integration

hp StorageWorks NAS e7000 v2

what’s new

• new server platform based on

HP ProLiant DL 80 G2

• snapshot technology enabled

by Columbia Data Products

Persistent Storage Manager

• new web interface for

easy management

key features and beneﬁts

controllable

• NAS/SAN fusion: integrates ﬁle or

block data leads to increase efﬁciency

of the storage network

• manageable: provides a simpler

management of ﬁle or block level

data leads, decreasing costs for

storage management

• affordable: NAS/SAN fusion provides

a more efﬁcient storage architecture

resilient

• reliable: delivers experience critical

a successful, affordable optimized

NAS solution

extensible

• extensive: produces low-end,

remote/workgroup solutions that

consolidate fusion for the enterprise

• optimi ed: offers the right NAS

solution for each customer; there’s

no need to settle for trade-offs

The HP StorageWorks NAS e7000 v2

fuses NAS and storage area network

(SAN) technologies. This innovative

combination provides tremendous gains

in scalability and ﬂexibility.

The NAS e7000 provides the best return

on data center storage investment by

simplifying centralized storage and system

management, saving resources, time,

and lowering the total cost of ownership.

It limits the need for expensive and

complex integration and management

by connecting to the industry’s broadest

range of SAN arrays. The NAS e7000

provides support for: HP StorageWorks

Modular SAN Array 1000 (msa1000),

Virtual Array, Modular Array, Enterprise

Modular Array, Enterprise Virtual Array

(EVA), and Disk Array XP.

With virtually unlimited storage scalability,

the NAS e7000 grows as business needs

grow — without downtime and without

compromising performance. With no

single-point-of-failure, this NAS solution

ensures data is always available,

enabling business continuance through

cluster support, hardware redundancy

and replication.

The NAS e7000 provides the simplicity

of NAS with the scalability of SAN —

a fusion that sets new standards in

performance, ﬂexibility and consolidated

management.

hp StorageWorks NAS e7000 v2

hp StorageWorks

NAS e7000 v2 management

technical speciﬁcations

ﬁle protocol support CIFS, NFS, NCP, AppleTalk, HTTP, FTP

OS support Microsoft®Windows®2000 Advanced Server

dimensions (HxWxD) 6.94 x 19 x 26. in/17.6 x 48.3 x 67.3 cm

weight 66 lbs/29.9 kg

cache 2 MB battery backed cache

data transfer method Fibre Channel

drives supported 10K RPM universal hot-pluggable 18 GB, 36 GB, 72 GB, 146 GB drives

input requirements • nominal line voltage; 100 to 120 VAC/200 to 240 VAC

• range line voltage; 113 W @ 110 VAC/112 W @ 220 VAC

• line frequency; 0 to 60 Hz

• typical input current; 12A (100 VAC), 9.8A (120 VAC), 4.9A (220 VAC)

maximum number of drives dependent upon SAN array

power 800W/800W (lowline/highline)

reliability features redundant OS, redundant power supplies, hot-plug PCI

relative humidity (non-condensing) • operating; 10% to 70%

• shipping; % to 9 %

temperature range • operating; 0 to 9 ° F/10 to 3 ° C

• shipping; -22 to 122° F/-30 to 0° C

maximum BTUs 4000 BTU

maximum wet bulb temperature 101.7° F/38.7° C

ordering information

product number product name description

322310-001, 421 NAS e7000 v2 NAS head for installation with the SAN array

what’s included

• 2 x 36GB SCSI HD; 2 x Intel®Xeon Processors MP; HP Integrated Lights-Out Standard Management (iLO) on system board; 2048 MB RAM;

HP Advanced Memory Protection; six, full length 64-bit/100 MHz PCI-X slots, 4 hot-pluggable; Integrated NC7770 PCI- X Gigabit Server

Adapter in a slot; Integrated Smart Array i Plus Controller (Dual Channel, Ultra3); battery-backed write cache enabler module

• HP supplied software: Windows Powered OS; HP StorageWorks NAS Data Copy; CDP Persistent Storage Manager; Rapid Launch; Web

Based Conﬁguration Utility; Array Conﬁguration Utility; HP Insight Manager (CIM) WBEM Win32; HP Insight Manager base console;

Smart Start 6.x software drivers; SmartStart 6.x CD (utilities only) and Management 6.x CD; Windows Powered OS drivers, including Array

Controller driver and HBA drivers; Tivoli TME, HP OpenView, IBM Netview, CA Unicenter, BMC agents installed for Enterprise (SNMP)

Management; NIC Teaming Drivers; HP UPS; APC UPS; Quick Restore CD

The information in this document is

subject to change without notice.

Microsoft and Windows are U.S.

registered trademarks of Microsoft

Corporation. Intel is a registered

trademark of Intel Corporation. All

other product names mentioned

herein may be trademarks or

registered trademarks of their

respective companies.

Development Company, L.P.

2/2003

981- 714EN for more information

For more information on the HP StorageWorks NAS e7000, contact any of our worldwide sales ofﬁces or

visit our web site at: http://h18006.www1.hp.com/storage/networkattached.html

warranty and support

warranty features — warranty uplifts and HP CarePaq services are offered on all HP StorageWorks NAS products

hp service and support
