Vehicle GPS Tracker HB-A5W
(3G Network)
Product Manual
06.07.2020 CHINA-HUABAO
CONTENT
1. Product Overview.......................................................................................................................
2. Product Features........................................................................................................................
3. Product Specifications................................................................................................................
4. Product connection port.............................................................................................................
4.1 Port1 Power port........................................................................................................................
4.2 Port2 Serial port.........................................................................................................................
4.3 Port 3 Panic button port.............................................................................................................
5. LED light status description.........................................................................................................
6. Product installation....................................................................................................................
6.1 Installation position...................................................................................................................
6.2 SIM card installation..................................................................................................................
6.3 Power connection......................................................................................................................
6.4 Relay installation........................................................................................................................
6.5 Panic button installation............................................................................................................
7. Operation...................................................................................................................................
7.1 Basic parameters setting............................................................................................................
7.2 Basic function operation............................................................................................................
7.3 Other operation…………………………………………………………………………………………………………………….
8. FAQ............................................................................................................................................
8.1 Equipment Non-online...............................................................................................................
8.2 Cannot Location after Equipment Online..................................................................................
8.3 Equipment Off-line when Operation..........................................................................................
8.4 The Accuracy of Satellite Location is not enough.......................................................................
9. After sales service.......................................................................................................................
10. Packing
list……………………………………………………………………………………………………………………………...
1. Product overview
HB-A5W GPS vehicle tracker is an easy install, stable & reliable and low power consumption device, it can connect
to external panic button, Relay for remotely fuel cut-off, handset, Fuel sensor etc. This device is 3G network
module. Especially suitable for logistics, long-distance passenger transport, and dangerous goods transport, bus
companies, vehicle rental, taxi and other industries.
2. Product features
Real-time location: Users can get real time vehicle location via PC, Mobile APP, or SMS.
3G data network: This device is using high level 3G module, it can cover 2G and 3G network.
Built in GPS/GSM antenna: This device is using built in GPS/GSM antenna, it is easy for installation and
customer can hidden it.
Trace playback: User can playback the history trace through PC or Mobile APP.
Configuration through GPRS/SMS: The device support to configuration through GPRS(PC or Mobile APP) and
SMS, please find the SMS command list in 7.1.
Ignition detection: This device can detect the vehicle ignition status ON/OFF
Remotely fuel cut-off (Relay): When the vehicle is stolen or the user doesn’t use the vehicle regularly etc.,
can make the driver cannot start the vehicle by remotely lock or unlock the vehicle.
Good expandability: This device has RS232 port, IN/OUT port and 1@wire port, can connect to panic button,
fuel sensor and temperature sensor. It is good and necessary features for fleet management.
Power off alarm: This device can detect the status of the main power connection, it will send message or
alarm if the main power is disconnected.
Backup battery: This device has back battery, when the main power supply is off, backup battery can supply
power to the device and continue send data. Support work for 1-2 hours.
SOS alarm: This device can connect with panic button to generate SOS alarm through GPRS or SMS
Over speed alarm: This device will generates over speed alarm through GPRS or SMS when the vehicle speed
is exceeding the MAX speed pre-configured.
Various reports: This device can provide various data for the reports purpose, such as mileage report, trip
report, speed report etc. It is customizable in the monitoring platform, please contact the dealer for more
details.
OEM/ODM: This device support OEM/ODM business mode, please contact the manufacturer for more
details.
OTA: This device firmware can be upgraded over the air.
Functions
HB-A5W
Note
Communication
2G
850/900/1900/2100M
Hz
3G
850/900/1800/1900M
Hz
4G
○
Positioning
GPS+BDS
GPS/BDS
Functions
Real-time positioning
●
Configurable transmission time. The
default setting is 20 seconds/ 1 data.
Dead zone
●
Record 800 pieces of backup data.
Mileage statistics
●
Remotely fuel cut-off
●
Disconnect vehicle power via relay.
Detection ACC
●
Power off alarm
●
Main power outage
Low voltage alarm
●
Read vehicle voltage, alarm when below
9V.
Emergency alarm
●
Panic button
Ex-speed alarm
●
Vibration alarm
○
Can support adding through upgrade
program
Displacement alarm
○
Area management
○
Platform functions assist docking.
Line management
○
Platform functions assist docking.
Domain name access
●
The platform displays the domain address,
instead of the server address. For
example: https://168.75.10.225:8080,
which is displayed as
https://www.abcde.com
Multiple servers and
platforms
○
Device data points to multiple servers and
platforms.
Remote upgrade
●
OTA
Interfaces
ACC
1
Connected vehicle ACC
Fuel cut-off
1
Connected relay
Emergency alarm
1
Connected panic button
MIC (Optional)
○
Standard version does not support. Can
add if project needs.
RS232
2
1 of Fuel sensor, 1 of Computer data cable
1-wrie
1
Temperature Sensor
3. Product specifications
Communication module
(MTK 6276)
WCDMA: 850/900/1900/2100MHz
GSM: 850/900/1800/1900MHz
GPS Parameters
(ublox-G7020)
Sensitivity：Location:-162dBm ;
Capture: -148dBm
Based on 64 channel HumbirdTM chip
UM220-III N high sensitivity location chip
Frequency：GPS L1BDS B1
Location accuracy：<10m
Cold start:30s Hot start: 1s
Speed accuracy
<0.1m/s
Accelerated speed accuracy
< 4g
Working temp
-20℃～ +70℃
Store Temp
40℃～ +85℃
Humidity
5% ～95%
Battery
180mAh rechargeable lithium battery, 3.7V, work 2 hours.
Work voltage
9V～36V
Power consumption
1W～1.5W
Work current
80mA
Port
2*RS232 (1 of Fuel sensor, 1 of Computer data cable)
1*5V output
1*SOS port
1*Relay connection
1*Input for Ignition detection
1*Input 1@Wire
Size
100 * 50 *16mm
Net Weight
100g
4. Product connection port
4.1 Port 1---Power port
No.
Cable color
description
1
Red
Power (+12/+24V)
2
Black
GND
3
Orange
Ignition detection
4
White
CUT-OFF
4.2 Port 2---Serial port
No.
Cable color
description
1
Purple
One wire (Temperature Sensor)
2
Yellow
RS232-RX (Fuel Sensor)
3
Blue
RS232-TX (Fuel Sensor)
4
Orange
5V
5
Black
GND
6
Green
SOS
4.3 Port 3---Monitor port
No.
Cable color
description
1
Gray
RS232-RX2 (Serial cable) / MIC
(Optional)
2
Brown
RS232-TX2 (Serial cable) / MIC
(Optional)
5. LED Light status description
Description of indicator light
Power
Red Light
Light Always-on: Working Fine
No Light: Shut Down
GPS
Blue Light
Flashing Every 2s：Searching GPS Signal
Light Always-on：GPS Positioned
No Light：GPS Sleep
GSM
Yellow Light
Flashing Every 2s：GSM Initialization
Light Always-on：GPRS Communication Normal/Been
Online
No Light：GSM Sleep
6. Product installation
6.1 Installation position
6.2 SIM Card Installation
The device needs to work with a SIM card. Please make sure the SIM card has the following functions:
(1) Already activated the GPRS and SMS function.
(2) Have enough remaining credit.
(3) PIN code removed.
Steps:
(1) Open the top cover of device
(2) Disconnect the built-in battery by turn OFF the switch.
(3) Insert the SIM card to the slot according to the direction instruction.
(4) Connect the built-in battery by turn ON the switch.
6.3 Power connection---Port 1
The standard input voltage of the device is 12V-24V (Note: Please check the working voltage of the device to
avoid any damage. If higher than this voltage, please choose the suitable power adapter.) The Red line is
power positive, Black line is power negative. Please choose the negative to connect ground or metal
separately.
(1) Red wire connect to vehicle power Positive Pole.
(2) Black wire connect to vehicle power Negative Pole.
(3) Orange wire connect vehicle ignition line.
(4) White wire is for controlling the engine
6.4 Relay Installation for fuel and power cut off---Port 1 Pin4
The Relay is an optional accessory. There are two types relay: 12VDC and 24VDC. Please choose the correct type
before installing Relay (Please use power meter to detect the vehicle voltage to choose the correct type of relay).
Connecting method:
(1) Port 1 Green line connect to relay 86 feet
(2) Relay 85 feet connect to main power supply of the vehicle.
(3) Cut the fire wire of the vehicle, tandem connect with the Relay two green wires. .(Usually to realize remotely
fuel cut-off via controlling to cut ignition wire.)
6.5 Panic button installation---Port 2
To connect the panic button, please find the port 2 pin6 Green line is the panic button signal line, port 2 pin5 black
line is GND, Connect SOS button to Port2 Pin6 and Port2 Pin5, Press the SOS button for 3s will trigger SOS alarm.
White Wire
Notes:
The device should be installed hiddenly, before installation, please pay attention to the following:
(1) The device have built-in GSM and GPS antenna, please make sure the front side up and no metal shelter when
installing. (Glass and plastic are without influence.)
(2) Avoid putting close to the heat and emission source, such as engine, controller, reverse radar, burglar alarm
and other vehicle communication device.
(3) Suggest fixing via magic sticks, double sided foam tape etc.
(4) Please do not install this device to the vehicle whose battery is not in good status.5) All SMS alarms are close as
default.
7. Operation steps
7.1 Basic parameters setting
After the installation complete, there are some configuration is necessary for make the device working online, we
suggest to use SMS command to do the configuration, the user will need to send the following command to the
device by SMS:
Command
Command Explain
SMS Command Sending Samples
SMS Command
Response
Set APN
APN means access point name
#000000,STAP:APN
eg.: #000000,STAP:m2m.onelink
Set Okay!
Set IP and
port
Set the IP and port to make
the device send data to the
server
#000000,STIP:IP,PORT
eg.: #000000,STIP:218.30.35.115,7008
Set Okay!
Set Interval
Send this command to
configure the time interval for
data uploading
#000000,STIN:30,600
(Notes: Second only: ACC ON, 30s;
ACC OFF, 600s)
Set Okay!
Set
Time-Zone
Different country with
different time zone, send this
command to set the time zone
#000000,STTZ:hour:minute
eg.: #000000,STTZ:+8
Time zone
