HP Pavilion dv2000 - Entertainment Notebook PC Manuale utente

Notebook Tour

User Guide

Development Company, L.P.

Microsoft and Windows are U.S. registered

trademarks of Microsoft Corporation.

Bluetooth is a trademark owned by its

proprietor and used by Hewlett-Packard

Company under license. SD Logo is a

trademark of its proprietor.

The information contained herein is subject

to change without notice. The only

warranties for HP products and services are

set forth in the express warranty statements

accompanying such products and services.

Nothing herein should be construed as

constituting an additional warranty. HP shall

not be liable for technical or editorial errors

or omissions contained herein.

First Edition: May 2006

Document Part Number: 411669-001

Table of contents

1 Components

Top components ................................................................................................................................... 2

TouchPad ............................................................................................................................ 2

Lights ................................................................................................................................... 3

Buttons, switches, and speakers ......................................................................................... 6

Keys ..................................................................................................................................... 9

Hotkey quick reference ...................................................................................................... 10

Front components .............................................................................................................................. 11

Rear components ............................................................................................................................... 12

Right-side components ....................................................................................................................... 13

Left-side components ......................................................................................................................... 14

Bottom components ........................................................................................................................... 16

Display components ........................................................................................................................... 17

Wireless antennae (select models only) ............................................................................................. 18

Additional hardware components ....................................................................................................... 19

Labels ................................................................................................................................................. 20

2 Specifications

Operating environment ....................................................................................................................... 21

Rated input power .............................................................................................................................. 22

Index ................................................................................................................................................................... 23

ENWW iii

iv ENWW

1 Components

This chapter explains the hardware features of the computer.

To see a list of hardware installed in the computer:

1. Select Start > My Computer.

2. In the left pane of the System Tasks window, select View system information.

3. Select Hardware tab > Device Manager.

You can also add hardware or modify device configurations using Device Manager.

NOTE Components included with the computer may vary by region and by model. The

illustrations in this chapter identify the standard features included in most computer models.

ENWW 1

Top components

TouchPad

Component Description

(1) TouchPad light Blue: TouchPad is enabled.

Amber: TouchPad is disabled.

(2) TouchPad* Moves the pointer and selects or activates items on

the screen.

(3) Left TouchPad button* Functions like the left button on an external mouse.

(4) Right TouchPad button* Functions like the right button on an external

mouse.

(5) TouchPad scroll zone* Scrolls up or down.

(6) TouchPad on/off button Enables/disables the TouchPad.

*This table describes factory settings. To view and change pointing device preferences, select Start

> Control Panel > Printers and Other Hardware > Mouse.

2 Chapter 1 Components ENWW

Lights

NOTE Refer to the illustration that most closely matches your computer.

Component Description

(1) Power lights (2)* On: The computer is on.

Blinking: The computer is in standby.

Off: The computer is off or in hibernation.

(2) Battery light On: A battery is charging.

Blinking: A battery that is the only available power source has reached a low-

battery condition. When the battery reaches a critical low-battery condition, the

battery light begins blinking rapidly.

Off: If the computer is plugged into an external power source, the light is turned

off when all batteries in the computer are fully charged. If the computer is not

plugged into an external power source, the light stays off until the battery

reaches a low-battery condition.

(3) Drive light Blinking: The hard drive or optical drive is being accessed.

(4) Caps lock light On: Caps lock is on.

(5) Media button light Blinks once: The media button has been pressed.

(6) DVD button light Blinks once: The DVD button has been pressed.

(7) Previous/rewind light Blinks once: The previous/rewind button has been pressed.

(8) Play/pause light Blinks once: The play/pause button has been pressed.

(9) Next/fast forward light Blinks once: The next/fast forward button has been pressed.

(10) Stop light Blinks once: The stop button has been pressed.

(11) Volume mute light Blue: Computer sound is turned on.

ENWW Top components 3

Component Description

Amber: Computer sound is turned off.

(12) Volume down light Blinking: The volume scroll zone is being used to decrease speaker volume.

(13) Volume up light Blinking: The volume scroll zone is being used to increase speaker volume.

(14) Num lock light On: Num lock is on or the embedded numeric keypad is enabled.

There are 2 power lights. Both display the same information. The light on the power button is visible only when the computer

is open; the other power light is always visible on the front of the computer.

Component Description

(1) Power lights (2)* On: The computer is on.

Blinking: The computer is in standby.

Off: The computer is off or in hibernation.

(2) Battery light On: A battery is charging.

Blinking: A battery that is the only available power source has reached a low-

battery condition or acritical low-battery condition.

Off: If the computer is plugged into an external power source, the light is turned

off when all batteries in the computer are fully charged. If the computer is not

plugged into an external power source, the light stays off until the battery

reaches a low-battery condition.

(3) Drive light Blinking: The hard drive or optical drive is being accessed.

(4) Caps lock light On: Caps lock is on.

(5) Media button light Blinks once: The media button has been pressed.

(6) Volume mute light Blue: Computer sound is turned on.

4 Chapter 1 Components ENWW

Component Description

Red: Computer sound is turned off.

(7) Volume down light Blinking: The volume scroll zone is being used to decrease speaker sound.

(8) Volume up light Blinking: The volume scroll zone is being used to increase speaker sound.

(9) Num lock light Blinking: Num lock is on or the embedded numeric keypad is enabled.

There are 2 power lights. Both display the same information. The light on the power button is visible only when the computer

is open; the other power light is always visible on the front of the computer.

ENWW Top components 5

Buttons, switches, and speakers

NOTE Refer to the illustration that most closely matches your computer.

Component Description

(1) Power button* When the computer is

●Off, press to turn on the computer.

●On, press to enter hibernation.

●In standby, briefly press to exit standby.

●In hibernation, briefly press to exit hibernation.

If the computer has stopped responding and Microsoft® Windows® shutdown

procedures cannot be used, press and hold the power button for at least 5

seconds to turn off the computer.

(2) Speakers (2) Produce sound.

(3) Media button If QuickPlay is not installed and the computer is

●On, the media opens the music program or Media menu, allowing you to

select a multimedia program.

●Off, the media button does not function.

●In standby, the media button resumes from standby into Windows.

If QuickPlay is installed and the computer is

●On, the media button opens the music program or Media menu, allowing

you to select a multimedia program.

●Off, the media button opens the music program or the Media menu,

allowing you to select a multimedia program.

●In standby, the media button resumes from standby into Windows.

6 Chapter 1 Components ENWW
