IBM Turbo 16/4 Token Ring ISA
Adapter
Installation Guide
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing, performance, or use
of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft
Corporation.
MMXTM is a trademark of Intel Corporation.
Pentium® is a registered trademark of Intel Corporation.
Hewlett-Packard France
Commercial Desktop Computing Division
38053 Grenoble Cedex 9
France
©1999 Hewlett Packard Company
General information to read before installing
General information to read before installing
On all systems: before installing LAN card, go into Bios setup and set PnP OS field to NO.
• This network card failed HP tests on Vectra VEi7 and VEi8.
• Installation on Win 3.11 with Novell server fails on Vectra VLi8.
• How to change LAN card configuration if needed (Advanced users only)
This is a general advisory on how to forcibly modify resources for ISA and PCI network
cards.
ISA cards:
• For ISA network adapters, start the configuration tool provided in driver
kit (See install documentation)
• Under CMOS setup, go to Advanced > PnP/PCI ISA IRQ Resource Exclu-
sion > reserve an IRQ for the adapter.
PCI cards:
• For PCI network adapters, go to CMOS setup > Advanced > PnP/PCI ISA
IRQ Resource Exclusion > reserve the IRQ for Legacy ISA.
• ISA cards can’t use IRQ9
• IRQ 9 is reported as being used by ACPI during POST. This is due to ISA’s
inability to share IRQs.
• Using a different IRQ (e.g. 5, 7, 10, and 11) will work. For this:
1Install the NIC then power up the system.
2Press F2 to go to CMOS setup.
3Set PnP OS to NO and reserve IRQ 5, 7, 10, or 11 (explained in installation
section).
4Save the configuration settings and boot to the applicable OS.
5Follow installation steps.
Sound conflict under Win 95 on VLi8 only
• On VLi8, LAN cards cause an IRQ conflict with the embedded sound de-
vice under Win95.
• To solve the problem: Reserve IRQ 5 and sett PNP OS to no. For this:
General information to read before installing
1Install the NIC then power up the system
2Press F2 to go to CMOS setup.
3Set PNP OS to NO and reserve IRQ 5.
4Save settings and boot to applicable OS.
1 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Microsoft Windows 95 SR2.5
1 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Microsoft Windows 95
SR2.5
Connecting to a
Windows NT 3.51 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• IBM Turbo 16/4 Token Ring ISA adapter and drivers disk version 2.22.
• Driver File: IBMTOK.SYS, version 10.27
• Microsoft Windows 95 SR2.5 media.
• Microsoft Windows NT 3.51 Server system that supports NetBEUI,
NWLink IPX/SPX Compatible Transport, and NWLink NetBIOS network
protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the IBM Turbo 16/4 Token-Ring ISA
adapter into an ISA slot.
2Connect network cable media to the IBM Turbo 16/4 Token-Ring ISA
adapter.
3Power on the machine and start Windows 95SR2.5 and the Token Ring
card will be recognized as “IBM Turbo 16/4 Token Ring ISA Adapter”.
Insert the “IBM Turbo 16/4 and Auto Wake Token-Ring ISA Adapter disk
2” and click on “Next”.
4Verify that “IBM Turbo 16/4 Token-Ring ISA Adapter” is listed and click
on “Finish”.
5Click on “OK” when the system prompts for the computer and workgroup
names.
6Enter the Computer Name, Workgroup, and Computer Description in the
appropriate spaces and click on “Close” (Contact your network
administrator if you do not have the required information).
Device Configuration Vectra Vli8
Interrupt 09
I/O Address 300
1 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Connecting to a Windows NT 3.51 Server
7Insert the Windows 95 CD into the CD-ROM drive, specify the path and
click “OK”.
8Remove the IBM diskette from the floppy drive and click on “YES” to
restart the system when prompted.
9Right-click on the “Network Neighborhood” icon and select “Properties”.
10 Accept the default Network Protocols and the Primary Network Logon
(Client for Microsoft Networks) as seen below and click on “OK”. (If you
do not have the required information, contact your network
administrator)
11 Client for Microsoft Networks
Client for Microsoft Networks
IBM Turbo 16/4 Token-Ring ISA Adapter
IPX/SPX-compatible Protocol
NetBEUI
12 Click on “OK” to accept the configuration.
13 Specify the path to your Windows 95 files when prompted.
2 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Microsoft Windows 95 SR2.5
2 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Microsoft Windows 95
SR2.5
Connecting to a
Windows NT 4.0 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• IBM Turbo 16/4 Token Ring ISA adapter and drivers disk version 2.22.
• Driver File: IBMTOK.SYS, version 10.27
• Microsoft Windows 95 SR2.5 media.
• Microsoft Windows NT 4.0 Server system that supports NetBEUI, NWLink
IPX/SPX Compatible Transport, and NWLink NetBIOS network protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the IBM Turbo 16/4 Token-Ring ISA
adapter into an ISA slot.
2Connect network cable media to the IBM Turbo 16/4 Token-Ring ISA
adapter.
3Power on the machine and start Windows 95SR2.5 and the Token Ring
card will be recognized as “IBM Turbo 16/4 Token Ring ISA Adapter”.
Insert the “IBM Turbo 16/4 and Auto Wake Token-Ring ISA Adapter disk
2” and click on “Next”.
4Verify that “IBM Turbo 16/4 Token-Ring ISA Adapter” is listed and click
on “Finish”.
5Click on “OK” when the system prompts for the computer and workgroup
names.
6Enter the Computer Name, Workgroup, and Computer Description in the
appropriate spaces and click on “Close” (Contact your network
administrator if you do not have the required information).
Device Configuration Vectra Vli8
Interrupt 10
I/O Address 300
2 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Connecting to a Windows NT 4.0 Server
7Insert the Windows 95 CD into the CD-ROM drive, specify the path and
click “OK”.
8Remove the IBM diskette from the floppy drive and click on “YES” to
restart the system when prompted.
9Right-click on the “Network Neighborhood” icon and select “Properties”.
10 Accept the default Network Protocols and the Primary Network Logon
(Client for Microsoft Networks) as seen below and click on “OK”. (If you
do not have the required information, contact your network
administrator)
11 Client for Microsoft Networks
Client for Microsoft Networks
IBM Turbo 16/4 Token-Ring ISA Adapter
IPX/SPX-compatible Protocol
NetBEUI
12 Click on “OK” to accept the configuration.
13 Specify the path to your Windows 95 files when prompted.
3 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Microsoft Windows 95 SR2.5
3 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Microsoft Windows 95
SR2.5
Connecting to a Novell
NetWare 3.12 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• IBM Turbo 16/4 Token Ring ISA adapter and drivers disk version 2.22.
• Driver File: IBMTOK.SYS, version 10.27
• Microsoft Windows 95 SR2.5 media.
• Novell NetWare 3.12 Server system that supports IPX network protocol.
• Novell Client for Windows 95 v2.5 installation media.
Device Configuration
Procedure
1With the HP Vectra turned off, install the IBM Turbo 16/4 Token-Ring ISA
adapter into an ISA slot.
2Connect network cable media to the IBM Turbo 16/4 Token-Ring ISA
adapter.
3Power on the machine and start Windows 95SR2.5 and the Token Ring
card will be recognized as “IBM Turbo 16/4 Token Ring ISA Adapter”.
Insert the “IBM Turbo 16/4 and Auto Wake Token-Ring ISA Adapter disk
2” and click on “Next”.
4Verify that “IBM Turbo 16/4 Token-Ring ISA Adapter” is listed and click
on “Finish”.
5Click on “OK” when the system prompts for the computer and workgroup
names.
6Enter the Computer Name, Workgroup, and Computer Description in the
appropriate spaces and click on “Close” (Contact your network
administrator if you do not have the required information).
Device Configuration Vectra Vli8
Interrupt 10
I/O Address 300
3 Installing the IBM Turbo 16/4 Token Ring ISA Adapter
Connecting to a Novell NetWare 3.12 Server
7Insert the Windows 95 CD into the CD-ROM drive, specify the path and
click “OK”.
8Remove the IBM diskette from the floppy drive and click on “YES” to
restart the system when prompted.
9Insert the “Novell Client for Windows 95” CD in the CDROM and execute
“Setup.exe”.
10 Click on “Yes” to accept the License Agreement.
11 Select “Custom” installation and click on “Next”.
12 Select “Bindery (NetWare 3.x)” and click on “Next”.
13 Click on “Install” to start the installation.
14 Click on “Yes” to set the Preferred Server. (If you do not have the
required information, contact your network administrator).
15 Click on “Reboot” to complete the installation.
16 Right-click on the “Network Neighborhood” icon and select “Properties”.
17 Accept the default Network Protocols and the Primary Network Logon
(Client for NetWare Networks) as seen below and click on “OK”. (If you
do not have the required information, contact your network
administrator)
18 Client for NetWare Networks
Client for NetWare Networks
IBM Turbo 16/4 Token-Ring ISA Adapter
IPX/SPX-compatible Protocol
NetBEUI
19 Click on “OK” to accept the configuration.
20 Specify the path to your Windows 95 files when prompted.
