Technical Reference Manual

HP 9000 B Class Workstations

April 96 Edition

Hewlett–Packard Company

3404 East Harmony Road, Fort Collins, CO 80525

Hewlett–Packard Preliminary and Confidential

    

______________________________________________________________________________

Notices

Information in this document is subject to change without notice.

Hewlett–Packard makes no warranty of any kind about this manual, including, but not limited to, the

implied warranties of merchantablility and fitness for a particular purpose. Hewlett–Packard shall not

beliableforerrorscontainedhereinordirect,indirect,special,incidentalorconsequentialdamagesabout

the furnishing, performance, or use of this material.

Warranty. PleasecarefullyreadtheenclosedHewlett–PackardSoftwareProductLicenseAgreementand

Limited Warranty before operating this product. Rights in the software are offered only on the condition

that the customer accepts all terms and conditions of the License Agreement.

Operating the product indicates your acceptance of these terms and conditions. If you do not agree to

the License Agreement, you may return the unused product for a full refund.

Acopy ofthe specificwarranty termsapplicable toyour Hewlett–Packardproduct andreplacement parts

can be obtained from your local Sales and Service Office.

This document contains information that is protected by copyright. All rights are reserved.

Reproduction, adaptation, or translation without prior written permission is prohibited, except as

allowed under the copyright laws.

Restricted Right Legend

Use, duplication, or disclosure by the U.S. Government Department of Defense is subject to

restrictions as set forth in paragraph (b)(3)(ii) of the Rights in Technical Data and Software clause in

FAR 52.227–7013.

This software and documentation is based in part on the Fourth Berkeley Software Distribution under

licence from the Regents of the University of California.

Hewlett–Packard Preliminary and Confidential



   

Printing History

New Editions of this manual incorporate all material updated since the previous edition. Update

packages may be issued between editions and contain replacement and additional pages to be merged

into the manual by the user.

The manual printing date and part number indicate its current edition. The printing date changes

when a new edition is printed. (Minor corrections and updates which are incorporated at reprint do

not cause the date to change.) The manual part number changes when extensive technical changes are

incorporated.

April 1996 ... Edition 1

Electrostatic Discharge (ESD) Precautions

Electrostatic charges can damage the integrated circuits on printed circuit boards. To prevent such

damage from occurring, observe the following precautions when unpacking and installing the board.

•Stand on a static–free mat.

•Wear a static strap to ensure that any accumulated electrostatic charge discharges from your body

to ground.

•Connect all equipment together, including the static–free mat, static straps, routing nodes, and

peripheral units.

•Keep uninstalled printed circuit boards in their protective antistatic bags.

•Once you have removed the printed circuit boards from their protective antistatic bags, handle

them by their edges.

Hewlett–Packard Preliminary and Confidential

    

For:root

Printed on:Wed, Sep 4, 1996 12:48:44

From book:MerlinTechRef

Document:chap_1

Last saved on:Thu, Apr 25, 1996 09:11:20

Hewlett–Packard Preliminary and Confidential



B Class Technical Reference General Information

General Information

This chapter describes the general features and gives an overview of the B Class workstation.

Features

Hewlett–Packard’s Model B132L/B160L Workstations are based on a PA7300 central processing unit

(CPU) that provides a variety of interfaces, graphics, and mass storage.

The following table lists the features of the Model B132L/B160L workstations.

Table 1–1. Features

Features Functionality

Operating system HP–UX 10.2

CPU Frequency

Performance

PA–RISC PA7300

Performance information may be obtained from HP Sales

(NOTE: Performance figures are OS and compiler version re-

lated.)

External Cache

Size

Bus Width

Speed

1MB (Two 512KB DIMMs)

128 bits with 16 bit for error detection and correction

83 MHz

Time source Battery–backed Real–Time Clock

Memory

Memory Management Unit

Virtual memory address

Instruction TLB and

data TLB

6 slots

32MB minimum required

Upgradeable to 384 MB

48 bit

Unified 120 page entries, additional single–entry instruction

TLB lookaside, 16block entries, fully associative

(continued)

Hewlett–Packard Preliminary and Confidential

1-2   

General Information

Table1–1. Features (Continued)

Optional Graphics HP VISUALIZE 24Z or 24–plane graphics

HP VISUALIZE–8/24Z Accelerated 8–plane or 24–plane 3D

graphics

HP VISUALIZE–48Z 24/24 image planes, 8 overlay planes,

24–bit Z buffer 3D graphics

Graphics Performance Performance information may be obtained from HP Sales

(NOTE: Performance figures are OS and compiler version re-

lated.)

200–Watt Power supply Four DC output voltages (+12V, +5V, –12V, and +3.3V)

Mass storage Up to two of the following:

3.5–inch, 4GB, low–profile, SE SCSI hard disk drive

3.5–inch, 2GB, low–profile, SE SCSI hard disk drive

3.5–inch, 1GB, low–profile, SE SCSI hard disk drive

3.5–inch, 4GB, low–profile, FW SCSI hard disk drive

3.5–inch, 2GB, low–profile, FW SCSI hard disk drive

Network IEEE 802.3 AUI connection

Supports connections to 10BASE2 (ThinNet), 10BASE5 (Thick-

Net), and 10BASE–T (EtherTwist) networks with the use of an

external transceiver.

I/O Two 9–pin Serial ports

One 25–pin HP parallel port

8–bit Single–Ended SCSI interface

16–bit Fast Wide SCSI interface (optional)

2 PS/2 ports for Keyboard and Mouse

CD–quality audio and speaker output

CD–quality microphone or audio input

Hewlett–Packard Preliminary and Confidential

1-3

B Class Technical Reference General Information

Memory

Standard memory is 32 MB of 60 ns 4 Mbit or 16 Mbit DRAMs. 32 MB is the minimum required for

the HP–UX operating system. Each workstation has 8 memory slots, labeled 0A, 0B through 2A, 2B.

There are several possible memory configurations:all 32 MB to 96 MB installed in pairs of

16 MB SIMM cards; or, 128 MB to 384 MB installed in pairs of 64 MB SIMM cards. The SIMM

pairs may be mixed for memory sizes between 32MB and 384MB, in all configurations memory

SIMMS must be installed in pairs of equal size.

Memory upgrades include:

HP A3026A 32 MB DRAM Upgrade, two 16 MB DRAM boards.

HP A3027A 128 MB DRAM Upgrade, two 64 MB DRAM boards.

Internal Storage Devices

The B132L/B160L workstation can have up to two fixed disk drives, one removable media drive

(DDS–tape or CD–ROM), and a floppy drive.

Fixed Disk drives

3.5–inch, 4GB, low–profile, single ended SCSI hard disk drive

3.5–inch, 2GB, low–profile, single ended SCSI hard disk drive

3.5–inch, 1GB, low–profile, single ended SCSI hard disk drive

3.5–inch, 4GB, low–profile, fast, wide differential SCSI hard disk drive

3.5–inch, 2GB, low–profile, fast, wide differential SCSI hard disk drive

Removable Media drives

The B Class workstation supports the following types of removable media devices:

CD–ROM drive

HP A4325A CD–ROM dive(4X speed)

DDS Tape drive

3.5–inch, DDS1 tape drive

3.5–inch, DDS2 tape drive

HP92283A Box of five 60–meter DDS data cassettes

HP92283B Box of five 90–meter DDS data cassettes

HP92283K Package of two cleaning cassettes

Floppy Disk drive

HP A4283A 96mm, slimline 1.44MB floppy drive

HP92192X High–Density Micro Flexible Disks (1.44MB Formatted Capacity) – box of ten diskettes

Hewlett–Packard Preliminary and Confidential

1-4   

General Information

System Graphics

The B132L/B160L workstation comes with built–in 8–bit color and high resolution graphics. The

supported monitors are:

A4330A 17–inch, multimode, 1280x1024 color monitor

A4331A 20–inch, multimode, 1280x1024 color monitor

AxxxxA 21–inch, multimode, 1600x1200 color monitor

The supported graphics boards are:

•HP VISUALIZE 24Z or 24–plane graphics

•HP VISUALIZE–8/24Z Accelerated 8–plane or 24–plane 3D graphics

•HP VISUALIZE–48Z 24/24 image planes, 8 overlay planes, 24–bit Z buffer 3D graphics
