s500

Digital Camera

Quick Start Guide

1

For more details about the camera operation and troubleshooting, please read the User Manual located on

the CDROM disc included with your camera or visit http://www.hp.com/support and download it for

the camera support page.

1

Tour of Your HP Camera

Front View

1 2

3

4

Flash1.

Self-timer LED / AF Assist Lamp2.

Lens3.

Microphone4.

Back View

11

10

5

8

7

6

9

LCD Screen5.

Shutter button6.

Menu Button7.

Function / Delete Button8.

LED Indicator9.

OK Button / 4-way Navigation Control10.

Mode Selector Switch11.

Photo Mode

Video Mode

Playback Mode

2 3

Top View

12

13

Power Button12.

Zoom Toggle13.

Bottom View

15 16

14

Battery/Memory card compartment14.

Tripod screw hole15.

Speaker16.

Left/Right View

18

17

USB/TV Out17.

Strap Ring18.

2 3

1. Getting Started

Attach the Camera Strap

To reduce the risk of dropping the camera, it is strongly recommended

to attach and use the provided camera strap

Inserting the Battery

Follow these instructions to insert the battery into the battery/memory card compartment.

If the battery are already installed, make sure to power off1.

the camera before removing and inserting recharged or new

battery.

Open the battery/memory cardcompartment at the bottom of2.

the camera as illustrated.

4 5

Insert the battery into the compartment with correct3.

orientation as illustrated. Be sure to push the battery into

position until the battery is locked into place.

Close and secure the battery/memory card compartment by sliding the locking button towards the4.

edge of the camera (as illustrated).

4 5

Charging the Battery by USB

The battery that comes alone with your package is not fully charged. You need to charge the battery

before using the camera.

Connect the camera with the USB cable as shown.1.

Connect the other end with the USB adapter and plug it into a power outlet or with the USB port of2.

PC directly for charging.

When the battery is charging, the LED indicator lights up.•

When the battery is fully charged, the LED indicator turns off.•

Whenthebatteryisincorrectlycharged,theLEDindicatorashesrapidly.•

When the camera is connected without the battery, the LED indicator will not Light up.•

1

2

The battery charging time is approximately 2 hours.

It’s not recommended to operate the camera when charging.

6 7

Inserting an SD/SDHC/SDXC Memory Card

It is highly recommended that the camera storage is expanded by inserting a SD or SDHC or SDXC

memory card. These memory cards are available at most consumer store and online locations.

Make sure to power off the camera before proceeding. Inserting1.

the memory card while powered on may damage the card and

camera.

Open the battery/memory card compartment at the bottom of the2.

camera.

Insert the SD/SDHC/SDXC card into the memory card slot with3.

the metallic connectors facing the front side of the camera as

illustrated below.

Push the SD/SDHC/SDXC card into the memory slot until it clicks into place. If the card does not4.

click into place, repeat the previous step to ensure proper orientation.

Close the battery/memory card compartment.5.

The 720p video recording capability of this camera requires a class 6 or faster

(High Speed) SD/SDHC/SDXC memory card.

6 7

- To remove the SD/SDHC/SDXC card

Make sure to power off the camera before proceeding.1.

Removing the memory card while powered on may damage

the card and camera.

Open the battery/memory card compartment.2.

Gently push the card until it clicks and pushes out of3.

position.

Carefully pull out the card.4.

8 9

2. Initial Settings

Whenthecameraispoweredupforthersttime,pleasesetthedisplaylanguageanddate&time.

Setting the Language

Use the 4-way navigation control to move through the selections.1.

Highlight the desired language and press the2. OK button to select.

Setting the Date & Time

Use the 4-way navigation control to move through the selections and to change the setting values.1.

Press2. OK button when finished. This will save your date and time settings.

If necessary, press3. Menu button to close the menu.

At this point, the camera settings are set to the default automatic mode and is ready to take photos and

videos.
