HP Compaq Presario Manuale
3-112 Volume Two
Presario 7500
Processor Boards Assembly Spare Part System
Processor Board w/o
Processor 157126-101 170686-101 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
Configuration
Code Assembly System Board
Spare Part Model
DCV1 157126-101 170686-101 7500
DCV2 157126-101 170686-101 7500
DCV3 157126-101 170686-101 7500
DCV6 157126-101 170686-101 7500
DCV7 157126-101 170686-101 7500
DCV8 157126-101 170686-101 7596
DCVB 157126-101 170686-101 7573
DCW1 157126-101 170686-101 7500
DCW2 157126-101 170686-101 7568
DCW3 157126-101 170686-101 7588
DCW4 157126-101 170686-101 7588
DCW5 157126-101 170686-101 7568
DCW6 157126-101 170686-101 7587
DCW7 157126-101 170686-101 7500
DCW8 157126-101 170686-101 7583
DCW9 157126-101 170686-101 7596
DCWA 157126-101 170686-101 7599
DCWB 157126-101 170686-101 7583
DCWC 157126-101 170686-101 7598
DCWE 157126-101 170686-101 7592
DCWF 157126-101 170686-101 7591
DCWH 157126-101 170686-101 7597
DCWJ 157126-101 170686-101 7595
DCWK 157126-101 170686-101 7598
DCWL 157126-101 170686-101 7589
DCWM 157126-101 170686-101 7500
DCWR 157126-101 170686-101 7599
DCWS 157126-101 170686-101 7543
Microprocessors Assembly Spare Part System
466, Celeron, w/ Heat Sink 401264-006 157285-001 7500, 43
500, Celeron, w/ Heat Sink 401264-007 149267-001 7500
533, Celeron, w/ Heat Sink 401264-009 149266-001 7573
566, Celeron, w/ Heat Sink 174029-002 175863-001 7500, 96
500, Pentium III, w/ Heat
Sink 158353-001 170073-001 7500, 68, 83, 87
550, Pentium III, w/ Heat
Sink 158353-002 170074-001 7500, 83, 88, 89
600, Pentium III, w/ Heat
Sink 158353-003 171260-001 7500, 91, 92, 97, 98,
99
650, Pentium III, w/ Heat
Sink 158353-004 186982-001 7595
700, Pentium III, w/ Heat
Sink 157381-001 176842-001 7599
700, Pentium III, w/ Heat
Sink 158353-005 189015-001 7599
Volume Two 3-113
Presario 7500
Memory DIMMs Assembly Spare Part System
64 MB 309036-001 179190-001 7500, 68, 73, 83, 87,
88, 89, 91, 92, 96, 97,
98, 99
128 MB 309037-001 166966-001 7583, 88, 95, 98, 99
Miscellaneous Assembly Spare Part System
Button Board, Headphone 127738-101 141011-001 7500, 43, 73, 83, 87,
88, 95, 96, 97, 98, 99
Button Board, Headphone 127738-101 155463-021 7568, 88, 89, 91, 92,
98, 99
Ethernet Card, Homenet 116158-001 120788-001 7587, 97
Front I/O Assembly 158487-002 170077-001 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
Keyboard 341162-XXX 387084-XXX 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
Mouse, Scroll 334684-006 334689-002 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
Controller Boards Assembly Spare Part System
NIC, 10/100 122849-001 123494-001 7573, 83, 88
Hard Drives Assembly Spare Part System
8.0 GB 158739-001 168027-001 7500, 43
10.0 GB 138224-001 168028-001 7500, 89, 91
13.0 GB 158740-001 168030-001 7500, 68, 88, 98, 99
15.0 GB 168097-001 170389-001 7500
17.0 GB 159945-001 168591-001 7573
20.0 GB 165123-001 168031-001 7583, 87, 92
30.0 GB 165134-001 168628-001 7588, 95, 96, 97
40.0 GB 171457-001 173342-001 7598, 99
CD-ROM Drive Assembly Spare Part System
40X, Stone 388770-806 134125-001 7500, 43, 87, 88, 97,
98
DVD, 12X 177719-F82 180811-001 7500, 43, 68, 83, 88,
89, 95, 96, 98, 99
RW 147290-001 120893-001 7573, 83, 87, 88, 91,
92, 95, 96, 97, 98, 99
Diskette Drives Assembly Spare Part System
1.44 MB 388617-806 136436-001 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
Modems Assembly Spare Part System
V.90, PCI Lucent 155817-001 166358-002 7500, 68, 88, 89, 91,
92, 98, 99
V.90, PCI 56K, Enduro 146139-001 166386-001 7500, 43, 73, 83, 87,
88, 95, 96, 97, 98, 99
V.90, PCI 56K, Enduro 146139-002 166386-002 7500, 43, 83, 87, 88,
95, 96, 97, 98, 99
Modem w/ Adapter 165268-001 165224-001 7568, 88
3-114 Volume Two
Presario 7500
Cables Assembly Spare Part System
Audio 171891-009 174773-001 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
Dual Connect, all SEC
Devices 167344-001 171290-001 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
FDD 122240-001 171291-001 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
Hard Drive, ATA 66 108950-014 171289-001 7500, 43, 68, 73, 83,
87, 88, 89, 91, 92, 95,
96, 97, 98, 99
Telephone L/Line 112666-003 137256-001 7500, 68, 73, 83, 87, 88
Modem Cables Assembly Spare Part System
Modem Cable, Ferrite,
United Kingdom 165227-033 161779-033 7568, 88
Modem Cable,
Telephone, Norway 165227-091 304398-091 7568, 88
Modem Cable w/
Adapter 165268-001 242636-001 7568, 88
Modem Cable Adapter
– Australia 234441-011 304398-011 7568, 88
Modem Cable Adapter
– Belgium 234441-181 304398-181 7568, 88
Modem Cable Adapter
– Denmark 234441-081 316904-081 7568, 88
Modem Cable Adapter
– Finland 234441-351 316904-351 7568, 88
Modem Cable Adapter
– France 234441-051 304398-051 7568, 88
Modem Cable Adapter
– Italy 234441-061 316904-061 7568, 88
Modem Cable Adapter
– Netherlands 234441-331 316920-331 7568, 88
Modem Cable Adapter
– Sweden 234441-101 316904-101 7568, 88
Modem Cable Adapter
– Switzerland 234441-112 316904-112 7568, 88
Modem Cable Adapter
– United Kingdom 234441-032 158593-031 7568, 88
Power Supply/Battery Assembly Spare Part System
Power Supply, 145 W 124848-001 127999-001 7500, 43, 73, 83, 87,
88, 95, 96, 97, 98, 99
Power Supply, 145 W 124848-001 155461-021 7568, 88, 89, 91, 92,
98, 99
Volume Two 3-115
Presario 7500
Memory Upgrade Chart
MAXIMUM MEMORY 512 MB
MEMORY OPTIONS NOT AVAILABLE
SYSTEM BOARD
157126-100
