HP I2000 Manuale

processor installation

hp workstation i2000

Manufacturing Part Number: A6037-90060

Edition: E0801

Printed in U.S.A.

hp workstation i2000

TABLE OF CONTENTS

WARNINGS

SAFETY AND REGULATORY REQUIREMENTS

PURPOSE OF THIS GUIDE

1. WORKSTATION INSTRUCTIONS ...................................................................... 10

1.1 accessing the system ..................................................................................... 10

1.2 installing an Itaniumprocessor in an hp workstation i2000 ...................... 15

1.2.1 removing the processor ........................................................................ 15

1.2.2 installing the processor .......................................................................... 17

1.2.3 replacing the power pod...................................................................... 19

1.3 installing a second Itaniumprocessor in a workstation............................ 20

1.4 reassembling your workstation ...................................................................... 20

1.4.1 reinstalling the processor board ........................................................... 20

1.5 workstation support ........................................................................................ 23

hp workstation i2000

Figures

Figure 1. Removing the Four- (4) Chassis Screws ................................................ 10

Figure 2. Bezel Interlock Clips................................................................................ 11

Figure 3. Internal System View after Side Door Removal ................................... 12

Figure 4. Power Supply Door in Opened Position ............................................... 13

Figure 5. Processor Power Harness ....................................................................... 14

Figure 6. Processor Assembly Removal................................................................ 14

Figure 7. Processor Assembly ................................................................................ 15

Figure 8. Removing the Power Pod...................................................................... 16

Figure 9. Removing the Processor ........................................................................ 16

Figure 10. Replacing the Processor ...................................................................... 17

Figure 11. Properly Seating the Processor............................................................ 18

Figure 12. Top View of Processor and Cross-Torque Pattern ............................. 18

Figure 13. Installing the Power Pod....................................................................... 19

Figure 14. Correct Reinstallation of E-PAC........................................................... 21

Figure 15. E-PAC Inserted over Memory Cards................................................... 21

Figure 16. E-PAC Installation.................................................................................. 22

Figure 17. Power Supply Door Locking Tab ......................................................... 23

hp workstation i2000

WARNING!

Please read all warnings and instructions BEFORE operating the system. Avoid Injury: To avoid

personal injury when unpacking the system, use only a mechanical assist unit to lift it off the

shipping pallet. The system weighs approximately 84 lbs.

WARNINGS

The following cautionary notices apply whenever you remove the access cover to access components inside

the system. Before you proceed, please read the following Warning section carefully.

The power supply in this product contains no user-serviceable parts. Refer

servicing only to qualified personnel.

Do not attempt to modify or use the supplied AC power cord if it is not the exact

type required.

The DC push-button on/off switch on the system does not turn off system AC

power. To remove AC power from the system, you must unplug each AC power

cord from the wall outlet or power supply.

SAFETY STEPS: Whenever you remove the chassis covers to access the inside

of the system, follow these steps:

1. Turn off all peripheral devices connected to the system.

2. Turn off the system by using the push-button on/off power switch on the system.

3. Unplug all AC power cords from the system or from wall outlets.

4. Label and disconnect all cables connected to the I/O connectors or ports on the

rear of the system.

5. Provide some electrostatic discharge (ESD) protection by wearing an anti-static

wrist strap attached to chassis ground of the system—any unpainted metal

surface—when handling components.

6. Do not operate the system with the chassis covers removed.

After you have completed the six SAFETY steps above, you can remove the

system covers. To do this:

1. Unlock the system from the side using the keys provided.

2. Remove the thumbscrews to remove the side cover.

Continued

hp workstation i2000

WARNINGS (continued)

For proper cooling and airflow, always reinstall the chassis covers before turning on

the system. Operating the system without the covers in place can damage system

parts. To install the covers:

1. Check first to make sure you have not left loose tools or parts inside the system.

2. Check that cables, add-in boards, and other components are properly installed.

3. Attach the covers to the chassis with the screws removed earlier, and tighten

them firmly.

4. Lock the system to prevent unauthorized access inside the system.

5. Connect all external cables and the AC power cord to the system.

The microprocessor, heat sink and Power Pod may be hot if the system has been

running. Also, there may be sharp pins and edges on some board and chassis

parts. Contact should be made with care. Consider wearing protective gloves.

Danger of explosion if the battery is incorrectly replaced. Replace only with the

same or equivalent type recommended by the equipment manufacturer. Discard

used batteries according to manufacturer’s instructions.

The system is designed to operate in a typical office environment. Choose a site

that is:

1. Clean and free of airborne particles (other than normal room dust).

2. Well ventilated and away from sources of heat including direct sunlight.

3. Away from sources of vibration or physical shock.

4. Isolated from strong electromagnetic fields produced by electrical devices.

5. In regions that are susceptible to electrical storms, we recommend you plug your

system into a surge suppresser and disconnect telecommunication lines to your

system during an electrical storm.

6. Provided with a properly grounded wall outlet.

7. Provided with sufficient space to access the power supply cords, because they

serve as the product’s main power disconnect.

hp workstation i2000

WARNING

Do not open the power supply. Risk of electric shock. Refer servicing

of the power supply to qualified service personnel.

CAUTION

Before removing the access cover for any reason, observe these

cautionary guidelines.

• Turn off all peripheral devices.

• Turn off the system by pressing the power button on the front of the chassis. Then

unplug the AC power cord from the chassis or wall outlet.

• Label and disconnect all peripheral cables connected to the I/O connectors or

ports on the back of the chassis.

• Provide some electrostatic discharge (ESD) protection by wearing an anti-static

wrist strap attached to chassis ground—any unpainted metal surface—when

handling components.

CAUTION

The power button on the front panel does not disconnect the AC power.

To remove power from the system, you must unplug the AC power cord

from the AC supply or from the computer chassis.

CAUTION

ESD can damage disk drives, boards, and other parts. Perform all

procedures in this chapter only at an ESD workstation. If one is not

available, provide some ESD protection by wearing an anti-static wrist

strap attached to chassis ground



any unpainted metal surface



your system when handling parts.

Always handle boards carefully. They can be extremely sensitive to

ESD. Hold boards only by their edges. Do not touch the connector

contacts. After removing a board from its protective wrapper or from the

system, place the board component side up on a grounded, static free

hp workstation i2000

surface. If you place the board on a conductive surface, the battery

leads may short out. If they do, this will result in a loss of CMOS data

and will drain the battery. Use a conductive foam pad if available but

not the board wrapper. Do not slide the board over any surface. For

proper cooling and airflow, always install the chassis side cover before

turning on the system. Operating it without the cover in place can

damage system parts.

safety and regulatory requirements

Read all instructions before using the system. Save all the safety and regulatory instructions. The

Federal Communications Commission at the time of distribution has not approved this

workstation.

This product is not, and may not be, offered for sale or lease, or sold until the written approval of

the FCC and Product Safety Certification have been obtained.

hp workstation i2000

purpose of this guide

The purpose of this guide is to provide detailed instructions on installing an Itanium

processor (for replacement or adding a second processor) in an hp workstation i2000.

Each section is intended to build on the previous section and should be preformed in the

order listed. If this kit is used in conjunction with another upgrade kit, the instructions

following the Removing the Processor section may overlap. Please read all instructions

prior to beginning any upgrade.

This processor kit contains:

• One- (1) Itaniumprocessor

• One- (1) heat sink (attached to processor)

hp workstation i2000

1. workstation instructions

1.1 accessing the system

NOTE

Due to the weight of the workstation system (approximately 84 lbs.), care must

be taken when maneuvering the system during assembly and disassembly.

CAUTION

The DC push-button on/off switch on the system does not completely turn off system AC power.

To remove AC power from the system, you must unplug each AC power cord from the wall outlet

or power supply.

Before servicing, first identify the component(s) that must be added or removed from the

system. If replacing components, such as hard drives, CD-ROMs, or the LS-120 floppy

drive, the front bezel (large plastic section on the front of the system) must be removed

for access to the bays, as well as side access within the system. In cases not involving the

peripherals or front panel ports, the bezel can remain in place. Use the following steps to

access or open the system:

1. Starting with the system in an upright (normal) position, and resting on an anti-

static surface, loosen the four- (4) Phillips-head screws from the rear (as shown in

Figure 1).

Figure 1. Removing the Four- (4) Chassis Screws
