HTC Tilt 2 Manuale utente

Quickstart

Welcome to AT&T

Your device controls are

shown on this foldout.

•Please use this Quickstart to get a brief overview of the major features and

services available with your new smartphone

•Access the on-device tutorial at any time for instructions on setting up

and customizing your device and performing common tasks. On the Home

screen, slide to the Programs tab and touch Getting Started.

•Use our interactive Web tutorial available at

att.com/tutorials

for the most complete and up-to-date information available to set up your

device and services. The on-line tutorials include step-by-step instructions

and screen shots to assist your learning as well as providing an easy search

function.

Note: Depending on the device model you purchased, Video Share and photo/video capture may

not be available.

Table of Contents

What’s in the box 5

Device setup 6

Insert the SIM card 6

Insert the battery 6

Charge the battery 7

Turn on your HTC Tilt™ 2 7

Install a microSD card (sold separately) 8

Sleep Mode 8

TouchFLO™ 3D 9

TouchFLO 3D: Learn the gestures for TouchFLO 3D 9

TouchFLO 3D: G-Sensor 10

TouchFLO 3D Tabs 11

TouchFLO 3D: Zooming 12

Keyboard 13

Enter text using the keyboard 13

Check device status, make calls, and set up voice

mail 14

Before making a call 14

Make a phone call 15

Set up your voicemail 15

Video Share 16

Start a Video Share call 16

Accept a Video Share call 16

End a Video Share Call 16

People 17

Add a contact to your device 17

Copy all SIM card contacts to your device 17

Link your contacts to their Facebook accounts 18

Find and use your contacts 18

Favorites 19

Add a favorite on the People tab 19

Appointments 20

Schedule an appointment 20

Table of Contents

View your appointments on the Home screen 20

Ringtones 21

Personalize your device ringtone 21

Text Messages 22

Compose and send a text message 22

Camera 23

Take a contact picture 23

Take and send a picture 23

Multimedia Message 24

Capture and send a video 24

Internet 25

Email 26

About email 27

Set up an email account 27

Send and receive personal email 28

Set up IT managed corporate email 29

AT&T Navigator 30

Start AT&T Navigator 30

Get directions 30

Bluetooth and Wi-Fi 31

Connect a Bluetooth headset 31

Connect to Wi-Fi 31

Connect to an AT&T Wi-Fi Hot Spot 31

AT&T Services 32

Use Mobile Web to access the Web and shop online 33

AT&T Music 34

Open AT&T Music 34

Music Player 35

Transfer music 35

Frequently Asked Questions 36

Tips and Tricks 37

What’s in the box

USB Sync Cable

AC Charger

Rechargeable Battery

Extra Stylus

HTC Tilt™ 2

3.5 mm Audio Adapter

Insert the SIM card

The SIM card contains your phone number,

service details, and phonebook/message

memory. Make sure that your device is turned

off before you remove the back cover.

1. Hold the device with both hands and the

front panel facing down.

2. Push the back cover up with your thumbs

until it disengages from the device and

then slide it up to remove.

3. Locate the SIM card slot, then insert the

SIM card with its gold contacts facing down

and its cut-off corner facing out of the card

slot.

4. Slide the SIM card completely into the slot.

Note: To remove the SIM card, remove theTo remove the SIM card, remove the

battery, then slide the SIM card out from

the SIM card slot with your thumb.

Insert the battery

Your device comes with a rechargeable

Lithium-ion or Lithium-ion polymer battery and

is designed to use only manufacturer-specified

original batteries and accessories.

1. Align the battery’s

exposed copper

contacts with the

battery connectors

inside the battery

compartment.

2. Insert the contact’s side of the battery

first and then gently push the battery into

place.

3. Replace the back cover.

To remove the battery

1. Make sure your device is turned off.

2. Remove the back cover.

3. Lift the protruding grip at the bottom right

side of the battery to remove the battery.

Battery grip

Device setup

2Cut-off

corner

Charge the battery

New batteries are shipped partially charged.

Before you start using your device, it is

recommended that you charge the battery.

To charge the battery

•Connect the USB connector of the AC

adapter to the PC and to the sync connector

on your device, or

•Plug in the AC adapter to an electrical outlet

to start charging the battery.

Note: Only the AC adapter and USB sync

cable provided with your device must be

used to charge the device.

As the battery is being charged while the

power is on, a charging icon appears in the

title bar of the Home screen. After the battery

has been fully charged, a full battery icon

appears in the title bar of the Home screen.

Warning! Do not remove the battery from

the device while you are charging it

using the AC or car adapter.

Turn on your HTC Tilt™ 2

Press the POWER button to turn on the device.

Power button

It may take several minutes for the TouchFLO

3D interface to load during initial setup. Do not

press any buttons or turn off

the device until the device

completes the startup.

Install a microSD card (sold

separately)

To have additional storage for your images,

videos, music, and files, you can purchase a

microSD™ card and install it into your device.

Insert the microSD card into the slot with its

gold contacts facing down, then replace the

back cover.

Note: To remove the microSD card, press it to

eject it from the slot.

Sleep Mode

Your device will go to Sleep Mode after 30

seconds or more of inactivity. Sleep Mode

suspends your device to a low power state

while the display is off to save battery power.

You will still be able to receive messages and

calls while your device is in Sleep Mode. To

wake up your device, press the POWER button

again. Incoming calls will also wake up your

device from Sleep Mode.

Note: You can change the delay before your

device goes into Sleep Mode. On the

Home screen, slide to the Settings tab,

and then touch All Settings > System >

Power > Advanced tab.

Device setup

TouchFLO™ 3D

TouchFLO™ 3D gives you touch control over your HTC Tilt™ 2. TouchFLO allows you to use

finger gestures to navigate screens and provides a Home screen that lets you access your most

important information and most-used applications quickly and easily.

Note: For detailed information about gestures and screen navigation, refer to the User Manual onFor detailed information about gestures and screen navigation, refer to the User Manual onFor detailed information about gestures and screen navigation, refer to the User Manual on

the Getting Started CD.

TouchFLO 3D: Learn the gestures for TouchFLO 3D

Touch, Hold and Slide

To navigate the Home screen, touch and hold

your finger on the active tab, then slide your

finger right or left over the tabs. Release when

you have selected the desired tab.

Note: Apply some pressure when touching and

holding on the active tab to be able to

slide over the tabs.

Up/Down Navigation

Inside each tab, to browse through pictures,
