HP Bt500 Manuale utente

English 1

Welcome to the HP bt500

The HP bt500 Bluetooth USB 2.0 Wireless Printer Adapter

(HP bt500) uses Bluetooth wireless technology to connect

devices without needing a cable. The HP bt500 can be used

with both printers and Windows computers.

When attached to a Bluetooth-enabled printer, the

HP bt500 allows you to print to the printer from Bluetooth

devices, such as camera phones, PDAs, digital cameras, and

Bluetooth-enabled computers (Windows and Mac).

NOTE: Check the documentation for your printer to verify

the devices you can use to print to it.

TIP: Check www.hp.com/go/Bluetooth for valuable

information concerning your HP bt500.

When attached to a Windows computer, the HP bt500 allows

you to link many Bluetooth devices with your computer,

such as digital cameras, camera phones, headsets, printers,

PDAs and PIMs, and network access points.

Get more information

The CD contains a User Guide with

detailed information about conguring

and using your HP bt500, technical

specications, and regulatory

information.

•

English_Opal_Printer-4x6-standal1 1English Opal Printer-4x6-standal1 1 4/30/2007 12:18:55 PM4/30/2007 12:18:55 PM

2 HP Bluetooth USB 2.0 Wireless Adapter

Connect to a printer

Generally, the sending device (camera, PDA, computer, etc.)

sends a signal and discovers the nearby Bluetooth printing

devices and displays their Bluetooth device names. Then, you

simply print or send to that printer name.

Tip: The printer’s default Bluetooth device name can be

found in the printer’s Bluetooth menu or user guide.

For most devices, the default settings will allow you to print

without making any changes. However, a Bluetooth device

may be set to be visible or invisible and may have security

settings established. If you have diculty printing to your

printer, consult the user guide for your printer.

Installation and setup

Follow these instructions to install and set up your HP bt500

with a printer. More detailed setup instructions can be found in

the user guide for your printer.

Locate the host USB port on your printer or all-in-one. It

will usually be located in the front and is shaped like the

USB port on your computer. It may be called a camera or

Pictbridge port.

English_Opal_Printer-4x6-standal2 2English Opal Printer-4x6-standal2 2 4/30/2007 12:19:13 PM4/30/2007 12:19:13 PM

English 3

Remove the cap from the HP bt500 and insert it in the port.

LED behavior

The LED on the HP bt500 provides information about its

current state.

On steady—This is the default state and means the device is

installed and has power.

Rapid blinking—A sending device is “Discovering” the

HP bt500.

Blinking—The HP bt500 is receiving data.

English_Opal_Printer-4x6-standal3 3English Opal Printer-4x6-standal3 3 4/30/2007 12:19:13 PM4/30/2007 12:19:13 PM

4 HP Bluetooth USB 2.0 Wireless Adapter

Connect to a computer

To use your HP bt500 with a computer you must install and

congure the software. If you are familiar with Bluetooth

devices, follow these instructions for initial installation and

conguration. Detailed setup instructions are in the User Guide

on your CD.

Insert the CD.

The installation should start automatically. If it does not,

browse to your CD and double-click setup.exe.

Follow the instructions on the screen.

When you have installed the software, right-click on

the Bluetooth icon in the system tray and congure the

software.

Important: The User Guide on the CD contains detailed

information on installing the software and conguring your

HP bt500 with your computer and many Bluetooth devices.

English_Opal_Printer-4x6-standal4 4English Opal Printer-4x6-standal4 4 4/30/2007 12:19:14 PM4/30/2007 12:19:14 PM

English 5

English_Opal_Printer-4x6-standal5 5English Opal Printer-4x6-standal5 5 4/30/2007 12:19:14 PM4/30/2007 12:19:14 PM

6 HP Bluetooth USB 2.0 Wireless Adapter

English_Opal_Printer-4x6-standal6 6English Opal Printer-4x6-standal6 6 4/30/2007 12:19:14 PM4/30/2007 12:19:14 PM

English 7

English_Opal_Printer-4x6-standal7 7English Opal Printer-4x6-standal7 7 4/30/2007 12:19:14 PM4/30/2007 12:19:14 PM
