HP Compaq Presario Manuale
Maintenance and Service
Guide
HP Pavilion ze2200 Notebook PC
Compaq Presario M2200 Notebook PC
Document Part Number: 383111-001
June 2005
This guide is a troubleshooting reference used for maintaining
and servicing the notebook. It provides comprehensive
information on identifying notebook features, components, and
spare parts; troubleshooting notebook problems; and performing
notebook disassembly procedures.
✎The information and procedures included in this
Maintenance
and Service Guide
apply to all Compaq Presario M2200
Notebook PC models and to the following HP Pavilion ze2200
Notebook PC models:
■ze2201AP
■ze2201XX
■ze2202AP
■ze2203AP
■ze2204AP
■ze2205AP
■ze2206AP
■ze2207AP
■ze2208AP
■ze2209AP
■ze2209XX
■ze2210AP
■ze2211AP
■ze2250EA
■ze2281EA
To verify the applicability of spare parts kits to HP Pavilion ze2200
Notebook PC models, visit the HP Parts Surfer Web site at
http://partsurfer.hp.com/cgi-bin/spi/main.
© Copyright 2005 Hewlett-Packard Development Company, L.P.
Microsoft and Windows are U.S. registered trademarks of Microsoft
Corporation. Intel, Pentium, Celeron, and Centrino are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United
States and other countries. Bluetooth is a trademark owned by its proprietor
and used by Hewlett-Packard Company under license.
The information contained herein is subject to change without notice. The
only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing
herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.
Maintenance and Service Guide
HP Pavilion ze2200 Notebook PC
Compaq Presario M2200 Notebook PC
Second Edition June 2005
First Edition February 2005
Document Part Number: 383111-001
Maintenance and Service Guide iii
Contents
1 Product Description
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
1.2 Resetting the Notebook . . . . . . . . . . . . . . . . . . . . . . . 1–4
1.3 Power Management. . . . . . . . . . . . . . . . . . . . . . . . . . 1–5
1.4 External Components . . . . . . . . . . . . . . . . . . . . . . . . 1–6
1.5 Design Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . 1–32
2 Troubleshooting
2.1 Computer Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Accessing Computer Setup . . . . . . . . . . . . . . . . . . . . 2–2
Computer Setup Defaults . . . . . . . . . . . . . . . . . . . . . 2–3
Selecting from the Main Menu . . . . . . . . . . . . . . . . . 2–4
Selecting from the Security Menu . . . . . . . . . . . . . . 2–4
Selecting from the Advanced Menu . . . . . . . . . . . . . 2–5
Selecting from the Tools Menu. . . . . . . . . . . . . . . . . 2–5
2.2 Troubleshooting Flowcharts . . . . . . . . . . . . . . . . . . . 2–7
3 Illustrated Parts Catalog
3.1 Serial Number Location . . . . . . . . . . . . . . . . . . . . . . 3–1
3.2 Notebook Major Components. . . . . . . . . . . . . . . . . . 3–2
3.3 Miscellaneous Plastics Kit . . . . . . . . . . . . . . . . . . . 3–14
iv Maintenance and Service Guide
Contents
3.4 Mass Storage Devices . . . . . . . . . . . . . . . . . . . . . . . 3–16
3.5 Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–18
3.6 Sequential Part Number Listing . . . . . . . . . . . . . . . 3–19
4 Removal and Replacement Preliminaries
4.1 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1
4.2 Service Considerations . . . . . . . . . . . . . . . . . . . . . . . 4–2
Plastic Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–2
Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . 4–2
4.3 Preventing Damage to Removable Drives . . . . . . . . 4–3
4.4 Preventing Electrostatic Damage . . . . . . . . . . . . . . . 4–4
4.5 Packaging and Transporting Precautions . . . . . . . . . 4–5
4.6 Workstation Precautions . . . . . . . . . . . . . . . . . . . . . . 4–6
4.7 Grounding Equipment and Methods . . . . . . . . . . . . . 4–6
5 Removal and Replacement Procedures
5.1 Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2
5.2 Disassembly Sequence Chart . . . . . . . . . . . . . . . . . . 5–3
5.3 Preparing the Notebook for Disassembly . . . . . . . . . 5–5
5.4 Hard Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–6
5.5 Notebook Feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–10
5.6 Optical Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–11
5.7 Memory Module . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–13
5.8 Mini PCI Communications Card. . . . . . . . . . . . . . . 5–16
5.9 Keyboard Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–19
Contents
Maintenance and Service Guide v
5.10 LED Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–22
5.11 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–24
5.12 Display Assembly . . . . . . . . . . . . . . . . . . . . . . . . . 5–28
5.13 Base Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–33
5.14 RTC Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–39
5.15 Speaker Assembly. . . . . . . . . . . . . . . . . . . . . . . . . 5–41
5.16 Heat Sink. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–43
5.17 Fan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–45
5.18 Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–47
5.19 Battery Connector Board. . . . . . . . . . . . . . . . . . . . 5–49
5.20 Power Connector Board . . . . . . . . . . . . . . . . . . . . 5–52
5.21 USB/S-Video Controller Board . . . . . . . . . . . . . . 5–54
5.22 Bluetooth Board . . . . . . . . . . . . . . . . . . . . . . . . . . 5–56
5.23 System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–58
6 Specifications
vi Maintenance and Service Guide
Contents
A Connector Pin Assignments
B Power Cord Set Requirements
3-Conductor Power Cord Set . . . . . . . . . . . . . . . . . . . . . . B–1
General Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . B–2
Country-Specific Requirements . . . . . . . . . . . . . . . . . . . . B–3
C Screw Listing
Index
Maintenance and Service Guide 1–1
1
Product Description
The HP Pavilion ze2200 Notebook PC 1and the
Compaq Presario M2200 Notebook PC 2offer advanced
modularity, Intel® Mobile Pentium® M and Celeron® M
processors, and extensive multimedia support.
HP Pavilion ze2200 and Compaq Presario M2200
1–2 Maintenance and Service Guide
Product Description
1.1 Features
✎Numerous references are made throughout this Maintenance and
Service Guide to “full-featured” and “defeatured” notebook
models. A model is considered to be full-featured if it has
3 Universal Serial Bus ports and the following components:
■S-Video-out jack
■Expansion port 2
■6-in-1 Digital Media Slot or 6-in-1 Memory Reader
A notebook model is considered to be defeatured if it has only
2 Universal Serial Bus ports and none of the components in the
preceding list.
■The following processors are available, varying by
notebook model:
❏Intel Pentium M 745 (1.8-GHz) with 400-MHz
front side bus (FSB)
❏Intel Pentium M 735 (1.7-GHz) with 400-MHz FSB
❏Intel Pentium M 725 (1.6-GHz) with 400-MHz FSB
❏Intel Pentium M 715A (1.5-GHz) with 400-MHz FSB
❏Intel Celeron M 360 (1.4-GHz) with 400-MHz FSB
❏Intel Celeron M 350 (1.3-GHz) with 400-MHz FSB
✎Full-featured models feature both Intel Pentium M and
Celeron M processors. Defeatured models feature only
Celeron M processors.
Product Description
Maintenance and Service Guide 1–3
■15.0-inch XGA (1024 × 768) TFT display with over
16.7 million colors
■80-, 60-, or 40-GB high-capacity hard drive, varying by
notebook model
■256-MB DDR2 synchronous DRAM (SDRAM) at 400 MHz,
expandable to 1.0 GB
■Microsoft® Windows® XP Home Edition or Windows XP
Professional, varying by notebook model
■Full-size Windows keyboard with embedded numeric keypad
■TouchPad pointing device with dedicated vertical scroll
region
■Integrated 10Base-T/100 Base-TX Ethernet local area
network (LAN) network interface card (NIC) with RJ-45 jack
■Integrated high-speed 56K modem with RJ-11 jack
■Integrated wireless support for Mini PCI IEEE 802.11b and
802.11b/g WLAN device
■Support for one Type II PC Card slot, with support for both
32-bit (CardBus) and 16-bit PC Cards
■External 65-watt AC adapter with 3-wire power cord
■6-cell or 12-cell Li-Ion battery pack
■Stereo speakers with volume up and down buttons
■Support for the following optical drives:
❏8X DVD-ROM Drive
❏24X DVD/CD-RW Combo Drive
❏8X DVD±RW/R and CD-RW Combo Drive
❏24X CD-ROM Drive (Compaq Presario M2200
notebooks only)
1–4 Maintenance and Service Guide
Product Description
■Connectors:
❏External monitor port
❏Universal Serial Bus (USB) v. 2.0 (up to 3 ports)
❏RJ-11 (modem) jack
❏RJ-45 (network) jack
❏Audio-out (headphone) jack
❏Audio-in (microphone) jack
❏Power
❏IEEE 1394 digital port
❏S-Video-out jack (select models only)
❏Expansion port 2 (select models only)
❏6-in-1 Digital Media Slot (select models only)
❏6-in-1 Memory Reader (select models only)
1.2 Resetting the Notebook
If the notebook you are servicing has an unknown password,
follow these steps to clear the password. These steps also
clear CMOS:
1. Prepare the notebook for disassembly (refer to Section 5.3,
“Preparing the Notebook for Disassembly,” for more
information).
2. Remove the real-time clock (RTC) battery (refer to
Section 5.14, “RTC Battery,” for more information).
3. Wait approximately 5 minutes.
4. Replace the RTC battery and reassemble the notebook.
5. Connect AC power to the notebook. Do not reinsert any
battery packs at this time.
6. Turn on the notebook.
All passwords and all CMOS settings have been cleared.
