BEFORE YOU BEGIN
CD/DVD DRIVE
123
1
3 4
Unplug the computer and
ground yourself Remove side cover 2
B
A
Remove connectors
B
A
A
Remove part
B
A
B
Replace part
B
A
Replace connectors
Before doing any work inside
your computer, ground yourself
by touching a metal part of the
computer’s frame.
Your replacement kit may contain
more parts than needed for the part
you are replacing.
All connectors are keyed for
their intended location and
should not require excessive
force to plug in.
2
HARD DRIVE
1 2
Remove connectors Remove part
B
A
A
A
B
Remove side cover 1
2 3
1
A
B
C
EXPANSION/RAID CARD
2
Lay down computer Remove connectors (if applicable) and remove part
3
C
B
A
Replace part and replace connectors (if applicable)
4
B
A
Replace connectors
6-in-1 MEDIA READER
1Remove connector Remove part
2
B
A
A
B
B
A
Replace part
3
Your replacement kit may contain
more parts than needed for the part
you are replacing.
All connectors are keyed for
their intended location and
should not require excessive
force to plug in.
2 3
POWER SUPPLY
3 4
A
B
B
Replace part Replace connector
Your replacement kit may contain
more parts than needed for the part
you are replacing.
1 2
3
5
A
B
C
D
A
B
Remove drive connectors
Remove system connectors
Replace power supply
Remove power supply
bracket
4Remove power supply
6Replace system connectors
A
B
All connectors are keyed for their intended location
and should not require excessive force to plug in.
4
POWER SUPPLY
7
A
B
C
D
Replace drive connectors Replace power supply
bracket
8
SOUND BLASTER
1
3 4
A
B
Remove connectors
B
A
A
Remove part
B
A
B
Replace part
A
B
Replace connectors
Your replacement kit may contain
more parts than needed for the part
you are replacing.
All connectors are keyed for
their intended location and
should not require excessive
force to plug in.
2
All connectors are
keyed for their
intended location
and should not
require excessive
force to plug in.
