HP DF1000A3 Manuale utente

HP df720, df780, df820 , df1000

Series

Digital Picture Frame

Cadre Photo Numérique

User Manual

Manuel de l’Utilisateur

Revision 1.0a

ENGLISH

FCC Compliance Statement

Note: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one of

the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, only use shielded

interface cables when connecting to computer or peripheral devices.

Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

ENGLISH

Table of Contents

FCC Compliance Statement

What’s in the Box?

Getting Started

Remote Control

Initial Setup

Setup Menu

Key Features

Selecting a Memory Source

Picture Options

Picture Rotate and Zoom

Copying and Deleting Pictures

Printing with PictBridge™

Music Playback

Video Playback

Four-Quadrant Display

Clock & Calendar Display

Specifications

Frequently Asked Questions

Cleaning and Care Tips

Getting Help

ENGLISH

What’s in the Box

Qty Item Image

1 Digital Picture Frame

1Remote Control

Replacement Battery = CR2025

PULL

Universal Power Adapter

(df720, df780, & df820 — 9V, 2A)

(df1000 — 12V, 1.5A)

1 USB 2.0 Cable

1 User Manual

1 Quick Start Guide

1 Warranty Document

IMPORTANT: Please keep this document

for technical support contact information.

1 Declaration of Conformity

Certain models may have inter-

changeable Mattes

ENGLISH

1. Connect the power cord into the DC input of the digital picture frame

and plug the adapter into a power outlet as illustrated below.

DC 12V

MEMU

MUTE

SD/MS/MMC/XD

2. The HP Digital Picture Frame is preloaded with pictures that illustrate

the basic features of this product. If you want to view these pictures,

turn the frame on as illustrated in step 4. The slideshow will begin in

a few seconds. However, if you wish to immediately view your own

pictures, go to the next step (step 3).

3. Insert a memory card or USB storage device (external memory)

containing desired pictures, music, and/or video into the

appropriate card slot or USB port as illustrated below. Note:

Memory cards and USB storage devices must be orientated correctly.

DC 12V

MEMU

MUTE

SD/MS/MMC/XD

Getting Started

HP df720, df780, & df820 HP df1000

ENGLISH

4. Power on the digital picture frame.

MEMUMUTE

A slideshow of your pictures will begin automatically in a few seconds.

If music tracks are available on the same external memory device, the

slideshow will be displayed with background music unless disabled in

the SETUP MENU. Enjoy it and have fun!

5. In addition to the remote control, the digital picture frame has basic

control buttons and LCD backlighting controls on the top of the frame

as illustrated below.

Next/Forward

Play/Pause/Select

Previous/Return

MuteLCD Backlighting

Move the POWER switch to the ON position

HP df720, df780, & df820

Push the POWER botton

HP df1000

MEMUMUTE

Next/Forward

Play/Pause/Select

Previous/Return

Mute

Power

HP df720, df780, & df820

HP df1000

ENGLISH

6. When using the remote control, point it at front remote sensor as

illustrated below.

Remote Sensor

ENGLISH

Remote Control

MENU: Press to access main menu mode or card selection

mode

TIME SET: Press this button in the time mode to set up the

date and time

SLIDESHOW: Press this button to begin a picture slideshow.

VIDEO PLAYBACK: Press this button to playback video les.

UP: Press to move up in thumbnail mode or when setting

options.

NEXT or FORWARD: Press to move right in browse,

thumbnail or menu mode.

PLAY/PAUSE or SELECT: Press to change display mode (slide

show, browse, or thumbnail). Press to play or pause music

or video les. Press to make selections in menu or settings

mode.

PREV or RETURN: Press to move left in browse, thumbnail or

menu mode, or return to previous screen in slide show mode.

DOWN: Press to move down in thumbnail mode or when

setting options.

COPY/DEL: Press this button in Photo Browse mode or

MUSIC mode to initiate the copy or delete process.

ROTATE: Press to rotate the picture.

ZOOM: Press to enlarge picture in photo browse mode.

VOL + / - : Press the + button to increase and the – button

to decrease audible playback volume.

Print: Press this button in the Browse mode to print photo

from a PictBridge™ photo printer.

BRIGHTNESS/CONTRAST/TINT/COLOR: Press this button

during picture browse mode to adjust basic appearance

controls.

ENGLISH

1. Pull tab from remote control to activate.

PULL

Should your remote control require a new battery, please purchase

a 3 volt lithium CR2025 model for replacement. The remote control

has battery replacement instructions stamped into the back side as

illustrated below.

2. Power on the picture frame and allow the picture slideshow to begin.

Press button once to view the MAIN MENU as illustrated

below.

Initial Setup

ENGLISH

3. Press or to highlight the icon. Press the to

open the SETUP MENU as illustrated below

4. LANGUAGE setting will be highlighted in blue. Press the

button to display additional language selections. Note: If desired

language is already selected, go to step 6.

5. Use or to highlight the desired On-Screen-Display

language (OSD) and press to select the language. Press

to return to the setup menu.

6. Press or to highlight other options and press to

select. Continue to use or to highlight and to select

the desired settings. Read the next section titled SETUP MENU for

details of these options.
