HP Compaq 6715b Manuale utente

External Devices

User Guide

Development Company, L.P.

Windows is a U.S. registered trademark of

Microsoft Corporation.

The information contained herein is subject

to change without notice. The only

warranties for HP products and services are

set forth in the express warranty statements

accompanying such products and services.

Nothing herein should be construed as

constituting an additional warranty. HP shall

not be liable for technical or editorial errors

or omissions contained herein.

First Edition: March 2007

Document Part Number: 435746-001

Product notice

This user guide describes features that are common to most models. Some features may not be

available on your computer.

ENWW iii

iv Product notice ENWW

Table of contents

1 Using a USB device

Connecting a USB device .................................................................................................................... 2

Stopping a USB device ........................................................................................................................ 2

USB legacy support .............................................................................................................................. 2

2 Using a 1394 device (select models only)

Connecting a 1394 device .................................................................................................................... 5

Stopping a 1394 device ........................................................................................................................ 5

3 Using the docking connector (select models only)

Index ..................................................................................................................................................................... 7

ENWW v

vi ENWW

1 Using a USB device

Universal Serial Bus (USB) is a hardware interface that can be used to connect an optional external

device, such as a USB keyboard, mouse, drive, printer, scanner, or hub. Devices can be connected to

the computer or an optional docking device.

Some USB devices may require additional support software, which is usually included with the device.

For more information about device-specific software, refer to the manufacturer's instructions.

Depending on the model, the computer may have up to 4 USB ports, which support USB 1.0, USB 1.1,

and USB 2.0 devices. An optional docking device or USB hub provides additional USB ports that can

be used with the computer.

ENWW 1

Connecting a USB device

CAUTION: To prevent damage to a USB connector, use minimal force to connect a USB

device.

To connect a USB device to the computer, connect the USB cable for the device to the USB port. You

will hear a sound when the device has been detected.

NOTE: The first time you connect a USB device, the “Found New Hardware” message is

displayed in the notification area, at the far right of the taskbar.

Stopping a USB device

CAUTION: To prevent loss of information or an unresponsive system, stop the USB device

before removing it.

CAUTION: To prevent damage to a USB connector, do not pull on the cable to disconnect the

USB device.

To stop a USB device:

1. Double-click the Safely Remove Hardware icon in the notification area, at the far right of the

taskbar.

NOTE: To display the Safely Remove Hardware icon, click the Show Hidden Icons icon

(<or <<) in the notification area.

2. Click the name of the device in the list.

NOTE: If the USB device is not listed, you do not have to stop the device before you

remove it.

3. Click Stop, and then click OK.

USB legacy support

USB legacy support (enabled by default) allows you to

●Use a USB keyboard, mouse, or hub connected to a USB port on the computer during startup or

in a non Windows® program or utility.

●Start or restart from an optional external MultiBay or an optional USB bootable device.

USB legacy support is enabled at the factory. To disable or enable USB legacy support:

1. Open Computer Setup by turning on or restarting the computer, and then pressing f10 while the

“F10 = ROM Based Setup” message is displayed in the lower-left corner of the screen.

2. Use the arrow keys to select System Configuration > Device configurations, and then press

enter.

2 Chapter 1 Using a USB device ENWW

3. Use the arrow keys to enable or disable USB legacy support, and then press f10.

4. To save your preferences and exit Computer Setup, use the arrow keys to select File > Save

changes and exit. Then follow the instructions on the screen.

Your preferences go into effect when the computer restarts.

ENWW USB legacy support 3

2 Using a 1394 device (select models

only)

IEEE 1394 is a hardware interface that can be used to connect a high-speed multimedia or data storage

device to the computer. Scanners, digital cameras, and digital camcorders often require a 1394

connection.

Some 1394 devices may require additional support software, which is usually included with the device.

For more information about device-specific software, refer to the user guide for the device.

The 1394 port, illustrated below, also supports IEEE 1394a devices.

4 Chapter 2 Using a 1394 device (select models only) ENWW
