HP ProLiant

Storage Server release notes

These release notes cover HP ProLiant Storage Servers running editions of Microsoft® Windows Storage Server 2003 R2

or Microsoft® Windows® Uniﬁed Data Storage Server 2003. For storage servers running Windows Storage Server

2003 SP1, see the HP ProLiant release notes, part number 379129–401.

Part number: 5697-6313

First edition: February 2007

Description

These release notes cover HP ProLiant Storage Servers running editions of Microsoft® Windows Storage

Server2003R2orMicrosoft®Windows®Uniﬁed Data Storage Server 2003. For storage servers

running Windows Storage Server 2003 SP1 or lower, see the HP ProLiant release notes, part number

379129–401.

Update recommendation Recommended

Supersedes These release notes supersede part number 5697–6073, published in October 2006.

Product models

Thefollowingtableidentiﬁes HP ProLiant Storage Servers that are capable of being upgraded to

Windows Storage Server 2003 R2. All four versions of the Service Pack 1 editions (Express, Workgroup,

Standard and Enterprise) can be upgraded to their R2 equivalents. In addition, the R2 edition of the

Workgroup operating system can be upgraded to the R2 edition of the Standard operating system.

Table 1 Servers eligible for upgrade to WSS 2003 R2

Upgrade OS HP ProLiant storage server

WSS 2003 R2 Express OS •ML110G2(320GBonly)

WSS 2003 R2 Workgroup OS •DL100 G2

•ML110 G2

•ML310 G3

WSS2003R2StandardOS •DL100

•DL100 G2 File-Print Appliance ( 640GB only)

•DL100 G2 DPSS

•ML110

•ML310 G3 DPSS

•ML350 G4

•ML350 G4p

•ML350 G5

•ML370 G4

•DL380 G3

•DL380 G4

•DL380 G4 DPSS

•DL380 G5

•DL380 G5 DPSS

•StorageWorks NAS 1500s

•StorageWorks NAS 2000s

WSS 2003 R2 Enterprise OS •DL380G3(SANGatewayonly)

•DL380G4(SANGatewayonly)

•DL380G5(SANGatewayonly)

•DL580 G2

•DL585

•StorageWorks NAS 4000s

•StorageWorks NAS 9000s

Operating systems

Microsoft® Windows® Storage Server 2003 R2

Storage Server release notes 3

Microsoft® Windows® Uniﬁed Data Storage Server 2003

Languages

When the Microsoft Multilingual User Interface (MUI) is installed on the HP ProLiant Storage Server,

the following languages are available:

•French

•Italian

•German

•Japanese

•Korean

•Simpliﬁed Chinese

•Spanish

•Traditional Chinese

Issues and workarounds

Issues and their workarounds have been identiﬁed and placed into categories. These categories are:

•MicrosoftWindowsServer2003R2, page 4

• HP Storage Server Management console user interface,page4

•Conﬁguration,page6

•Additional applications and utilities,page6

• System installation and recovery process,page7

Microsoft Windows Storage Server 2003 R2

This section describes issues related to Microsoft Windows Storage Server 2003 R2.

Microsoft Windows Storage Server 2003 R2

Issue: Bugcheck 0x50 (PAGE_FAULT_IN_NONPAGED_AREA) in next boot after disabling Multipath

Support

Description Using the Microsoft Device Manager to disable the HP MPIO driver and rebooting

the system causes the system to continuously reboot. After successfully installing

the MPIO and DSM for MSA/EVA/XP, right-click and disable Multipath Support

from Device Manager and reboot the system. During the next boot, the system

bugchecks with bugcheck code 0x50 when coming up. The issue occurs because

the DSM uses MPIO export DsmGetVersion. This call is made even before the DSM

registers with MPIO. Since MPIO is disabled, DsmGetVersion is not available,

and the system bugchecks. The uninstall driver selection under Device Manager

works ﬁne.

Workaround Bring up the Safe Mode menu using F8 during the reboot sequence. Select Last

Known Good Conﬁguration to recover the system, or boot into the recovery console

and disable the DSM service.

HP Storage Server Management console user interface

This section describes issues with the user interface for the HP Storage Server Management console.

HP Storage Server Management console user interface

Issue: HP Storage Server Management console stops responding after cancelling

Install SIS

HP Storage Server Management console user interface

Description After selecting HP Storage Server Management > Storage Management > Single

Instance Storage, the management console sometimes stops responding after

performing the following steps:

1. Click on any data volume that does not have Single Instance Storage installed.

2. Select the InstallSISactionfromtheActionspaneorfromtheright-clickmenu.

3. Click No when prompted about whether or not to continue.

Workaround If the console is unresponsive, do the following:

1. Run Task Manager (select Start,thenRun,andtypetaskmgr.exe).

2. Select the Applications tab.

3. Select HP Storage Server Management.

4. Click the End Task button.

5. Click End Now when prompted.

Issue: While connected to the HP Storage Server Management console using the web browser method,

an error is shown if the user tries to open a shared folder

Description While connected using the web browser method (http://machine-name:3201

or https://machine-name:3202), if the user navigates to HP Storage Server

Management > Share Folder Management > Shared Folders, right-clicks on a

shared folder, and selects Open, an error is shown. In addition, the desktop icons,

start menu, and task bar appear on the screen. This is because the action of

opening a shared folder depends on the Windows shell, which is not running by

default while connected through a web browser.

Workaround ConnectdirectlytothestorageserverorviaRemoteDesktop.

Issue: The pie chart under HP Storage Server Management > Storage Management may indicate a

larger amount of disk space than actually exists

Description This issue may occur if both of the following are true:

•A hard quota is set and enabled on the root folder of one or more volumes.

•A volume with a hard quota on the root folder also has Single Instance Storage

(SIS) enabled.

This is due to an interoperability issue between directory quotas and SIS.

Workaround Disable the hard quota on the root folder of the volume, or change the hard quota

to be a soft quota.

Issue: Adding multiple instances of the HP Storage Server Management snap-in to one console causes

information to display incorrectly

Description If multiple instances of the HP Storage Server Management snap-in are added

to one console, all instances will reﬂect information about only the ﬁrst server

speciﬁed.

Workaround Open a new MMC console for each instance of the snap-in.

Issue: The Storage Server and Microsoft MMC quota plug-in fail when creating a new quota

Description When creating a new quota using the HP Storage Server Management

console, the creation may fail with the event log message: A File Server

Resource Manager configuration file or import-export file

is corrupted. If the corrupt file is a configuration file,

it is required that the system or volume be restored from

backup. If the file is an import-export file, export the

items again and retry the operation without editing the

file contents.

Storage Server release notes 5

HP Storage Server Management console user interface

Workaround If the volume has existing quotas, recover the volume from backup. If the volume

does not have existing quotas, use an Administrator login to rename the <Drive

Letter>:\System Volume Information\SRM\quota.xml ﬁle and try to

create the quotas again. Recover from backup if the creation continues to fail.

Issue: After installing a Multilingual User Interface (MUI), the HP Storage Server Management console

might incorrectly display unsupported MMC snap-ins

Description On the ﬁrst reboot after installing a new MUI from the HP Localization Kit onto an

HP ProLiant Storage Server, the HP Storage Server Management console might

display the Data Protection and Clustered Gateway Management MMC snap-ins,

which are not supported.

Workaround There are two workarounds for this issue:

•Reboot the server.

1. Close the HP Storage Server Management console.

2. Restart the HP Storage Server Management service.

3. Reopen the HP Storage Server Management console.

Issue: Creating quotas on a newly-installed cluster might cause File Server Resource Manger to fail

with an unexpected error

Description After creating a cluster, if you try to create a quota using the HP Storage Server

Management console (Storage Management > Share and Storage Management

>FileSe

rver Resource Manager > Quota Management > Quotas), the Quota

Creation window might not open, the File Server Resource Manager will fail with

the message An unexpected error occurred,andanentrywillbeadded

to the event logs.

Workaround 1. Close the HP Storage Server Management console.

2. Restart the File Server Resource Manager service.

3. Reopen the HP Storage Server Management console.

Conﬁguration

This section provides additional information on conﬁguring your storage server.

Conﬁguration

Issue: DL320s hardware RAID conﬁguration omitted from documentation

Description ThehardwareRAIDconﬁguration information for the DL320s model was omitted

from the HP ProLiant Storage Server User Guide.

Workaround ThehardwareRAIDconﬁguration for the DL320s is as follows:

•Logical Disk 1 — Operating System Volume, RAID 1, Physical Drives 0–1

•Logical Disk 2 — DON’T ERASE Volume, RAID 1, Physical Drives 0–1

•Logical Disk 3 – n — Data Volume, RAID 5 (SAS models) RAID 6 (SATA

models), Physical Drives 2–11

Additional applications and utilities

This section provides additional information on using certain applications and utilities on the storage

server.

Additional applications and utilities

Issue: JRE-dependent applications or web sites prompt for JVM installation, or it is not properly

displayed

Description A web site or application that is dependent on Java Virtual Machine (JVM) is not

displayed properly with Internet Explorer. A message prompts you to install JVM.

Workaround Uninstall the Java Runtime Environment (JRE) using the Control Panel and Add or

Remove Programs. Reinstall the JRE from the c:\hpnas\components\JRE

folder.

Issue: VDS provider for MSA does not refresh after volume creation fails

Description Creating a LUN and volume using the Create a New LUN wizard using Storage

Manager for SAN results in the volume creation failing and displays a warning

icon on the created volume in the Storage Manager for SAN user interface.

The warning icon continues to display even after closing and re-opening the HP

Storage Server Management console. Attempting to delete the LUN results in the

Storage Manager for SAN user interface becoming unresponsive and unable to

proceed past the delete LUN dialog box.

Workaround Do one of the following:

•Restart the system to load the LUNs and to refresh Storage Manager for SAN.

•Use the Array Conﬁguration Utility (ACU) to create the LUN on the MSA, and

then use the Disk Manager utility on the Windows storage server to create

the LUN volume.

Issue: Storage Manager for SAN stops responding when Subsystem is selected

Description When Subsystem is clicked in Storage Manager for SAN, the system stops

responding and displays the message MMC has detected an error in a

snap-in and will unload it.Thisbehaviorisseenonlywhenanyofthe

MSA subsystem volumes are being expanded.

Workaround Use the Array Conﬁguration Utility (ACU) to access the MSA subsystem when

volumes are being expanded.

Issue: NfsSvr logs an error in the event log

Description On systems with Windows Storage Server 2003 R2, the event log may contain an

error stating that Server for NFS failed to initialize on a non-existent drive letter.

For example:

Event Type: ErrorEvent

Source: NfsSvr

Event Category: None

Event ID: 1066

Description: Server for NFS failed to initialize

on volume with drive letter F:

Workaround This error does not affect the performance of NFS. The issue will be resolved in a

later HP ProLiant Storage Server release.

System installation and recovery process

This section describes issues related to installing the operating system on a storage server or performing

the recovery process.

Storage Server release notes 7

System installation and recovery process

Issue: After restoring the system with the System Installation and Recovery DVD, the data drive may be

seenbyWindowsasaforeigndisk

Description If the data drive was a dynamic disk prior to performing a system recovery, the

disk may be designated as a foreign disk by Windows after the recovery. This

issue is seen in the Disk Management MMC snap-in.

Workaround Open the Disk Management snap-in. Right-click on the foreign disk and select

Import disk.

Installation instructions

To complete the conﬁguration of storage servers, see the HP ProLiant Storage Server User Guide.To

upgrade a storage server to Windows Storage Server 2003 R2, see the HP ProLiant Windows Storage

Server 2003 R2 upgrade guide.

Effective date

February 12, 2007

Altri manuali per DL320s - ProLiant 9TB SATA Storage Server...

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali HP Server di archiviazione di rete

HP ProLiant ML350 G4p Manuale utente

HP EX495 - 1.5TB Mediasmart Home Server Istruzioni per l'installazione

HP AH809B Guida all'installazione

HP ProLiant DL38 Manuale utente

HP X300 Data Vault Guida all'installazione

HP ML350 - ProLiant - G2 Manuale utente

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuale utente

HP 3PAR StoreServ 7000 Manuale utente

HP ProLiant Server Manuale dell'operatore

HP ProLiant ML310 G3 1TB Manuale utente

HP StorageWorks NAS 500s Manuale di servizio

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Istruzioni per l'installazione e il funzionamento

HP ProLiant DL585 Manuale utente

HP 3PAR StoreServ 7000 Manuale utente

HP 201723-B21 - HP StorageWorks Modular SAN Array 1000 Hard... Manuale utente

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuale utente

HP J3278B - SureStore CD-ROM Server/Tower 7 NAS... Manuale di istruzioni

HP NetStorage 6000 Guida rapida

HP ProLiant DL380 G4 DPSS Manuale utente

HP NetStorage 6000 Manuale utente

HP ProLiant ML350 G5 Manuale utente

HP ML110 - ProLiant G5 2TB Storage Server NAS Come usare

HP NetStorage 6000 Manuale di istruzioni

HP ProLiant ML350 G5 Manuale di istruzioni

Manuali Server di archiviazione di rete popolari di altre marche

Seagate

Seagate U10 ST320423A Manuale utente

Synology

Synology RackStation RS816 Manuale

D-Link

D-Link ShareCenter Pro DNS-1200-05 Manuale utente

Avid Technology

Avid Technology VideoRAID ST Guida di sicurezza

Western Digital

Western Digital My Cloud Home Duo Manuale utente

PrimeArray

PrimeArray 4xxx Manuale utente

Buffalo

Buffalo TeraStation WSS WSH5010N6 Manuale utente

Planex

Planex MZK-NAS01SG Manuale utente

Intel

Intel SS4000-E - Entry Storage System NAS Server Manuale utente

Synology

Synology RS2212+ Manuale utente

Allnet

Allnet ALL69000 Manuale utente

Adaptec

Adaptec 5325301580 Manuale utente

Motorola

Motorola EXORdisk II Manuale utente

Sony

Sony XDAAI1PK Manuale utente

Cisco

Cisco Linksys NAS200 Istruzioni operative originali

Sans Digital

Sans Digital MR4UT6G Manuale utente

AIC

AIC FB128-LX Manuale utente

Dell

Dell PowerVault NX3500 Istruzioni utente
