Huawei C2809 Manuale utente

C2809

No part of this document may be reproduced or transmitted in any

form or by any means without prior written consent of Huawei

Technologies Co., Ltd.

The product described in this manual may include copyrighted

software of Huawei Technologies Co., Ltd and possible licensors.

Customers shall not in any manner reproduce, distribute, modify,

decompile, disassemble, decrypt, extract, reverse engineer, lease,

assign, or sublicense the said software, unless such restrictions are

prohibited by applicable laws or such actions are approved by

respective copyright holders under licenses.

Trademarks and Permissions

, HUAWEI, and are trademarks or registered

trademarks of Huawei Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned

are the property of their respective owners.

Notice

Some features of the product and its accessories described herein rely

on the software installed, capacities and settings of local network,

and may not be activated or may be limited by local network

operators or network service providers, thus the descriptions herein

may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify

any information or specifications contained in this manual without

prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.

EXCEPT AS REQUIRED BYAPPLICABLE LAWS, NO

WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,

INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITYAND FITNESS FOR A

PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE

ACCURACY, RELIABILITY OR CONTENTS OF THIS

MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE

LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD

BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR

CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,

REVENUE, DATA, GOODWILL ORANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and

regulations and will obtain all necessary governmental permits and

licenses in order to export, re-export or import the product mentioned

in this manual including the software and technical data therein.

Table of Contents

1Your Phone.....................................................................................1

2Keys and Functions........................................................................2

3Screen Icons....................................................................................4

4Menu Tree ......................................................................................6

5Installing the UIM Card and Battery ..........................................7

6Removing the Battery and UIM Card.........................................7

7Charging the Battery.....................................................................8

8Using the Function Menu..............................................................8

9Using the Power Saving Function ................................................8

10 Making a Call...............................................................................9

11 Answering a Call........................................................................10

12 Recording a Voice Clip .............................................................10

13 Switching On the Radio ............................................................10

14 Searching for a Channel ...........................................................11

15 Phone Lock.................................................................................11

16 PIN and PUK .............................................................................11

17 Locking the Keypad...................................................................12

18 Changing the Text Input Modes ..............................................12

19 Entering English (En)................................................................13

20 Entering English (Abc)..............................................................13

21 Entering Hindi ...........................................................................13

22 Entering Numbers .....................................................................13

23 Entering Symbols.......................................................................14

24 Warnings and Precautions........................................................14

1 Your Phone

Earpiece

Screen

Left Soft key

OK key

Send key

Navigation keys

Charger

/Headset jack

# key

Numeric keys

End key

key

Right Soft key

2 Keys and Functions

Press… To…

zView the call log in the standby mode.

zMake or answer a call.

zPower on or off the phone (by pressing and holding

it).

zEnd a call or reject an incoming call.

zReturn to the standby mode.

Select the option displayed on the lower left corner of

the screen.

Select the option displayed on the lower right corner of

the screen.

–

zEnter numbers, letters, and symbols.

zAccess Voice Mail in the standby mode (by pressing

and holding the 1key).

zSpeed-dial phone numbers in the standby mode (by

pressing and holding the 2-9 keys).

zSelect a submenu item labeled the corresponding

number.

zDisplay the TATA Zone interface in the standby

mode.

zConfirm a selection.

Press… To…

zDisplay the TATA Zone interface ( ), the

Messages main menu ( ), the Create Message

interface (by pressing and holding ), the

Scheduler interface ( ), and the Profiles main

menu ( ) in the standby mode.

zIncrease the volume ( or ) or decrease the

volume ( or ) during a call.

zEnter the * symbol, + symbol, Pcharacter, or T

character by pressing it once, twice, three times or

four times.

zEnable or disable the Meeting profile in the standby

mode (by pressing and holding it).

zProvide different functions according to the phone

features being used.

zEnter the # symbol.

zLock the keypad in the standby mode (by pressing

and holding it).

zProvide different functions according to the phone

features being used.

3 Screen Icons

Icon Description

Indicates the signal strength.

There is no network signal.

There is an incoming call, a call is being set up, or your

phone is in conversation.

The keypad is locked.

An alarm clock is set.

The Voice Privacy function is activated during a call.

A new message is received.

The memory for saving messages is full.

An urgent message is received.

A new voice mail is received.

General profile is activated.

Silence profile is activated.

Meeting profile is activated.

Outdoor profile is activated.

My profile 1 or My profile 2 is activated.

The hands free function is activated.

Icon Description

The current network type of the phone is CDMA2000

1X.

The phone is in the domestic roaming status.

The phone is in the overseas roaming status.

Indicates the battery power level.

4 Menu Tree

1AllCalls

2MissedCalls

3 Received Calls

4 Dialled Calls

5CallMemo

6 Call Duration

1 Create Message

2Inbox

3Outbox

4Drafts

5VoiceMail

6 Templates

7Recipient List

8MyFolder

9Settings

0Delete All

1 Automatic Tuning

2 Manual Tuning

1Search

2Search By

Location

3AddNew

4 Groups

5 SpeedDial

6MyNumber

7 Management

Contacts

3 FineTuning

4 Set Frequency

(Options when no

channel saved)

(Options when some

channels saved)

1SwitchOff

2 Speaker On/Off

3StartRecord

4 Tuning

5 Delete Channel

6 Rename Channel

Radio

Messages

Call Log

1General

2Silence

3Meeting

4Outdoor

5MyProfile1

6MyProfile2

1 Display Settings

2Date&Time

3 Call Settings

4 PhoneSettings

5 Security Settings

6 Restore Factory

Settings

1Recorder

2Alarms

3Scheduler

4Calculator

5Stopwatch

6 World Clock

7Gallery

Gulper

Tools

9Minicricket

Profiles

Settings

1AllCalls

2MissedCalls

3 Received Calls

4 Dialled Calls

5CallMemo

6 Call Duration

1 Create Message

2Inbox

3Outbox

4Drafts

5VoiceMail

6 Templates

7Recipient List

8MyFolder

9Settings

0Delete All

1 Automatic Tuning

2 Manual Tuning

1Search

2Search By

Location

3AddNew

4 Groups

5 SpeedDial

6MyNumber

7 Management

Contacts

3 FineTuning

4 Set Frequency

(Options when no

channel saved)

(Options when some

channels saved)

1SwitchOff

2 Speaker On/Off

3StartRecord

4 Tuning

5 Delete Channel

6 Rename Channel

Radio

Profiles

Messages

Call Log

1General

2Silence

3Meeting

4Outdoor

5MyProfile1

6MyProfile2

1 Display Settings

2Date&Time

3 Call Settings

4 PhoneSettings

5 Security Settings

6 Restore Factory

Settings

1Recorder

2Alarms

3Scheduler

4Calculator

5Stopwatch

6 World Clock

7Gallery

Gulper

ToolsTools

9Minicricket

SettingsSettings
