be used.

Two bars mean the clothes need a mild wash action, but can be spun and

rinsed normally. Such items should not be wrung out by hand.

If the tub contains a hand, wash the item on a Hand Wash programme.

A triangle means that you can safely use a cold, dilute solution of bleach.

A triangle with a cross over it means the item cannot be bleached.

A circle inside a square means you can tumble dry the garment.

The dots indicate temperature

- one dot for lower heat.

- two dots for higher heat.

A cross over this symbol shows you should not tumble dry the garment.

A circle means the garment is suitable for dry-cleaning.

A letter inside the circle is to tell the dry-cleaner which chemical wash and

method to use.

Contents

Wash Labels Explained, 2

Washing Machine Description, 4

Ultima

Programmes and Option Modifiers, 5-11

Special features

Option modifiers

Programme table

Starting a wash programme

A typical wash load

Automatic features

Troubleshooting, 12-13

Problems and solutions

Safety Advice, 14

Disposal of old electrical appliances

Technical Details, 15

Service, 16

Before calling for assistance

Spare parts

Key Contacts

Wash Labels

Explained Contents Description Programmes and

Option Modifiers Troubleshooting Safety

Advice Technical

Details Service

WASHING MACHINE

Washing Machine

Description

Ultima

Ultima control panel features

●Option buttons: To select the options available (see Programme Table and Option Modifiers).

●LCD display: Shows all information relating to your programme selections: wash temperature and spin speed,

chosen options, along with time remaining. It will also indicate if the door is locked (when ‘keyhole’ symbol lit,

the door cannot be opened) and the stage of the programme the machine has reached (wash, rinse or spin).

●ON/OFF Pause button: To turn the washing machine on and off. If pressed when the machine is running the

programme will be paused, press again and the machine will restart.

●ON/OFF light: Shows that the machine is in use or is on ready for you to select a programme.

●START/CANCEL button: To start the selected programme - or to cancel a running programme, if incorrect

settings were selected.

●Programme selector buttons: To select the programme you require. Press the button the required number of

times to select the programme you want (For more information please see ‘Starting a wash programme’

section, Programmes and Option Modifiers).

Detergent dispenser

drawer

Status indicator

lights

START/CANCEL

button

Option

buttons

LCD display

Programme selector

buttons

ON/OFF Pause

button

On/Off

light

Wash Labels

Explained Contents Description Programmes and

Option Modifiers Troubleshooting Safety

Advice Technical

Details Service

Programmes and

Option Modifiers

Special features

●Fast Wash:

The Fast Wash programmes are designed for lightly soiled loads delivering quick results for smaller loads,

using less energy. For loads with stains or increased soil levels which require deeper cleaning, use the standard

or intensive wash cycles.

●Cool Wash: 30˚C

A low temperature wash which delivers cleaning results comparable to the intensive 40˚C cotton programme

but at a lower temperature for more colour sensitive garments and using less energy.

●Handwash:

A gentle action programme for delicate items and items labelled as hand wash only.

Not for Wool or Silk garments (use the special programmes for those materials).

●Handwash Wool Approved:

The wool wash cycle on Hotpoint machines has been tested and approved by the Woolmark company for

washing garments labelled as ‘hand wash’, provided that the ‘garments’ are washed in accordance to the

instructions issued by the manufacturer of this machine.

This cycle is selected by pressing the wool programme selector button and selecting the ‘Wash Enhance’

option modifier (see Programme Table and Option Modifiers).

We recommend using a wool wash liquid when using Wool programmes.

●Super Silent Wash:

Using the latest brush-less electric motors and damper technology the noise levels during the washing phase

are significantly lower than a conventional washing machine.

●LCD Display

Shows all information relating to your programme selections. Also indicating the stage of a programme in

progress.

If time delay is selected this shows the time remaining until the start of the wash programme in hours – counting

down each hour.

It also displays which option modifiers have been selected, the door lock status and the time to end of the

wash programme in hours and minutes, counting down each minute. Please note time can go up as well as

down depending on load absorbency, size and water temperature.

Did you know?…

●… when an option button is selected the corresponding indicator is illuminated on the LCD display.

●… if the option selected is incompatible with the programme selected, the option indicator will flash

and the option will not be enabled.

●… if you set an option that is incompatible with an option selected previously, only the last option

selected will be enabled

Programmes and

Option Modifiers

Option modifiers

Selecting options and their function

●Wash Enhance:

Use this option to select a more intensive wash programme for the cotton 60˚C and cotton 40˚C for more heavily

soiled items. Additionally, use this option on the machine wash wool programme to select the special Handwash

wool programme for wool items that are not marked as machine washable. This cycle has been approved by

Woolmark for the Platinum Care award.

●Reduced Creases:

Selecting this option will run the wash programme with a more gentle action and lower spin speed, in addition to

carrying out an additional rinse to ensure your laundry has fewer creases and will require less ironing.

●Rinse Hold:

Selecting this option will pause the cycle in the final rinse with the fabric conditioner keeping the laundry fresh

until you are ready to complete the programme. The Rinse Hold option light will flash to indicate the cycle is

paused. The machine will stay in this state, tumbling the load occasionally until either the START/CANCEL button

is pressed or the Rinse Hold button is pressed again to continue the cycle.

●Mini Load:

Use this option for smaller loads less than the capacity listed for the material and programme type (see

Programmes Table). This option reduces water consumption and washing time, saving energy when washing

smaller loads.

●Time Delay:

Use this option to delay the programme start by up to 24 hours. The LCD display will show the delay chosen.

Each press of the button increases the Time Delay in increments of 1 hour. If you press the button again after 24

shows in the display the machine will reset the Time Delay and show ‘OFF’ in the display, pressing the button

after this will start the Time Delay selection from 1 hour.

Once the countdown reaches zero the programme will start.

●Variable Temperature:

Use this option to reduce the wash temperature below the maximum for the programme you have chosen.

- Each press of the button will reduce the wash temperature by either 5˚C or 10˚C.

The new wash temperature will be shown in the LCD display.

If you press again after ‘OFF’ has been displayed, the machine will revert to the original higher temperature.

●Variable Spin Speed:

Use this option to reduce the spin speed below the maximum for the programme you have chosen.

- Each press of the button will reduce the spin speed. The new spin speed will be shown in the LCD display.

If you press again after ‘OFF’ has been displayed, the machine will revert to the original higher spin

speed.

●Extra Rinse:

Use this option for people with sensitive skin, to add a rinse to your selected wash programme. Press the ‘Rinse’

option button once and ‘Extra Rinse’ will illuminate on the LCD display. Press the ‘Rinse’ button again to cancel.

Wash Labels

Explained Contents Description Programmes and

Option Modifiers Troubleshooting Safety

Advice Technical

Details Service

Programmes and

Option Modifiers

Option modifiers

Selecting options and their function

●Prewash:

Use Prewash to loosen heavy soil deposits on laundry. Selecting this option will run a short 30˚ wash cycle

before the selected main wash programme. Add detergent to both the prewash and main wash compartments

of the dispenser drawer.

To select press the Prewash option button and the option light will illuminate on the LCD display above the

button.

Press the button for again to cancel, the option light will go out.

●How Dirty:

Use this option to modify your programme according to the degree of soiling on the laundry to be washed.

You can select either ‘Light’, ‘Normal’ or ‘Super’.

This option is set automatically to ‘Normal’, this will be illuminated on the LCD display.

- Each press of the ‘How Dirty’ option button will scroll through the three options. The new selection will be

shown on the display.

●Stored Programme:

Use this option to store your favourite programme. Only one programme can be stored.

- To store a programme:

Load your machine and add detergent to the dispenser drawer. Select the programme and any

options required. Press the START/CANCEL button and the programme will start. Then press the

‘Stored’ option button twice and that programme will be stored for future use. ‘Saving Favourite’ will

illuminate on the LCD display for 2 seconds after the programme settings have been stored.

- To retrieve and use a stored programme:

Load your machine and add detergent to the dispenser drawer. Press the ‘Stored’ option button, your

favourite programme settings will appear on the LCD display. Press the START/CANCEL button to start

the programme.

- To change a stored programme:

Load your machine and add detergent to the dispenser drawer. Press the ‘Stored’ option button, your

favourite programme settings appear on the LCD display. Select the programme and option selections

for you new requirements, then press the START/CANCEL button to start the programme. Press the

‘Stored’ option button again and the new settings will replace the old. ‘Saving Favourite will illuminate

on the LCD display for 2 seconds after the programme settings have been stored.

●Child Lock:

Select this option to disable all buttons so no programme and option selections can be altered.

Press the Child Lock option button and the option light will illuminate on the LCD display above the button.

Once Child Lock is selected it remains activated even when the machine is switched off. If power is interrupted

at any time pressing any button will reactivate the Child Lock feature. If Child Lock is activated and any

control buttons are pressed the option light will flash: no alterations to the settings will be allowed.

Press and hold the Child Lock option button for 2 seconds to cancel, the option light will go out.

Programmes and

Option Modifiers

Label Programme Programme Type / Fabric Description Temp Max

Selector (˚C) Load

Button (kg)

AP THREE Hygienic For hard wearing heat resistant cotton and linen. 95 7

TIMES White Cotton

B60 Superwash An intensive cleaning programme for heavily soiled 60 6

ONCE Colourfast Cotton hard wearing fabrics.

D60 Everyday For everyday cleaning needs for colourfast cotton 60 6

TWICE Colourfast Cotton or linen fabrics.

D60 TWICE Standard An intensive cleaning, energy efficient cycle using 60 7

Colourfast Cotton (IEC 60456*) the maximum load capacity.

E60 Fast Wash A fast cycle for lightly soiled heat resistant cotton 60 5

ONCE Colourfast Cotton & linen fabrics.

F40 Everyday For the everyday cleaning needs of cottons and other 40 6

ONCE Non Colourfast Cotton hard wearing fabrics.

F40 Intensive A less energy efficient intensive 40˚C cycle for more 40 7

ONCE Non Colourfast Cotton stubborn soiling.

G40 - Man-made fibres A cycle designed to wash a variety of man-made fibres 40 3.5

ONCE Coloured Synthetics & Acrylics and fibre mixtures.

H30 Cool Wash Delivers the same performance as the intensive 40˚C 30 5

TWICE Non Colourfast Cotton cycle but is more energy efficient at the expense of duration.

J40 - - Machine Washable For machine washable wool and wool mixtures. 40 3

ONCE Wool

J40 - - Platinum Woolmark Approved A special cycle for Hand Wash wool that will not shrink 40 1

ONCE Handwash Wool your garments exclusively approved by Woolmark.

K30 - Machine Washable For silk garments labelled as machine washable. 30 3

ONCE Silk

L30 Fast Wash A very short refresh programme for lightly soiled mixed 30 3

TWICE Mixed (not Wool/Silk/Handwash) fabrics.

MHHandwash A gentle cycle for delicate items labelled as Hand Wash 25 4

TWICE Delicates (not Wool/Silk) only.

R&S -Fast Rinse & Spin This partial programme completes two full rinses and then - 7

ONCE Cotton a fast spin.

R&S -Slow Rinse & Spin This partial programme completes two full rinses and then - 3.5

TWICE Mixed a slow spin.

FS - THREE Fast Spin This partial programme completes the maximum speed - 7

TIMES Cotton final spin.

SS - FOUR Slow Spin This partial programme completes the intermediate speed - 3.5

TIMES Delicates final spin.

Press START/CANCEL Pump Out This draining programme ensures the appliance is emptied - 7

button All of water.

Programme Table *Programme setting for test in accordance with IEC 60456 and EN 60456

Wash Labels

Explained Contents Description Programmes and

Option Modifiers Troubleshooting Safety

Advice Technical

Details Service

Max Approximate Required Soil Level Spin Available Recommended

Load Programme Additional Speed Options Detergent

(kg) Time (h : min) Option

7 2 : 30 - Normal Max Pre Wash, Rinse Hold, Mini Load, Ariel Bio Powder /

Extra Rinse, Time Delay, How Dirty Tablets

6 2 : 20 - Heavy Max Reduce Creases, Rinse Hold, Mini Load Ariel Colour

Extra Rinse, Time Delay, How Dirty

6 1 : 30 - Light to Max Pre Wash, Wash Enhance, Reduce Creases, Ariel Colour

Normal Rinse Hold, Mini Load, Extra Rinse, Time

Delay, How Dirty

7 2 : 00 Wash Normal to Max Time Delay Ariel Colour

Enhance Heavy

5 1 : 00 - Light Max Rinse Hold, Extra Rinse, Time Delay Ariel Colour

6 1 : 15 - Light to Max Pre Wash, Wash Enhance, Reduce Creases, Ariel Colour

Normal Rinse Hold, Mini Load, Extra Rinse, Time

Delay, How Dirty

7 1 : 45 Wash Heavy Max Time Delay Ariel Colour

Enhance

3.5 1 : 15 - Normal 800 Pre Wash, Reduce Creases, Rinse Hold, Ariel Colour

Mini Load, Extra Rinse, Time Delay,

How Dirty

5 1 : 50 - Normal to Max Pre Wash, Rinse Hold, Mini Load, Ariel Colour Liquid

Heavy Extra Rinse, Time Delay

3 1 : 00 - Normal 850 Wash Enhance, Time Delay Dreft

1 0 : 50 Wash Normal 600 Time Delay Dreft

Enhance

3 0 : 55 - Normal 800 Pre Wash, Rinse Hold, Time Delay Dreft

3 0 : 30 - Light 800 Time Delay Ariel Colour Liquid

4 0 : 50 - Normal 400 Rinse Hold, Time Delay Ariel Colour Liquid

7 0 : 30 - - Max Reduce Creases, Rinse Hold, Mini Load -

Extra Rinse, Time Delay

3.5 0 : 30 - - 800 Reduce Creases, Rinse Hold, Mini Load, -

Extra Rinse, Time Delay

7 0 : 15 - - Max Time Delay -

3.5 0 : 12 - - 800 Time Delay -

70:02- - - - -

GB Starting a wash programme

Operating the machine

●On-Off / Selecting a programme:

1. Switch the machine on by pressing the ON/OFF Pause button.

2. Load your laundry into the machine and shut the door.

3. Add the detergent and any fabric softener.

4. Select the programme you require:

- Press the button the required number of times (see Programme Table).

- The display will change on each press to show the temperature of the selected programme.

5. Select any options you require (see Option Modifiers).

6. Press the START/CANCEL button to start the programme.

●To stop or change a programme:

1. Press the START/CANCEL button.

2. The machine will start to empty.

3. When the machine has finished the ‘pump out’ programme you can select the new programme required.

- You may need to add detergent.

4. Press the START/CANCEL button to start the new programme.

A typical wash load

Did you know that with Hotpoint and Ariel you’ll get the best washing results?

Certain laundry products work better in some machines than others. At Hotpoint we know this is

true because we’ve done the research to prove it.

We used real everyday clothes and ran tests to find out which washing powder works best with

Hotpoint. The results proved that Hotpoint and Ariel produces the best washing results on all your

clothes.

Ariel can meet all your laundry needs. It’s available as a biological powder for everyday wash

loads. Colour powder to keep your clothes staying brighter for longer and a Non-Bio powder for

when you need brilliant cleaning but are concerned about sensitive skin.

Programmes and

Option Modifiers

Two examples of maximum wash loads for different types of fabric:

2 Bath Towels

1 Hand Towel

6 Shirts

6 Blouses

2 Sets of Pyjamas

12 Items of

Underwear

2 T-Shirts

C TT N

= 7kg

4 Items of

Sports wear

4 Shirts

4 Blouses

1 Set of Pyjamas

8 Items of

Underwear

SYNTHETIC

= 3.5kg

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Hotpoint Rondella

Hotpoint

Hotpoint Aqualtis AQ73F 49 E Manuale utente

Hotpoint

Hotpoint WMJLD 943 Manuale utente

Hotpoint

Hotpoint hvl 211 Manuale utente

Hotpoint

Hotpoint WML 730 K Manuale utente

Hotpoint

Hotpoint AQ113D 697 E Manuale utente

Hotpoint

Hotpoint WMYL 8552 Manuale utente

Hotpoint

Hotpoint RZ 1066 W Manuale utente

Hotpoint

Hotpoint Experience WMEF 963 Manuale utente

Hotpoint

Hotpoint AWM 1081 Manuale utente

Hotpoint

Hotpoint WMBF 742 Guida alla risoluzione dei problemi

Hotpoint

Hotpoint WLW3000B Istruzioni per l'installazione

Hotpoint

Hotpoint Aqualtis AQ113L 297E Manuale utente

Hotpoint

Hotpoint HY6F 1551 Manuale utente

Hotpoint

Hotpoint WM51 Manuale utente

Hotpoint

Hotpoint WLW3500B Istruzioni per l'installazione

Hotpoint

Hotpoint ultima digit wt640 Manuale utente

Hotpoint

Hotpoint WMF540A Manuale utente

Hotpoint

Hotpoint WMA5 Manuale utente

Hotpoint

Hotpoint FEW10 Manuale utente

Hotpoint

Hotpoint WML 560 P/G/A/K Manuale utente

Hotpoint

Hotpoint ARXXL 129 Manuale utente

Hotpoint

Hotpoint ARTXD 129 Guida alla risoluzione dei problemi

Hotpoint

Hotpoint AQUALTIS AQ8D 492 U Manuale utente

Hotpoint

Hotpoint WLW3505A Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
