Overview

G16SE

The HP NonStop G16SE enclosure is a high-bandwidth 16-port Ethernet ServerNet

enclosure for the HP Integrity NonStop BladeSystem NB54000c and the HP Integrity

NonStop BladeSystem NB56000c. This product meets the stringent requirements

of the NonStop system, which oers continuous availability, scalability, and

mission-critical capabilities. The NonStop G16SE is a follow-on product to the

combination of the Input Output Adapter Modular Enclosure (IOAME) and the

Gigabit 4-port ServerNet Adapter (G4SA). It requires 8U of rack space and can be

separated into two 4U modules. For increased exibility, these modules may be

installed in dierent racks. The ports on the G16SE can be paired such that a failure

of a port does not result in any outage or reconnection and does not require manual

intervention. Each Ethernet port is dual-ported to both the X and Y ServerNet fabrics.

This ensures that there is no outage due to a ServerNet fabric failure.

The G16SE complies with 1GbE and 10/100 Ethernet standards. It is designed

toaddress your need for increased connectivity and performance.

16-port enclosure

• The 16 ports can be paired so that a single port failure can seamlessly fail over

tothe paired port without intervention.

• Each of the two 4U modules has four 1GbE ports and four 10/100 Ethernet ports.

• Each of the two 4U modules provides Ethernet congurations with all-copper

orupto four ber-optical interfaces. These interfaces can be changed between

copper and ber-optic without changing components.

Features

• Increased scalability for demanding

TCP/IP environments

• No outage or reconnect required upon a

portfailure

• Flexible speed and cabling options

Data sheet

HP NonStop G16SE

High-bandwidth and fault-tolerant communications

Data sheet | HP NonStop G16SE

Key features and benets

• One model with a variety of conguration and cabling options

• Dynamic adjustment to network trac characteristics

• Enhanced TCP/IP support with up to 80,000 UDP/TCP connections per adapter

• Congurable MAC to override auto-negotiation settings (UTP cabling only)

• Application-compatible with previous Ethernet adapters for a smooth migration

• Support for multiple protocols (TCP/IP, IPX/SPX, Expand/IP, PAM, and SNAX over Ethernet)

A NonStop NB54000c or a NonStop NB56000c system with two c7000 blade enclosures

supports up to six G16SEs per system. For a system with only one c7000 blade enclosure,

youcan install up to four G16SEs per system.

If your NonStop system does not have a pair of IP or Telco CLIMs, two 10/100 Ethernet

ports on the rst G16SE are needed for system maintenance communications. These ports

can be recongured for customer use if a pair of IP or Telco CLIMs is added to the system

later. Subsequent G16SE enclosures in the system have all 16 Ethernet ports available for

application use.

The Cable Management Panel (BL8153) is an important component of the overall G16SE

solution and provides clean and easy access to the Ethernet ports. This provides an elegant

cabling solution and allows for quick recongurations.

Flexibility and scalability

The NonStop G16SE product further increases the leadership role of NonStop systems by

oering unique conguration options. It can coexist with IP and Telco CLIMs for a more exible

environment. The NonStop G16SE installs and operates in conjunction with IP and Telco CLIMs,

thus maintaining your existing investment. 1GbE speeds are available on eight ports, for which

both UTP copper or multimode ber cabling is supported. As le size and transaction volume

increase, the NonStop G16SE provides the kind of scalability that keeps your system at pace

with the increased capacity.

Form factor 8U (two 4U modules)

Weight 136 lb (61.7 kg)

Dimensions (Inches: H x W x D) 13.8 x 19 x 29.37

Number of power plugs 4

Power supply plug type IEC 320 C14

Maximum watts RMS 652

NonStop system supported HP Integrity NonStop BladeSystem NB54000c and HP Integrity BladeSystem NB56000c

NonStop OS versions Release RVU is J06.15

Minimum RVU is J06.14 with required SPRs

Compliance with IEEE standards 10 megabits per second Ethernet: IEEE 802.3—10BASE-T CSMA/CD (Ethernet)

10/100 megabits per second Fast Ethernet: IEEE 802.3u—100BASE-TX Fast Ethernet with

auto-negotiation of speed

1000 megabits per second Gigabit Ethernet: IEEE 802.3ab—1000BASE-T Gigabit Ethernet and

IEEE802.3z—1000BASE-SX

IEEE 802.3x—Flow control in full-duplex Ethernet LANs

1000 megabits per second Gigabit Ethernet

Ethernet ports cabling requirements The procurement of cables is a customer responsibility. The G16SE uses the following standard cables that

can be purchased from third-party vendors:

• CAT 5, CAT 5e, or CAT 6 UTP (4 pairs)

• 850 nm 50/125 μm multimode ber

Connectors Standard RJ-45 pin-out connector

Standard LC duplex connector

Specications

Data sheet | HP NonStop G16SE

Rate this documentShare with colleagues

hp.com/go/getupdated

HP Technology Services

HP Technology Services help build an infrastructure that is reliable, highly available and

rootedin best practices. We oer a support experience that is proactive, personalized and

simplied—delivering support when and how you need. HP recommends the following services

for NonStop servers:

HP Critical Service: High performance reactive and proactive support designed to

minimize downtime. It oers an assigned support team which includes an Account Support

Manager(ASM). This service oers access to HP’s Global Mission Critical Solution Center,

24x7 HW and SW support, 6-hour Call-to-Repair commitment, enhanced parts inventory and

accelerated escalation management.

HP Proactive 24: Provides proactive and reactive support delivered under the direction of

an ASM. It oers 24x7 HW support with 4 hour onsite response, 24x7 SW support with 2 hour

response and exible call submittal.

HP Installation and Start-up Services: This service provides ecient and eective

deployment of HP hardware components.

For more information on Support Services for NonStop servers, click here.

Learn more at

hp.com/go/nonstop

warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein

should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

4AA4-8001ENW, August 2013
