HP StorageWorks 8B - FC Entry Switch Manuale di istruzioni

release notes

version 3.0.1b

fabric os

www.hp.com

Notice

Edition: E1201

Hewlett-Packard Company makes no warranty of any kind with

regard to this material, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

This document contains proprietary information, which is protected

by copyright. No part of this document may be photocopied,

reproduced, or translated into another language without the prior

written consent of Hewlett-Packard. The information contained in

this document is subject to change without notice.

Use, duplication, or disclosure by government is subject to

restrictions as set forth in subdivision (c) (1) (ii) of the Rights in

Technical Data and Computer Software Clause at DFARS

252.227.7013.

Warranty

If you have any questions about the warranty for this product,

contact your dealer or local Hewlett-Packard sales representative.

Trademarks

BROCADE, the Brocade B weave logo, Brocade: the Intelligent

Platform for Networking Storage, SilkWorm, and SilkWorm

Express, are trademarks or registered trademarks of Brocade

Communications Systems, Inc. or its subsidiaries in the United

States and/or in other countries.

All other brands, product or service names are or may be trademarks

or service marks of, and are used to identify products of services of

their respective owners.

Safety notices

Any servicing, adjustment, maintenance, or repair must be

performed only by authorized service-trained personnel.

Fabric OS v3.0.1b Release Notes - iii

Contents

General Information

About This Release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Fibre Channel Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Getting Software Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

New Features and Enhancements

New Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

ISL Trunking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Advanced Performance Monitoring . . . . . . . . . . . . . . . . . . . 3

Speed Auto Negotiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Enhancements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Fabric Watch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Zoning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Management Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Web Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Telnet Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Documentation

MIB Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Fabric Watch Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Supporting Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Fabric OS v3.0.1b Release Notes - iv

Requirements and Compatibility

Fabric OS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Compatibility with Other Products. . . . . . . . . . . . . . . . . . . . 10

Standards Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Web Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Workstation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 10

HBA Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Limitations

Fabric Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Automated Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Telnet Configure Command . . . . . . . . . . . . . . . . . . . . . . . . . 12

Fabric OS v3.0.1b Release Notes - 1

General Information

About This Release

Fabric OS version 3.0.1b firmware runs and delivers the full potential of the FC Entry Switch 8B

and FC Switch 8B products. Both switches are 8-port, auto-sensing 2 Gb/Sec and 1 Gb/Sec Fibre

Channel switches.

Overview

This release note includes a brief description of the new features and enhancements made in

Fabric OS version 3.0.1b. For detailed information on the items included in this release note, refer

to the appropriate user’s guide or reference manual.

Note: The information in this document supersedes any information found in other v3.0

documentation.

Fibre Channel Standards

Information about Fibre Channel standards and Fibre Channel in general can be found on the Fibre

Channel Industry Association Web site, located at http://www.fibrechannel.com.

Getting Help

For the most current technical support information for the FC Entry Switch 8B and FC Switch 8B,

visit the HP Web site at http://www.hp.com/support/fc8B. This includes hardware and software

support, all repairs, and spare components.

Be prepared to provide the following information to the support personnel:

•Switch serial number

•Switch world wide name

•Output from the supportShow telnet command

•Detailed description of the problem

•Topology configuration

•Troubleshooting steps already performed

For detailed information on telnet commands, refer to the Fabric OS Reference Manual.

Fabric OS v3.0.1b Release Notes - 2

General Information

Getting Software Updates

For information on obtaining software updates contact your HP account representative.

Fabric OS v3.0.1b Release Notes - 3

New Features and Enhancements

New Features

ISL Trunking

Interswitch Link (ISL) Trunking is an optionally licensed product (Performance Upgrade (Option

001)) available on the FC Entry Switch 8B and FC Switch 8B products with Fabric OS

version 3.0.1b. ISL Trunking is managed using telnet commands or the Web Tools interface.

The ISL Trunking feature allows up to four ISLs, connections between two switches through an

Expansion Port (E_Port), to merge logically into a single link. When using ISL Trunking to

aggregate bandwidth of up to four ports, the throughput of the ISLs between switches in a fabric is

quadrupled. For example, at 2 Gb/Sec speeds, ISL Trunking delivers ISL throughput of up to 8

Gb/Sec.

ISL Trunking also supports high-bandwidth, large-scale Storage Area Networks (SANs) which

include core switches. ISL Trunking simplifies network design and reduces the cost of storage

management by optimizing bandwidth use and enabling load balancing of traffic at the frame-level.

For more information about ISL Trunking, refer to the ISL Trunking User’s Guide.

Advanced Performance Monitoring

The Performance Monitoring feature, previously available from the Performance View in Web

Tools, has been updated to include more functionality and is now called Advanced Performance

Monitoring. Advanced Performance Monitoring is an optionally licensed product (Performance

Upgrade (Option 001)) available on the FC Entry Switch 8B and FC Switch 8B products with

Fabric OS version 3.0.1b. The Performance Monitoring View is available from the Switch View,

and includes the following new features:

AL_PA Monitoring - Provides information regarding the number of CRC errors that occur in the

frames originated from each possible AL_PA attached to a specific port.

For each SID-DID pair, the following categories of information are available:

•CRC errors for the frames that has the SID-DID pair

•Fibre Channel words being transmitted from the port for the SID-DID pair

•Fibre Channel words being received by the port for the SID-DID pair

End-to-end Monitoring - Can be achieved by first configuring the SID-DID pair on which

monitoring needs to be performed. All ports in the SID-DID communication path in the fabric can

be used for the same monitoring purpose.

Fabric OS v3.0.1b Release Notes - 4

New Features and Enhancements

Frame Filtering Based Performance Monitoring - Provides frame statistics based on contents of

frame. The application of this monitoring can be used to collect statistics based on FC_Type,

Logical Unit Number (LUN), and read/write.

Reports - An existing report can be selected from a list of reports that are predefined. In some

cases, you can supply the object to be monitored and graphed.

Graphs - Graphs are displayed on a “canvas”, which can hold a maximum of 8 graphs

simultaneously.

•The collection of graphs in the canvas can be stored for later retrieval on the switch. Up to

20 individual canvases can be saved. Each canvas is saved with its name, a brief

description, and the graphs which comprise the canvas.

•Any graph can “zoom in”, or be magnified and detached from the main canvas, or

“removed” from the main canvas during a pop-up menu.

•Each graph can be printed to a specified printer.

For more detailed information, refer to the Advanced Performance Monitoring User’s Guide.

Speed Auto Negotiation

Speed Auto Negotiation is a new feature enabling a port to determine the highest common link

speed with another port, or set of ports, in fixed speed loop automatically. This feature is

implemented in accordance with FC-FS standard.

For more information, refer to the Fabric OS Reference Manual.

Enhancements

Fabric Watch

Classes

The following classes have been added in Fabric OS version 3.0.1b:

•AL_PA Performance Monitor Class - Monitors CRC errors on ALPA devices of Loop

ports.

•End-to-end Performance Monitor Class - Monitors transmitting performance, and

receiving performance errors and CRC errors of predefined SID-DID pairs.

•Filter-Performance Monitor Class - Monitors filter counter for a given port. Specific

filter counters such as SCSI read/write, are predefined through Advanced Performance

Monitoring.

Fabric Watch classes and areas are automatically loaded after the Fabric Watch license is installed.

Fabric OS v3.0.1b Release Notes - 5

New Features and Enhancements

Alarms

The following alarm notification methods have been added in Fabric OS version 3.0.1b:

•Email Alert - Sends alarms to pre-configured Email addresses.

•Remote Agent Notification (RAN) - Sends alarms to remote applications using Fabric

Access.

Zoning

The following features have been added to Zoning in Fabric OS version 3.0.1b:

•WWN Zoning can now be enforced through the hardware.

•Zoning hardware enforcement can now be implemented on a zone by zone basis at the

port level.

For more information, refer to the Zoning User’s Guide.

Management Server

Management Server now uses Topology Discovery during the fabric topology discovery process.

The process involves two standards: FC-FS and FC-GS3.

•RTIN/RNID queries from FC-FS: Request Node Identification Data and Request

Topology Information are now supported.

•GATIN/GNID/GTIN from FC-GS3: Get Attributes of Topology Information/Get Node

Identification Data/ Get Topology Information are now supported.

Web Tools

The following views, tabs, and features have been added or modified in Web Tools v3.0:

Zone Admin View

Zoning Configuration Analyze Screen: The new Zoning Configuration Analyze screen, available

from the Zone Admin View, displays a summary of the saved configuration and attempts to point

out some of the zoning conflicts before applying the changes to the switch. For more information,

refer to the Web Tools User’s Guide.

Admin View

Network Configuration Tab: The new Network Configuration tab, available from the Admin

View, can be used to manage the IP networking functionality of the switch. For more information,

refer to the Web Tools User’s Guide.

Port Settings Tab: The new Port Settings tab, available from the Admin View, can be used to

disable and enable ports on a switch. The Port Settings tab is also used to set port speed to 1 GB/2

GB/Autosense as well as disable and enable the Trunking feature. For more information, refer to

the Web Tools User’s Guide.

Fabric OS v3.0.1b Release Notes - 6

New Features and Enhancements

Routing Tab: The new Routing tab, available from the Admin View, can be used to view the

routing table and to set the link cost for the selected ports and static route. For more information,

refer to the Web Tools User’s Guide.

Trunk Information Tab: The new Trunk Information tab, available from the Admin View, is a

read-only tab that displays trunk information. For more information, refer to the Web Tools User’s

Guide.

Report Tab: The new Report tab, available from the Admin View, is a read-only tab that displays

information about all of the switches, interswitch links, and ports in the Fabric. For more

information, refer to the Web Tools User’s Guide.

SNMP Tab: The SNMP tab, available from the Admin View, has been updated to include

“Community and Trap Recipient Configuration” and “Access Control List Configuration”

information. It can now be used to specify the switch community string, location, trap level, and

trap recipients. For more information, refer to the Web Tools User’s Guide.

Telnet Commands

The following telnet commands have been added or modified in Fabric OS version 3.0.1b:

•turboRamTest

•portCfgSpeed

•switchCfgSpeed

•msTDEnable

•msTDDisable

•islShow

•portCfgShow

•diagHelp

•statsTest

•fDefectTest

•perfAddEEMonitor

•perfAddIPMonitor

•perfAddReadMonitor

•perfAddRWMonitor

•perfAddSCSIMonitor

•perfAddUserMonitor

•perfAddWriteMonitor

•perfCfgClear

•perfCfgRestore

•perfCfgSave

•perfClrAlpaCrc

•perfDelEEMonitor

•perfHelp

•perfDelFilterMonitor

•perfSetPortEEMask

•perfShowAlpaCrc

•perfShowEEMonitor

Altri manuali per StorageWorks 8B - FC Entry Switch

Indice

Altri manuali HP Magazzinaggio

HP 20/700 Manuale utente

HP Invent EH853 Series Istruzioni per il montaggio

HP StoreOnce B6000 Manuale operativo

HP Surestore Tape Library Model 10/180 Manuale utente

HP A2W75-67905 Manuale utente

HP StorageWorks MSL6000 series Manuale utente

HP StorageWorks 4000/6000/8000 - Enterprise Virtual... Manuale di istruzioni

HP EVA P6000 Manuale utente

HP StorageWorks 4000/6000/8000 - Enterprise Virtual... Manuale di istruzioni

HP Xw8200 - Workstation - 1 GB RAM Manuale di riferimento

HP 705 Guida rapida

HP StorageWorks 4000/6000/8000 - Enterprise Virtual... Manuale di istruzioni

HP StorageWorks P4000 Series Manuale utente

HP AJ765A - StorageWorks RDX Removable Disk Backup... Manuale di istruzioni

HP StorageWorks 9100 - Extreme Data Storage... Manuale

HP Surestore 6164 - Switch Manuale utente

HP StorageWorks XP12000 Manuale utente

HP StorageWorks 7110 - Virtual Array Manuale utente

HP Compaq Presario,Presario 2120 Manuale utente

HP OmniBook 3100 - Notebook PC Manuale utente

HP 3PAR StoreServ 7000 Manuale utente

HP StorageWorks MSL6000 series Manuale utente

HP Pavilion p6000 - Desktop PC Guida

HP StorageWorks P2000 Manuale utente

Manuali Magazzinaggio popolari di altre marche

QNAP

QNAP TS 32PXU Series Manuale utente

LaCie

LaCie RUGGED RAID Manuale utente

Freecom

Freecom CLS DOCK Manuale utente

PNY

PNY Attache P-FD64MBATT3 Manuale utente

OLT

OLT 6x6 Maximizer Manuale utente

Transcend

Transcend JetFlash 160 Manuale utente

LaCie

LaCie RUGGED MINI Manuale utente

Thunderbolt

Thunderbolt 600 Manuale utente

Panasonic

Panasonic LB-DH8 series Manuale

Intel

Intel RAID High Availability Manuale utente

LaCie

LaCie 12big Thunderbolt 3 Manuale utente

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuale utente

Panasonic

Panasonic LKM-F931-1 Manuale utente

Tabernus

Tabernus Enterprise Erase E2400 Manuale utente

Rocstor

Rocstor COMMANDER 3F series Manuale utente

Western Digital

Western Digital Ultrastar Data60 Manuale utente

Dell

Dell PowerVault MD3600f Series Manuale utente

CFI

CFI TERA STOR SATA RAID IV Manuale utente
