TABLE OF CONTENTS

Symbol Reference ..........................................................2

Intended Use and Precautions........................................3

Part Identiﬁcation - HoverMatt® PROS Sling....................4

Product Speciﬁcations/Required Accessories..................4

Instructions for Use .....................................................5-8

Cleaning and Preventive Maintenance ...........................9

Returns and Repairs......................................................10

User Manual

Visit www.HoverMatt.com for other languages

Patient Repositioning O-Loading System

PROS™ Sling User Manual

2| HoverTech International HMPROSSlingManual, Rev. A

Symbol Reference

CE MARKING OF CONFORMITY

UK MARKING OF CONFORMITY

AUTHORIZED REPRESENTATIVE

UK RESPONSIBLE PERSON

SWITZERLAND AUTHORIZED

REPRESENTATIVE

CAUTION / WARNING

ATTACH CONNECTING STRAP

DISPOSAL

FOOT END

IMPORTER

OPERATING INSTRUCTIONS

LATEX FREE

LOOP STYLE HANGER BAR

LOT NUMBER

MANUFACTURER

DATE OF MANUFACTURE

MEDICAL DEVICE

MODEL NUMBER

SINGLE PATIENT  MULTIPLE USE

DO NOT LAUNDER

UNIQUE DEVICE IDENTIFIER

PATIENT WEIGHT LIMIT

HMPROSSlingManual, Rev. A www.HoverMatt.com | 3

PROS™ Sling User Manual

Intended Use and Precautions

INTENDED USE

• The HoverMatt PROS (Patient Repositioning O-Loading System)

Sling is used to assist caregivers with patient positioning (including

boosting and turning), vertical lifts, lateral transfers, and proning.

By providing pressure relief of bony prominences to aide with Q2

compliance, reducing shear and friction when repositioning, and

enhancing microclimate management, the system provides a solution

to safely turn and reposition patients while reducing caregiver strain.

INDICATIONS

• Patients unable to assist in their own repositioning (including turning

and boosting) and lateral transfer.

• Patients that need Q2 turning for o-loading pressure.

• Patients that need to be placed in prone position.

CONTRAINDICATIONS

• Do not use with patients over the weight limit of 550 lbs without use

of a ceiling or ﬂoor lift.

• Do not use with patients over the weight limit of 1000 lbs with a

ceiling or ﬂoor lift (or the weight capacity of the lift – whichever is

the lower weight limit).

• Do not us as a sling with patients who are experiencing thoracic,

cervical or lumbar fractures that are deemed unstable unless a clinical

decision has been made by your facility.

INTENDED CARE SETTINGS

• Hospitals, long term or extended care facilities

PRECAUTIONS  FOR USE AS A SLIDE SHEET

• Caregivers must verify that all brakes have been engaged prior to

transfer.

• Use a minimum of two caregivers during lateral patient transfers.

• For in-bed positioning tasks, more than one caregiver may need to

be used.

• Use this product only for its intended purpose as described in this

manual.

• When transferring or positioning on a low air loss mattress, set the

bed mattress air ﬂow to the highest level for a ﬁrm surface.

• Additional support products may be necessary between surfaces

when transferring.

• PRECAUTIONS – FOR USE AS A SLING

• For transfers more than one caregiver may need to be used.

• For in-bed positioning tasks, more than one caregiver may need to

be used.

• For proning, see HoverTech’s training video @ www.HoverMatt.com.

• The PROS Sling should only be used by trained personnel.

• Only use accessories that are authorized by HoverTech International.

• A clinical assessment should be carried out before lifting patients

with the PROS Sling.

• Make sure the PROS Sling is not attached to any object other than the

loop style hanger bar.

• When connecting to loop style hanger bar, ensure strap loop colors

match on the patient’s left and right side.

• Once the sling support straps are fully extended, make sure they are

properly connected to the hanger bar before the patient is lifted.

• Never lift a patient higher than is necessary to complete the lift/

transfer.

• Never leave the patient unattended while using the PROS Sling to lift

the patient.

• Use the PROS Sling according to both the lift and PROS Sling

instructions.

• If the weight limit diers among the patient lift, hanger bar, and

PROS Sling, then the lowest weight limit applies.

If there is any indication of damage, remove the PROS Sling

from service and discard.

Side rails must be raised with one caregiver.

For use with loop style hanger bar only.

In the OR – To prevent patient from slipping, always deﬂate the

HoverMatt and secure the patient and HoverMatt to the OR table

prior to moving the table into an angled position.

PROS™ Sling User Manual

4| HoverTech International HMPROSSlingManual, Rev. A

Part Identiﬁcation – PROS Sling

PROS Sling

Material: Nylon Twill

Construction: Sewn

Width: 43.5" (110.49 cm)

Length: 78" (198 cm)

Model #: PROS-SL-KIT (Non-Air Sling + HoverCover + pair of wedges) 3 per case*

Model #: PROS-SL-CS (Non-Air Sling + HoverCover) 5 per case

LIMIT 550 LBS/ 250 KG (Slide Sheet)

1000 LBS/ 454 KG (Sling)

*Wedge Pair Includes: 1 Wedge with Tail & 1 without Tail, Compressed

REQUIRED ACCESSORY FOR USE AS A SLING:

Any patient lift with 2, 3, or 4-point loop style hanger bars intended for

use with:

• Mobile hoists

• Hoist trolleys

• Stationary hoists ﬁxed to the wall/walls, ﬂoor and/or ceiling

• Stationary free-standing hoists

Product Speciﬁcations/Required Accessories

Link Velcro Hook (4)

Link Velcro Loop (4)

Link Velcro Hook (4)

Link Velcro oop (4)

HoverCover Holding Patch

Handles (under sides)

Sling Support Straps (8)

(green, white, beige &

blue color coded straps

for easy identiﬁcation)

HMPROSSlingManual, Rev. A www.HoverMatt.com | 5

PROS™ Sling User Manual

Instructions for Use – PROS Sling

PLACING PRODUCT UNDER PATIENT – LOG ROLLING TECHNIQUE

1. Open the product and place length-wise next to the patient.

2. Unfold the PROS Sling furthest from the patient to the side of the bed.

3. Tuck the other side under the patient as far as possible.

4. Roll the patient onto their side toward the unfolded sling. Unroll the

rest of the sling from under the patient to cover the bed.

5. Place the patient back in a supine position. Straighten sling to

remove any wrinkles.

ATTACHING TO BEDFRAME

1. Loosely attach Velcro hook to Velcro loop around solid points on the

bedframe (or to the headboard or siderails as your facility protocols

or bed type allow) to reduce sling migration.

2. Repeat the process on the other three corners of the sling.

3. Before boosting, turning, proning, lifts and/or transfers, disconnect

sling straps.

Instructions for Use as a Slide Sheet

BOOST/REPOSITION

(To ease boosting eorts, place bed in Trendelenburg prior to boosting.

1. Ensure brakes are locked. More than one caregiver may be needed

for this task. If using one caregiver, raise the siderails.

2. Place PROS Sling underneath patient using a log rolling technique.

Be sure patient is centered on the product prior to movement.

3. Using the handles on the sling, boost/reposition the patient using

proper ergonomic positioning for the caregiver.

Note: To use with a ceiling or ﬂoor lift, see strap suggestion guide on

page 5 for attachment to a loop-style hanger bar.

TURN/WEDGE PLACEMENT

1. Ensure brakes are locked. More than one caregiver may be needed

for this task. If using one caregiver, raise the siderails.

2. Be sure patient is centered on the product prior to movement.

3. Wedge Placement

a. To insert wedges, hold PROS Sling by the handles and place

wedges between the bed and sling.

b. Insert the tail of the wedge under the patient’s thighs. Ensure

the back part of the wedge is elevated until the position is set,

then lower the wedge down to secure in place with the

HoldFast™ foam.

c. Place the standard wedge to support the patient’s back about 1

hand’s width away from the tailed wedge. Ensure the back part

of the wedge is elevated until the position is set, then lower the

wedge down to secure in place with the HoldFast foam.

d. Pull the tail through to the other side of the patient to anchor

the wedge.

e. After wedges are placed, make sure the sacrum is not touching

the bed (ﬂoating). If it is touching the bed, reposition wedges to

ensure sacral o-loading.

4. Hygiene Turn, HoverCover™ Replacement, Wedge Placement (non-air turn)

a. With a caregiver on each side of the patient, one caregiver hands

the sling straps to the caregiver who will be completing the turn

b. With good ergonomic posture, the caregiver turning the patient

will begin to pull on the sling straps facilitating the turn. Patient will

start to roll on their side towards the caregiver performing the turn

c. If replacing the HoverCover or performing a hygiene turn, the

opposite caregiver will brace the patient on their side while the

turning caregiver will release the handles and hold onto the

patient’s hip and shoulder to stabilize the patient.

d. While the patient is turned, hygiene can be performed and

HoverCover removed and replaced.

e. Repeat on the other side before placing wedges.

f. Find the patient’s sacrum and place the wedge under the sacrum.

Insert the tail under the patient’s thighs. Ensure the back part of the

wedge is elevated until the position is set, then lower the wedge

down to secure in place with the HoldFast foam.

g. Place the standard wedge to support the patient’s back about 1

hand width away from the tailed wedge. Ensure the back part

of the wedge is elevated until the position is set, then lower the

wedge down to secure in place with the HoldFast foam.

h. Return patient to supine position.

i. Pull the tail through to the other side of the patient to secure the

wedge.

j. After wedges are placed, make sure the sacrum is not touching

the bed (ﬂoating). If it is rouching the bed, reposition wedges to

ensure sacral o-loading.

PROS™ Sling User Manual

6| HoverTech International HMPROSSlingManual, Rev. A

Instructions for Use as a Slide Sheet

TURN/WEDGE PLACEMENT CONTINUED

5. Wedge Placement with a Ceiling or Portable Lift (Single Caregiver)

a. Raise the side rails on the opposite side of the bed the patient

will be turned toward. Ensure the patient is centered and slide

the patient in the opposite direction of the turn using either the

sling to lift or a manual technique. This will allow the patient to be

centered on the bed when repositioned on the wedges.

b. Attach the shoulder and hip loop straps of the sling to the hanger

bar which should be parallel to the bed. Raise the lift to initiate the

turn.

c. Insert the tail of the wedge just under the patient’s thighs. Ensure

the back part of the wedge is elevated until the position is set, then

lower the wedge down to secure in place with the HoldFast™ foam.

d. Place the standard wedge to support the patient’s back about 1

hand’s width away from the tailed wedge. Ensure the back part

of the wedge is elevated until the position is set, then lower the

wedge down to secure in place with the HoldFast foam.

e. After the wedges are placed, lower the patient onto the wedges,

ensure straps are not underneath the PROS Sling.

f. Pull the tail through to the patient’s other side until taught. Check

wedge placement by placing your hand between the wedges,

conﬁrming the sacrum is not touching the bed. If it is, reposition

wedges to ensure sacral o-loading.

PRONE

1. Ensure brakes are locked. Multiple caregivers will be needed for this

task.

2. Be sure patient is centered on the product prior to movement.

3. Slide patient & PROS Sling over to one side of the bed to ensure room

for the turn.

4. Place another HoverCover & PROS Sling on top of the patient. Fold

mat down to shoulder level to keep face exposed.

5. Roll the two slings together toward the patient to tightly cocoon the

patient.

6. With a ﬁrm grasp on the rolled slings, turn the patient onto their side.

Caregivers on opposite sides should exchange hand positions (hands

on top should switch with hands on bottom).

7. Continue with turn after hand positions are switched. Unroll the

slings and remove the top PROS Sling and HoverCover.

8. Position patient per facility protocol.

Note: To use as a sling with a ceiling or ﬂoor lift, see strap suggestion guide

below for attachment to a loop-style hanger bar.

LATERAL TRANSFER

1. Patient should be in a supine position and centered on the PROS

Sling.

2. Ensure that transfer surfaces are as close as possible and lock all

wheels.

3. If possible, transfer from a higher surface to a lower surface. Bridge

the gap between the two surfaces using an extra sheet or blanket.

4. Grab the handles under the sling and slide the patient onto the

receiving surface.

5. Ensure patient is centered on receiving equipment.

6. Raise the bed/stretcher rails.

Note: To use as a sling with a ceiling or ﬂoor lift, see strap suggestion

guide below for attachment to a loop-style hanger bar.

STRAP USAGE

TECHNIQUE Supine Lift Turn Hygiene/Perineal

Care

Prone

(Use supine lift

technique to move

patient closer to side

of bed. Then follow

strap use below on

one side to turn

patient.)

1st Set (Head) Brown You can use - Blue,

Brown, or SKIP SKIP You can use - Blue,

Brown, or SKIP

2nd Set (Shoulder) Blue Blue Blue Blue

3rd Set (Hip) Blue Blue SKIP Blue

4th Set (Foot) Brown

You can use -

Brown, White, or

SKIP

You can use -

Brown, White, or

SKIP

*This is just a guide to using the PROS™ Sling. Please use clinical judgement for patient-speciﬁc needs.

Instructions for Use as a Sling

HMPROSSlingManual, Rev. A www.HoverMatt.com | 7

PROS™ Sling User Manual

INSTRUCTIONS FOR USE  BACK TO BED

1. Position patient above center of bed. Lower

patient on the bed.

2. Detach strap loops from hanger bar.

3. Reattach the sling straps to Velcro to avoid

dangling straps and to reduce boosting

(see chart for attaching to bedframe).

Instructions for Use as a Sling

INSTRUCTIONS FOR USE  PATIENT IN BED

Note: PROS Sling has eight (8) sling support straps that need to be attached.

1. Place the PROS Sling underneath

patient using log rolling technique.

2. Attach all straps to the hanger bar for the

proper safety and comfort of the patient.

[Color coded strap loops provide easy

identiﬁcation to match strap placement

on the left and right side of the patient.]

Lift patient according to lift manufacturer’s

instructions.

PROS™ Sling User Manual

8| HoverTech International HMPROSSlingManual, Rev. A

Instructions for Use as a Sling

INSTRUCTIONS FOR USE  LATERAL TURN/PRONE

1. With patient centered on the PROS Sling,

lower the hanger bar to comfortable

working height.

2. Raise bed rails and attach (see chart for

guidance) straps on opposite side of pa-

tient turn to loops on same side of hanger

bar starting at foot end.

3. As lift is raised, patient will turn towards

the opposite side of the bed the straps are

attached to. Use wedges to keep patient

in position if desired. After the task is

completed, lower hanger bar and remove

sling straps.

INSTRUCTIONS FOR USE  HYGIENE TURN

1. With patient centered on the PROS Sling,

lower the hanger bar to comfortable

working height.

2. Raise bed rails and attach the sling

strap that is closest to patient’s shoulder

to hanger bar.

3. As lift is raised, patient will begin to turn

to the side opposite the connected strap.

Leave sling in place to perform task. Once

task is completed, lower hanger bar and

remove sling strap.

* To prone, continue the turn and

adjust patient/device as necessary after

the task is complete.

HMPROSSlingManual, Rev. A www.HoverMatt.com | 9

PROS™ Sling User Manual

Cleaning and Preventive Maintenance

PROS SLING CLEANING

If soiled, the PROS Sling may be wiped down with disinfectant wipes or a

cleaning solution used by your hospital for medical equipment disinfection.

A 10:1 bleach solution (10 parts water: one part bleach) may also be used.

NOTE: Cleaning with bleach solution may discolor fabric.

To help keep the PROS Sling clean, HoverTech International recommends

the use of the HoverCover™ Disposable Absorbent Cover. Whatever the

patient is lying on to keep the hospital bed clean may also be placed on

top of the PROS Sling.

The Single-Patient Use PROS Sling is not intended to be laundered.

PREVENTIVE MAINTENANCE

Prior to use, a visual inspection should be performed on the

PROS Sling

ensure that there is no visible damage that would render the PROS Sling

unusable. The

PROS Sling

should have all of its sling straps and handles

(reference the manual for all appropriate parts). If any damage is found that

would cause the system not to function as intended, the

PROS Sling

should be removed from use and discarded.

INFECTION CONTROL

The Single-Patient Use PROS Sling eliminates the possibility of

cross-contamination and the need for laundering.

If the PROS Sling is used for an isolation patient, the hospital should employ

the same protocols/procedures it utilizes for the bed mattress and/or for

linens in that patient room.

PROS™ Sling User Manual

10 | HoverTech International HMPROSSlingManual, Rev. A

In case an adverse event in relation to the device,

incidents should be reported to our authorized

representative. Our authorized representative will

forward information to the manufacturer.

CEpartner4U, ESDOORNLAAN 13,

3951DB MAARN, THE NETHERLANDS.

www.cepartner4u.com

Etac Ltd.

Unit 60, Hartlebury Trading Estate,

Hartlebury, Kidderminster,

Worcestershire, DY10 4JB

+44 121 561 2222

Promefa AG

Kasernenstrasse 3A

Hartlebury, Kidderminster,

8184 Bachenbülach, CH

+41 44 872 97 79

Returns and Repairs

All products being returned to HoverTech International (HTI) must have

a Returned Goods Authorization (RGA) number issued by the company.

Please call (800) 471-2776 and ask for a member of the RGA Team who will

issue you an RGA number. Any product returned without an RGA number

will cause a delay in the repair time.

Returned products should be sent to:

HoverTech International

Attn: RGA # ___________

4482 Innovation Way

Allentown, PA 18109

For product warranties, visit our website:

https://hovermatt.com/standard-product-warranty/

HoverTech International

4482 Innovation Way

Allentown, PA 18109

www.HoverMatt.com

Info@HoverMatt.com

These products comply with the standards applicable

for Class 1 products in the Medical Device Regulation

(EU) 2017/745 on medical devices.

For European companies, send returned products to:

Attn: RGA #____________

Kista Science Tower

SE-164 51 Kista, Sweden

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Hovertech Arredamento per interni

Hovertech

Hovertech HOVERMATT PROS Air Manuale utente

Manuali Arredamento per interni popolari di altre marche

Homelegance

Homelegance California 1662PEK-1CK Manuale utente

Osmond Ergonomics

Osmond Ergonomics FLO Manuale utente

OVE

OVE ELOISE 42 Manuale utente

overstock

overstock MF286255 Manuale utente

Sonoma

Sonoma 160-801 Manuale utente

BOLERO

BOLERO Wicker Side Chair CF158 Guida all'installazione

Coaster

Coaster 4799N Manuale utente

Stor-It-All

Stor-It-All WS39MP Manuale di programmazione

Lexicon

Lexicon 194840161868 Manuale utente

Next AMELIA NEW 462947 Manuale utente

Furinno

Furinno 18089 Manuale utente

Munchkin

Munchkin Push to Close MK0001 Manuale utente

impekk

impekk Manual II Manuale utente

Elements

Elements Ember Nightstand CEB700NSE Manuale utente

JWA

JWA CARY 68429 Manuale utente

VIPACK

VIPACK AMORI AMKB9014 Manuale utente

Anthro

Anthro GT03 Series Manuale utente

Rowico

Rowico SANNA Manuale utente
