Huawei Mobile Phone Manuale utente
Notice
Copyright © Huawei Technologies Co., Ltd. 2010. All rights reserved.
Trademarks and Permissions
, HUAWEI and are trademarks or registered trademarks of Huawei
Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are
the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION
TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR
ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOOD-
WILL OR ANTICIPATED SAVINGS.
Getting Started
1
1 Getting Started
About This Guide
This guide describes how to find and use the menu functions on your
phone.
All the pictures in this guide are for your reference only. The actual appear-
ance and display depend on the mobile phone you purchase.
Packing List
Your phone package box contains the following:
• One mobile phone
• One Li-ion battery
• One travel charger
• One USB data cable
• One Quick Start Guide
• One Headset
2
Getting Started
Installing SIM Card and Memory Card
Insert your SIM card before using your phone. Remove the SIM card and
the battery only after powering off your phone. To use the SIM card
properly, please read the following instructions carefully.
NOTE:
• Keep the SIM card out of the reach of children.
• The SIM card and its metal contacts can be easily damaged by
scratching or bending. Be careful when you carry , insert or remove
the SIM card.
• Always disconnect the charger from the phone before loading or
removing the SIM card.
Your phone supports a memory card (microSD) with a capacity of up to 8
GB.
To load or remove the memory card, remove the battery cover.
Getting Started
3
The following figures show the installation of the SIM card and memory
card.
Charging the Battery
NOTE:
• The battery discharges even while not being used. If you have not
used it for a long time, please recharge it first.
1 Remove the battery cover.
2 Insert the SIM card.
3 (Optional) Insert the memory card.
4 Insert the battery.
4
Getting Started
• Do not strike, throw or cause any kind of violent shock to the battery,
otherwise liquid leakage, body damage, overheating, fire or explosion
may occur.
• The battery can be recharged but eventually wears out. If the battery
lasts for a shorter time period than usual after being charged normally,
replace it with a battery of the same type.
• Charge the battery by using the charger connector and the USB cable
supplied with your phone.
Before charging the battery, ensure that the battery has been properly
loaded into your phone.
1. Connect the USB interface of the USB cable to the travel charger.
2. Plug in the travel charger to a power socket.
3. Connect the mini USB interface of the USB cable to the charger
connector of your phone. When the battery is being charged, the
charging indicator blinks continuously.
4. When the charging indicator stops blinking, it indicates that the battery
is full. Disconnect the charger connector from the power socket.
5. Disconnect the USB cable from the phone.
Getting Started
5
NOTE: The plug of the cable is in trapezium shape. Reversely
inserting the plug may damage the mobile phone and the charger.
6
Getting Started
Getting to Know Your Phone
Appearance of Your Phone
1 Left function
key
2 Send key 3 Menu key
4 Scroll key 5 Camera key 6 Clear key
7 Volume key 8 Power/End
key
9 Right function
key
10 OK key 11 Camera
Getting Started
7
Left function
key/Right
function key
Perform the corresponding functions displayed
above these keys.
Send key Answer a call or view call records in standby
mode.
Menu key Quick access to Menu.
Scroll key Scroll through a menu.
Camera key • Short press to activate the camera.
• Long press to activate the flashlight.
Clear key Delete characters to the left of the cursor in input
mode.
Power/End key • Switch on and off your phone by holding down
this key.
• Return to the standby mode and reject or end
a call.
OK key Perform the corresponding functions displayed
above OK key.
8
Getting Started
Home Screen
1 Icon bar
2Desktop
3 Prompt bar
Indicates signal
strength.
Alarm clock is
enabled.
Indicates power level
of the battery.
The normal profile
is activated.
Getting Started
9
The phone is currently
in a GSM network.
The headset is
plugged in.
The phone is currently
in a WCDMA network.
You have new text
messages.
You are using the
roaming service.
You have new
multimedia
messages.
Bluetooth is enabled. You have new
PUSH messages.
Your phone connects
with your PC.
You have a new
voice message
waiting.
Call in progress.
