HTC Desire 616 dual sim Manuale utente
1. With the phone facing
down, open the back cover
from the small opening at
the bottom.
2. Before inserting the cards
into the slots, you need to
remove the battery.
3. Insert a WCDMA/GSM SIM
into the SIM 1 slot, with the
card’s gold contacts facing
down and cut-off corner
facing out.
4. Insert a GSM micro SIM
into the SIM 2 slot, with the
gold contacts facing down
and cut-off corner facing
in.
5. Insert a microSD™ card
into the storage card slot
with its gold contacts
facing down.
IMPORTANT: USE A REGULAR SIM IN SLOT 1 AND A
MICRO SIM IN SLOT 2.
Inserting a smaller size SIM (such as a nano SIM with an
adapter or a modified SIM) may damage the card slot or
cause the card to not fit properly.
GSM
WCDMA/
GSM
Inserting the SIM and storage cards
HTC Desire616dualsim
gold contacts
cut-o corner
microSD regular SIM
micro SIM
© 2014 HTC Corporation. All rights reserved.
HTC, the HTC logo, and HTC Desire are trademarks of HTC
Corporation. All other company, product and service names
mentioned herein are trademarks, registered trademarks or service
marks of their respective owners.
6. Reinsert the battery.
7. To replace the back cover,
align the phone onto the
top part of the back cover
first. Then press the sides
and the bottom part of
the back cover down to
lock the cover into place.
Complies with
IDA Standards
DB 104368
91H0xxxx-xxM Rev.A
htc.com
6
7
Want some guidance on using your phone?
Go to www.htc.com/support/ to find the user guide,
latest news, and more.
