HTC Touch Diamond2 Manuale utente

Quick Start Guide

Please Read Before Proceeding

THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU DISASSEMBLE OR ATTEMPT

TO DISASSEMBLE THE DEVICE.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and

stipulate that you must inform the person with whom you are speaking that the

conversation is being recorded. Always obey the relevant laws and regulations of your

country when using the recording feature of your PDA Phone.

LIMITATION OF DAMAGES

To the maximum extent permitted by applicable law, in no event shall HTC or its

providers be liable to user or any third party for any indirect, special, consequential,

incidental or punitive damages of any kind in contract or tort, including, but not

limited to, injury, loss of revenue, loss of goodwill, loss of business opportunity, loss of

date, and/or loss of profits arising out of, or related to, in any manner, or the delivery,

performance or nonperformance of obligations, or use of the weather information,

stock data, data or documentation hereunder regardless of the foreseeability thereof.

FOR MORE INFORMATION

For health, safety, and regulatory information, see “Safety and Other Notices”.

Table of Contents

1. Welcome to the HTC Touch Diamond2 Quick Start Guide.....5

2. Inside the Box .........................................................................................5

3. Getting to Know the HTC Touch Diamond2 ................................6

4. Installing the SIM Card, Battery, and Storage Card ...................7

5. Charging the Battery............................................................................9

6. Starting Up...............................................................................................9

7. The Home Screen................................................................................10

8. Lock Screen............................................................................................11

9. Using the Start Screen.......................................................................13

10. Making Your First Call.........................................................................14

11. Making a Video Call ............................................................................15

12. Entering Information..........................................................................16

13. Basic Settings........................................................................................17

14. Adding Favorite Contacts.................................................................20

15. Viewing Conversations......................................................................22

16. Sending a Text Message....................................................................23

17. Sending an MMS Message...............................................................23

Contents

Table of Contents

18. Setting Up an Internet Email Account .........................................24

19. Using Wi-Fi .............................................................................................25

20. Mobile Internet ....................................................................................26

21. Bluetooth................................................................................................27

22. Keeping Track of Appointments ....................................................28

23. Capturing Photos and Recording Videos....................................29

24. Viewing Photos and Videos .............................................................30

25. Connecting Your Phone to a Computer......................................31

26. Synchronizing Your Phone with Your Computer......................32

27. Copying Files to the Storage Card.................................................33

28. Synchronizing Music Files ................................................................33

29. Listening to Music on Your Phone.................................................34

30. Resetting Your Phone.........................................................................35

31. Safety and Other Notices..................................................................36

Quick Start Guide 5

1. Welcome to the HTC Touch Diamond2 Quick Start Guide

Congratulations on your purchase of the HTC Touch Diamond2.

This Quick Start Guide will help you get started with your Windows Mobile® 6.5

Professional powered Touch Phone. We’ve arranged this Quick Start Guide in a way that it

starts from when you open the box and then it walks you through the features we feel that

you want to know or use right away when you turn on your phone for the first time.

For a more complete guide in using your phone, please refer to the User Manual PDF

which can be downloaded from the HTC website at http://www.htc.com/au/support.aspx.

2. Inside the Box

You should find the following items inside the box.

HTC Touch Diamond2 phone

Battery

AC adapter

Wired stereo headset

USB sync cable

Screen protector

Quick Start Guide

Pouch

Extra stylus

•

6 Quick Start Guide

3. Getting to Know the HTC Touch Diamond2

Speaker

POWER

Stylus

VOLUME UP

VOLUME

DOWN

Earpiece

Touch Screen

START

END

Second

Camera

TALK/SEND

Back Cover

5.0

Megapixel

Camera

Sync Connector/

Earphone Jack

Microphone

Light Sensor

BACK

Notification LED

Zoom Bar

Quick Start Guide 7

4. Installing the SIM Card, Battery, and Storage Card

Make sure your phone is turned off before installing the SIM card and battery. You also

need to remove the back cover before you can install these components.

To remove the back cover

Make sure your phone is turned off.

Firmly hold the phone with both hands and

the front panel facing down.

Push the back cover up with your thumbs

until it disengages from the phone and then

slide it up to remove.

To install the SIM card

Remove the battery if it is installed.

Locate the SIM card slot, then insert the SIM

card with its gold contacts facing down and

its cut-off corner facing out the card slot.

Slide the SIM card completely into the slot.

Cut-off

corner

8 Quick Start Guide

To install the battery

Align the battery’s exposed copper contacts

with the battery connectors at the bottom

part of the battery compartment.

Insert the contacts side of the battery first and

then gently push the battery into place.

Replace the back cover.

Notch

To install a microSD™card

Locate the storage card slot, then insert the

microSD card into the slot with its gold contacts

facing down until it clicks into place.

Note To remove the microSD card, press it to eject it

from the slot.

Storage

card slot

For information on how to remove or replace these components on your phone, refer to

the “Getting Started” chapter in the User Manual PDF.

Quick Start Guide 9

5. Charging the Battery

New batteries are shipped partially charged. Before you start using your phone, it is

recommended that you install and charge the battery.

To charge the battery

Connect the USB connector of the AC adapter to the sync connector at the bottom

of your phone.

Plug in the AC adapter to an electrical outlet to start charging the battery.

6. Starting Up

After installing the battery and charging the battery, you can now power on and start

using your phone.

To turn on the power

Press the POWER button.

On first time use, the phone installs customized settings, and then displays the SIM Card

Changed screen. Follow the on-screen instructions to import the contacts to your device.

To turn off the power

If the display is off, press the END/POWER button to turn the display back on.

Press and hold the END/POWER button for a few seconds.

Tap Yes when prompted.

10 Quick Start Guide

7. The Home Screen

The Home screen of your phone allows finger-touch access to the most widely-used functions,

such as People, Messages, Internet, and more. The Home screen has the following tabs::

Home Music Settings

CalendarNews and

Sport

Photos

and Videos

People

DownloadsMessages

Internet

and Search

Telstra

Applications

Favorite

Programs

To switch between the tabs of the Home screen

Do any of the following:

Tap the desired tab on the Home screen.

Press and hold your finger

on the active tab, and then

slide your finger right or

left over the tabs. Release

when you have selected

the desired tab.

Swipe left across the

screen to move to the next

tab, and swipe right across

the screen to move to the

previous tab.

•

The following sections in this Quick Start Guide will show you how to use some of the

Home screen tabs. For complete information about using the Home screen, refer to the

User Manual PDF.

•
