HP StorageWorks 8B - FC Entry Switch Manuale utente

user's guide

version 3.0

advanced performance monitoring

www.hp.com

Notice

Edition: E1201

Hewlett-Packard Company makes no warranty of any kind with

regard to this material, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

This document contains proprietary information, which is protected

by copyright. No part of this document may be photocopied,

reproduced, or translated into another language without the prior

written consent of Hewlett-Packard. The information contained in

this document is subject to change without notice.

Use, duplication, or disclosure by government is subject to

restrictions as set forth in subdivision (c) (1) (ii) of the Rights in

Technical Data and Computer Software Clause at DFARS

252.227.7013.

Warranty

If you have any questions about the warranty for this product,

contact your dealer or local Hewlett-Packard sales representative.

Trademarks

BROCADE, the Brocade B weave logo, Brocade: the Intelligent

Platform for Networking Storage, SilkWorm, and SilkWorm

Express, are trademarks or registered trademarks of Brocade

Communications Systems, Inc. or its subsidiaries in the United

States and/or in other countries.

All other brands, product or service namesare or may be trademarks

or service marks of, and are used to identify products of services of

their respective owners.

Safety notices

Any servicing, adjustment, maintenance, or repair must be

performed only by authorized service-trained personnel.

Advanced Performance Monitoring User’s Guide iii

Contents

Preface

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

Related Publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Getting Software Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Chapter 1 Introducing Advanced Performance Monitoring

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Terminology Used in this Document . . . . . . . . . . . . . . . . . . 1-2

Performance Monitoring with Telnet Commands . . . . . . . . . . . . . . . . . 1-2

AL_PA Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

End-to-end Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Filter-based Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Performance Monitoring with Web Tools . . . . . . . . . . . . . . . . . . . . . . . 1-3

Predefined Performance Graphs. . . . . . . . . . . . . . . . . . . . . . 1-3

User-defined Graphs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Performance Graph Formats. . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Performance Graph Canvas . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Chapter 2 Installing Advanced Performance Monitoring

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Installing Through Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Installing through Web Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

iv Advanced Performance Monitoring User’s Guide

Chapter 3 Using Advanced Performance Monitoring

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Web Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Telnet Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

AL_PA Performance Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Displaying the CRC Error Count . . . . . . . . . . . . . . . . . . . . . 3-2

Clearing the CRC Error Count . . . . . . . . . . . . . . . . . . . . . . . 3-2

End-to-end Performance Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Adding End-to-end Monitors . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Setting a Mask for End-to-End Monitors . . . . . . . . . . . . . . . 3-4

Displaying the End-to-end Mask of a Port . . . . . . . . . . . . . . 3-6

Displaying End-to-end Monitors . . . . . . . . . . . . . . . . . . . . . 3-6

Deleting End-to-End Monitors . . . . . . . . . . . . . . . . . . . . . . . 3-7

Clearing End-to-End Monitor Counters . . . . . . . . . . . . . . . . 3-8

Filter-based Performance Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Adding Standard Filter-Based Monitors. . . . . . . . . . . . . . . . 3-8

Adding User-Defined Filter-Based Monitors . . . . . . . . . . . . 3-9

Displaying Filter-Based Monitors. . . . . . . . . . . . . . . . . . . . . 3-10

Deleting Filter-Based Monitors . . . . . . . . . . . . . . . . . . . . . . 3-11

Clearing Filter-Based Monitor Counters . . . . . . . . . . . . . . . 3-12

Saving and Restoring Monitor Configuration . . . . . . . . . . . . . . . . . . . . 3-12

Glossary

Index

Advanced Performance Monitoring User’s Guide v

Preface

Advanced Performance Monitoring is a licensed option and requires a valid license key to function.

It is included and enabled in switches with the performance upgrade option. It is supported for the

HP Surestore FC 1Gb/2Gb Entry Switch 8B, FC 1Gb/2Gb Switch 8B and FC 1Gb/2Gb Switch 16B

using Fabric OS version 3.0.1b or later.

About This Guide

This guide provides the following information about Advanced Performance Monitoring:

Related Publications

Related product information can be found in the following publications.

Provided with the FC Entry Switch 8B and FC Switch 8B:

•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Getting Started

Guide (A7346-90902)

•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Documentation

CD (A7346-11001)

Chapter 1

Introducing Advanced Performance

Monitoring

Overview of Advanced Performance Monitoring.

Chapter 2

Installing Advanced Performance Monitoring Instructions for installing Advanced

Performance Monitoring using telnet commands.

Chapter 3

Using Advanced Performance Monitoring Information about configuring and using the

Advanced Performance Monitoring telnet

commands.

vi Advanced Performance Monitoring User’s Guide

Provided on the FC Entry Switch 8B and FC Switch 8B Documentation CD, and at the HP Web site

at http://www.hp.com/support/fc8B:

•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Getting Started

Guide (A7346-90902)

•HP Surestore FC 1Gb/2Gb Entry Switch 8B and FC 1Gb/2Gb Switch 8B Installation and

Reference Guide

•Fabric OS Reference Manual, version 3.0

•Fabric OS Procedures Guide, version 3.0

•Fabric OS Version 3.0.1b Release Notes

•Fabric Watch User’s Guide, version 3.0

•QuickLoop User’s Guide, version 3.0

•Web Tools User’s Guide, version 3.0

•Distributed Fabrics User’s Guide, version 3.0

•Zoning User’s Guide, version 3.0

•MIB Reference Manual, version 3.0

•ISL Trunking User’s Guide, version 3.0

•Advanced Performance Monitoring User’s Guide, version 3.0

•Merging Heterogeneous Fabrics Instructions

Provided with the FC 16B:

•HP Surestore FC 1Gb/2Gb Switch 16B Quick Start Guide (A7340-96002)

•HP Surestore FC 1Gb/2Gb Switch 16B Documentation CD (A7340-11001)

Provided on the FC 1Gb/2Gb Switch 16B Documentation CD and at the HP Web site at

http://www.hp.com/support/fc16B:

•HP Surestore FC 1Gb/2Gb Switch 16B Quick Start Guide (A7340-96002)

•HP Surestore FC 1Gb/2Gb Switch 16B Installation and Reference Guide

•Fabric OS Reference Manual, version 3.0

•Fabric OS Procedures Guide, version 3.0

•Fabric OS Version 3.0.1 Release Notes

•Fabric Watch User’s Guide, version 3.0

•QuickLoop User’s Guide, version 3.0

•Web Tools User’s Guide, version 3.0

•Distributed Fabrics User’s Guide, version 3.0

•Zoning User’s Guide, version 3.0

•MIB Reference Manual, version 3.0

•ISL Trunking User’s Guide, version 3.0

•Advanced Performance Monitoring User’s Guide, version 3.0

•Merging Heterogeneous Fabrics Instructions

Information about Fibre Channel standards and Fibre Channel in general can be found on the Fibre

Channel Industry Association Web site, located at http://www.fibrechannel.com.

Advanced Performance Monitoring User’s Guide vii

Getting Help

For information for the FC Entry Switch 8B and FC Switch 8B, visit the HP Web site at

http://www.hp.com/support/fc8B. For the most current technical support information for the FC 16B,

visit the HP Web site at http://www.hp.com/support/fc16B. This includes hardware and software

support, all repairs, and spare components.

Be prepared to provide the following information to the support personnel:

•Switch serial number

•Switch world wide name

•Output from the supportShow telnet command

•Detailed description of the problem

•Topology configuration

•Troubleshooting steps already performed

Getting Software Updates

For information on obtaining software updates contact your HP account representative or technical

support.

viii Advanced Performance Monitoring User’s Guide

Advanced Performance Monitoring User’s Guide 1-1

Chapter

Introducing Advanced Performance Monitoring

This chapter provides the following information:

•Overview on page 1-1

•Performance Monitoring with Telnet Commands on page 1-2

•Performance Monitoring with Web Tools on page 1-3

Overview

Advanced Performance Monitoring provides SAN performance management through an

end-to-end monitoring system that enables you to:

•Increase end-to-end visibility into the fabric

•Enable more accurate reporting for service level agreements and charged access applications

•Improve performance tuning and resource optimization

•Shorten troubleshooting time

•Promote better capacity planning

•Simplify administration and setup

•Increase productivity with preformatted and customizable screens and reports

Features

The Advanced Performance Monitoring product:

•Measures the bandwidth consumed by individual routes (host-target pairs)

•Provides device performance measurements by port, AL_PA, and LUN

•Reports CRC error measurement statistics

•Measures Trunking performance

•Compares IP vs. SCSI traffic on each port

•Includes a wide range of predefined reports

•Allows you to create customized user-defined reports

Administration

Advanced Performance Monitoring is an optionally licensed product that runs on FC Entry Switch

8B, FC Switch 8B, and FC 16B switches.

1-2 Advanced Performance Monitoring User’s Guide

Introducing Advanced Performance Monitoring

If you have a fabric with HP Brocade 2400/2800, FC 6164, FC Entry Switch 8B, FC Switch 8B, or

FC 16B switches, you can take advantage of the end-to-end performance monitoring features by

installing an FC Entry Switch 8B, FC Switch 8B, or FC 16B switch anywhere in the route path

between the Source ID and the Destination ID.

You can administer performance monitoring through either telnet commands or Web Tools. If you

use Web Tools, a Web Tools license must also be installed on the switch.

Terminology Used in this Document

AL_PA Arbitrated Loop Physical Address. An 8-bit value used to uniquely identify an

individual port within a loop. A loop may have one or multiple AL_PAs.

SID 3-byte Source ID of the originator device, in the “0xDomainAreaALPA”

(0xDDAAPP) format.

DID 3-byte Destination ID of the destination device, in the “0xDomainAreaALPA”

(0xDDAAPP) format.

CRC Cyclic redundancy check; an error detection method. The CRC is 32 bits in the

frame, after the data field, and before the EOF (end of frame).

Performance Monitoring with Telnet Commands

Telnet commands provide three different types of performance monitoring:

•AL_PA monitoring

•End-to-end monitoring

•Filter-based monitoring

Refer to Chapter 3, Using Advanced Performance Monitoring, for detailed information on how to

use the telnet commands to monitor performance.

AL_PA Monitoring

AL_PA monitoring provides information regarding the number of CRC errors occurring in Fibre

Channel frames in a loop configuration. AL_PA monitoring collects CRC error counts for each

AL_PA attached to a specific port.

End-to-end Monitoring

End-to-end monitoring provides information regarding transaction performance between the

transaction source (SID) and destination (DID) on a fabric or a loop. Up to eight SID-DID pairs per

port can be specified. For each of the SID-DID pairs, the following information is available:

•CRC error count on the frames for the SID-DID pair

•Fibre channel words that have been transmitted through the port for the SID-DID pair

Altri manuali per StorageWorks 8B - FC Entry Switch

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali HP Magazzinaggio

HP dat72 5242 Manuale utente

HP StorageWorks XP10000 - Disk Array Manuale utente

HP P9000 Manuale utente

HP AJ765A - StorageWorks RDX Removable Disk Backup... Manuale di istruzioni

HP StorageWorks SDLT Series Manuale utente

HP XP7 Manuale utente

HP StorageWorks Ultrium 215i Manuale utente

HP HPE 3PAR StoreServ 8000 Manuale utente

HP VS160 - StorageWorks DLT Tape Drive Istruzioni operative

HP Surestore 6164 - Switch Manuale utente

HP StorageWorks MSL6000 series Istruzioni utente

HP P9000 Manuale utente

HP StoreOnce 4900 Backup Manuale dell'operatore

HP Ultrium Drive Manuale del prodotto

HP StorageWorks 8000 - NAS Manuale utente

HP Surestore 6164 - Switch Manuale utente

HP Storevirtual 4000 Manuale utente

HP P9000 Manuale utente

HP StorageWorks D2700 Manuale utente

HP Storevirtual 4000 Manuale di istruzioni

HP XP20000/XP24000 Manuale utente

HP Surestore Disk Array 12h - And FC60 Manuale utente

HP StorageWorks 4000/6000/8000 - Enterprise Virtual... Manuale di istruzioni

HP StorageWorks 8000 - NAS Manuale utente

Manuali Magazzinaggio popolari di altre marche

QNAP

QNAP TS 32PXU Series Manuale utente

LaCie

LaCie RUGGED RAID Manuale utente

Freecom

Freecom CLS DOCK Manuale utente

PNY

PNY Attache P-FD64MBATT3 Manuale utente

OLT

OLT 6x6 Maximizer Manuale utente

Transcend

Transcend JetFlash 160 Manuale utente

LaCie

LaCie RUGGED MINI Manuale utente

Thunderbolt

Thunderbolt 600 Manuale utente

Panasonic

Panasonic LB-DH8 series Manuale

Intel

Intel RAID High Availability Manuale utente

LaCie

LaCie 12big Thunderbolt 3 Manuale utente

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuale utente

Panasonic

Panasonic LKM-F931-1 Manuale utente

Tabernus

Tabernus Enterprise Erase E2400 Manuale utente

Rocstor

Rocstor COMMANDER 3F series Manuale utente

Western Digital

Western Digital Ultrastar Data60 Manuale utente

Dell

Dell PowerVault MD3600f Series Manuale utente

CFI

CFI TERA STOR SATA RAID IV Manuale utente
