Huawei Ascend Y210D Manuale utente

Welcome to HUAWEI

Quick Start Guide

HUAWEI Ascend Y210D

Dual-Card Dual-Standby

Your mobile phone supports dual-card dual-standby mode, which

can significantly reduce power consumption and increase your

phone's standby time. Note that two restrictions exist:

• When you make calls using one SIM card, the other SIM card is

disabled.

For example, when you make calls using SIM card 1, SIM card

2 cannot be used to answer calls or access the Internet. If

someone calls SIM card 2, the caller will hear a voice message

like "The subscriber you dialed is out of the service zone" or "The

subscriber you dialed is not able to answer your call, please try

again later." This is because your mobile phone cannot access

the network with both SIM cards at the same time and has

nothing to do with your service provider's network condition. It is

recommended that you subscribe to services such as voicemail

or missed-call reminders from your service provider to avoid the

inconvenience caused by missed calls.

• When you are using one SIM card's data services, you can

receive calls and messages using the other SIM card, but data

services will be interrupted.

For example, when SIM card 1's data services are in use, you

can use SIM card 2 for calling and messaging, but SIM card 1's

data services will be interrupted as a result. When the call using

SIM card 2 is terminated, or the message is received or sent, you

can resume using SIM card 1's data services.

Phone at a Glance

All the pictures in this guide are for your reference only. Your

phone’s actual display features may be different to those

described here, depending on its software version.

Key Functions at Your Fingertips

• Press and hold to power on your mobile phone.

• Press and hold to open the

Phone options

menu.

• Press to lock the screen when your mobile phone is

active.

• Touch to return to the previous screen or exit the

application you are running.

• Touch to hide the keyboard.

Touch to open the menu on an active screen.

Volume

key

Speaker

Earpiece

Camera

Charger/

Data port

Headset jack

Back

Home

Power key

Installing the SIM Card

• Touch to return to the Home screen.

• Touch and hold to show the most recently used

applications.

3Insert SIMcard

Remove the battery cover

Insert WCDMA/GSM card Insert GSM card

Remove the battery

Dual-Card Management

Your mobile phone supports access to both WCDMA and GSM

networks. Follow the onscreen instructions or the quick start guide to

install SIM cards.

1. Touch >

Settings

2. Touch

Dual Card Settings

to activate the SIM cards.

(Optional) Installing the microSD

Card

If you want to expand your phone memory, you can also insert a

microSD card.

1. Remove the battery cover.

2. Remove the battery.

3. Insert the microSD card into the card slot as shown in the

diagram.

Enable Enable

Preferred Preferred

Card1

Card2

Installing the Battery

1. Angle the edge labeled

(with the contacts) into the bottom end

of the battery compartment.

2. Push the edge labeled

into the compartment until the battery

clicks firmly into place.

Charging the Battery

Before charging the battery, ensure that it has been properly installed

on your phone.

1. Connect the USB cable that came with your mobile phone to

the charger.

2. Connect the other end of the USB cable to your mobile phone.

Then, to start charging, plug the charger into an electrical outlet.

If you charge your mobile phone while it is powered on, the battery

icon on the notification bar indicates the charging status. When the

battery icon changes to , your mobile phone is fully charged.

Status Indicator

The color of the status indicator tells you the status of your mobile

phone’s battery.

Touchscreen Actions

Using your finger on the touchscreen, you can operate your phone

conveniently.

Status Indicator

Green: Fully charged (when connected to charger).

Orange: Charging in progress (when connected to charger).

Red: Battery low.

Drag

TouchTouch & hold Double touch

Flick

Home Screen

You can set up the Home screen according to your own

preferences, for example by adding a shortcut or a widget to your

Home screen or changing the wallpaper.

To return to the Home screen from any of its extensions, press .

When a new notification icon appears on the notification bar, place

your finger on the notification bar and flick down to open the

notification panel.

Adding a New Home Screen Item

1. Touch and hold a blank area on the Home screen until the

Add

to home screen

menu is displayed.

2. Select an item to add it to the Home screen.

Removing a Home Screen Item

1. Touch and hold an item on the Home screen until the item

expands and the mobile phone vibrates.

2. Without lifting your finger, drag the item to the trash can. When

the item and the trash can turn red, the item is ready to be

removed.

3. Release the item to remove it from the Home screen.

10:23

Flick your finger left or

right across the Home

screen.

Touch to view thumbnails

of the Home screen and its

extensions. Touch a thumbnail

to open the screen.

10:23

Importing Contacts from a SIM

Card

1. In the contact list, touch >

Manage contacts

2. Touch

Copy contacts from card 1

Copy contacts from

card 2

3. Wait for the SIM card contents to be loaded. Select the contacts

you want to import or touch

Select All

to select all contacts.

4. Touch

Copy

5. If you have more than one account on your phone, touch the

account into which you want to import the contacts.

Adding a Contact

1. In the contact list, touch >

Create contact

2. If you have more than one account with contacts, touch the

account to which you want to add the contact.

3. Enter the contact's name, and then add detailed information

such as phone number and address.

4. When you are finished, touch

Save

to save the contact

information.

Making a Call with the Dialer

Application

On the home screen, touch to open the

Dialer

Your mobile phone supports the SmartDial function, that is, when

you touch numbers on the dialer, the phone automatically searches

among your contacts and lists the matching results ordered

according to the accuracy of the match. If no contacts match the

information entered, the phone will not display any result.

Creating and Sending a

Multimedia Message

You can use multimedia messages to make everyday

communications very special. You can record a message and send

it as an audio file, sing 'Happy Birthday' and send it to friend, or send

a slideshow of photographs of a special event. The possibilities are

endless.

1. Touch >

Messaging

New message

2. Enter a phone number in the

field, or touch to select a

contact from

Contacts

Groups

3. Touch the composition text box to start entering your message.

4. When the message is ready to be sent, touch

Card 1 MMS

Card 2 MMS

10:23
