HP Brio 80xx Manuale utente

Advanced Setup Guide

Online Guide

Date: Autumn 1997

How to Use This Online Guide

Click underlined red text to go to the topic indicated. Underlined red text is text that is “linked”

to another topic in the guide.

Click the Go Back button in the toolbar to go back to your previous place in the guide.

Click the Next Page button in the toolbar to go to the next page in the guide.

Click the Previous Page button in the toolbar to go to the previous page in the guide.

Click the First Page button in the toolbar to go to the opening screen of the guide.

Click a bookmark name (to the left of the screen) to go to the topic corresponding to that

bookmark. Click the small triangle to the left of the bookmark to hide or show subordinate

bookmarks.

Topic

Advanced Setup Guide

How to use this

Notice

Contents

Introducing the Adva

Note You can print this book, but only in landscape format.

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained

herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this

document may be photocopied, reproduced, or translated to another language without the prior written consent of

Hewlett-Packard Company.

CompuServeis a U.S. trademark of CompuServe, Inc.

Microsoft, MS-DOS and Windowsare U.S. registered trademarks of Microsoft Corporation.

Hewlett-Packard France

Grenoble Personal Computer Division

Technical Marketing

38053 Grenoble Cedex 9

France

1997 Hewlett-Packard Company

Advanced Setup Guide

The HP PC

The HP PC provides the following components and features:

System Board

•Enhanced IDE (Integrated Drive Electronics) controller with two channels on the PCI bus:

❒A primary IDE channel for two IDE hard disk drives.

❒A secondary IDE channel for an IDE CD-ROM drive or a IDE hard disk drive.

•Rear panel connectors:

❒1 mouse socket

❒1 keyboard socket

❒1 display connector

❒1 Universal Serial Bus (USB) connector

❒1 parallel port

❒1 serial port

•Keyboard/mouse controller and interface.

•Four memory module sockets for DRAM main memory, allowing installation of up to 128 MB.

•1 MB Integrated video memory on the system board, upgradeable to 2MB.

•System ROM (using flash ROM technology) that can be easily updated with the latest firmware, using the Phlash.exe

program supplied with the firmware upgrade.

The HP PC

The system ROM contains:

❒The BIOS (system BIOS, video BIOS and low-option ROM).

❒The menu-driven Setup program with context-sensitive help

(in U.S. English only).

•Energy Star-compliant power management.

All PCs described in this manual have a power-saving capability in accordance with the Energy Star guidelines (U.S.

Environmental Protection Agency). Nevertheless, it is possible that some configurations (e.g. fully loaded multi-media

models) use slightly more than 30W in sleep mode, which is the limit required for obtaining the Energy Star label.

Inclusion of the Energy Star label indicates that your PC is Energy Star-compliant.

Backplane

Five expansion card slots for the installation of:

❒Two 32-bit PCI (Peripheral Component Interconnect) cards

and three 16-bit ISA (Industry Standard Architecture) cards,

❒Three 32-bit PCI cards and two 16-bit ISA cards.

Preinstalled Software

Your HP PC is preinstalled with the following operating software:

•BIOS: Phoenix.

•Operating system: On most models, Windows 95 is provided. This operating system provides: configuration tools, Plug

and Play mode, and many other features.

•Depending on the model you have purchased, your computer may also include: business applications, communication

software, and a range of information sources, tools, and utilities to better tailor your PC to suit your needs.

Associated Documentation

The following HP publications may also assist the reader of this manual:

•Communications - paper book providing guidance on how to set up your communications software.

•Getting Support - paper book explaining how to obtain HP support. The book also contains safety and warranty

information.

•Questions & Answers - paper document that answers your most commonly asked questions.

•Upgrade Guide - online book explaining how to upgrade your PC.

•Learning About Your HP PC - online help giving information about your computer.

For a list of available documentation, double-click the HP Guide to Documentation icon on the desktop, or press

the Information key on your keyboard.

If your PC is up and running but you are experiencing some problems, refer to the online support center on page 9 .

HP Centers

Double-click the icon on the desktop, or click the Start menu and then HP Centers, or press the key on

your keyboard, to open the HP Centers window.

Once you have opened the HP Centers window you can access and use the following centers:

•Communications - communicate easily with the outside world1. You can set up your fax program, send a fax,

enable/disable fax reception, set up your answering machine, dial a phone number, and listen to your voice messages.

•Data Protection - make sure your data is secure and protected. You can protect your PC from viruses, back up your

data, maintain your hard disk (for example, scan it for errors), and restrict access to your PC.

•Network - share and access local network resources2. You can share and access printers, folders and files, fax modems,

CD-ROM drives, Internet connections, and so on.

•Welcome - discover what you can do with your PC and how to personalize it. You can register your PC, check your PC

settings, follow a PC tour, and see what documentation is available to you.

•Support - solve computer problems with the support tools and services provided by HP. You can diagnose hardware

problems, recover software applications that were preinstalled on your PC, access HP online support services, and run

Windows 95 troubleshooting tools.

1. Communications features are only available on communications models.

2. To use a local area network (LAN), you need to install a network card and software.

HP Centers
