Huawei PAR-LX1 Manuale utente
Quick Start Guide
PAR-TL20
PAR-LX1M
PAR-LX1
PAR-LX9
Your Device at a Glance
Before you start, let's take a look at your new device.
lTo power on your device, press and hold the power button
until the screen turns on.
lTo power off your device, press and hold the power button,
and then touch .
lTo restart your device, press and hold the power button,
and then touch .
lPress and hold the power button for 10 or more seconds to
forcibly restart your device.
/'$
2
1
5
6
7
3
4
13
16
15
14
11
12
10
9
8
Light sensor Secondary microphone
Rear camera Flash
Fingerprint scanner Headset jack
USB-C port Primary microphone
Speaker Power button
Volume button Card slot
Front camera Infrared sensor
Status indicator Earpiece
lOnly PAR-LX1 supports NFC. Please keep the NFC area
close to other devices or objects while using the NFC
function.
1
Getting Started
lDo not insert or remove the SIM card when your device
is powered on.
lEnsure that the card is correctly aligned and that the
card tray is level when you insert it into your device.
lBe careful not to scratch your device or hurt yourself
when using the eject pin.
lStore the eject pin out of the reach of children to
prevent accidental swallowing or injury.
lDo not use cut or modied SIM or microSD cards with
your device as these may not be recognized and could
damage the card tray (slot).
lIf your SIM card does not match your device, please
contact your carrier.
Follow the instructions in the following gures to set up your
device. Please use the eject pin included.
Single-SIM:
12
OBOP4*.
OBOP4*.
OBOP4*.
Dual-SIM:
12
OBOP4*.
OBOP4*.
OBOP4*.
or
2
Dual Card Dual Standby Single
Pass (dual-SIM devices only)
Your device supports only dual card dual standby single pass,
which means you cannot use both SIM cards for calls or data
services simultaneously.
lWhen you are on a call using SIM card 1, SIM card 2 cannot
be used to make or answer calls. If someone calls SIM card
2, the caller will hear a voice message similar to "The
subscriber you dialed is out of the service area" or "The
subscriber you dialed cannot be connected for the moment,
please try again later." The actual message will vary by
service provider.
lWhen you are using SIM card 1's data service, SIM card 2's
data service will be disabled.
Your device's single pass feature helps reduce power
consumption and increase your device's standby time. It is not
related to your service provider's network conditions.
You can go to Settings > Wireless & networks > Dual SIM
settings, and enable Enable call forwarding between SIMs
to avoid the conicts mentioned above.
3
For More Information
If you encounter any problems while using your device, you
can obtain help from the following resources:
lGo to Tips for function details and usage tips.
lVisit http://consumer.huawei.com/en to view device
information, frequently asked questions and other
information.
lVisit http://consumer.huawei.com/en/support for the most
up-to-date contact information for your country or region.
Go to Settings and touch System > About phone > Legal to
view legal information for your product.
Go to Settings and touch System > About phone > Legal >
Safety information to view safety information for your
product.
Go to Settings and touch System > About phone >
Authentication info to view regulatory information for your
product.
PAR-LX9: Go to Settings and touch System > Certication
logos to view more information on certication logos for your
product.
All pictures and illustrations in this guide, including but
not limited to the device color, size, and display content,
are for your reference only. The actual device may vary.
Nothing in this guide constitutes a warranty of any kind,
express or implied.
4
Safety Information
Please read all of the safety information carefully before using
your device to ensure its safe and proper operation and to
learn how to dispose of your device properly.
Operation and safety
l To prevent possible hearing damage, do not
listen at high volume levels for long periods.
lUsing an unapproved or incompatible power adapter,
charger, or battery may damage your device, shorten its
lifespan, or cause a re, explosion, or other hazards.
lIdeal operating temperatures are 0 °C to 35 °C. Ideal
storage temperatures are -20 °C to +45 °C.
lPacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If using a pacemaker, hold the device on the
side opposite the pacemaker and do not carry the device in
your front pocket.
lKeep the device and the battery away from excessive heat
and direct sunlight. Do not place them on or in heating
devices, such as microwave ovens, stoves, or radiators.
lObserve local laws and regulations while using the device.
To reduce the risk of accidents, do not use your wireless
device while driving.
lWhile ying in an aircraft or immediately before boarding,
only use your device according to instructions provided. Use
of a wireless device in an aircraft may disrupt wireless
networks, present a hazard to aircraft operation, or be
illegal.
lTo prevent damage to your device's parts or internal
circuits, do not use it in dusty, smoky, damp, or dirty
environments or near magnetic elds.
lWhen charging the device, make sure the power adapter is
plugged into a socket near the devices and is easily
accessible.
lUnplug the charger from electrical outlets and the device
when not in use.
lDo not use, store or transport the device where ammables
or explosives are stored (in a gas station, oil depot, or
5
chemical plant, for example). Using your device in these
environments increases the risk of explosion or re.
lDispose of this device, the battery, and accessories
according to local regulations. They should not be disposed
of in normal household waste. Improper battery use may
lead to re, explosion, or other hazards.
Disposal and recycling information
The crossed-out wheeled-bin symbol on your product, battery,
literature or packaging reminds you that all electronic products
and batteries must be taken to separate waste collection
points at the end of their working lives; they must not be
disposed of in the normal waste stream with household
garbage. It is the responsibility of the user to dispose of the
equipment using a designated collection point or service for
separate recycling of waste electrical and electronic equipment
(WEEE) and batteries according to local laws.
Proper collection and recycling of your equipment helps ensure
electrical and electronic equipment (EEE) waste is recycled in a
manner that conserves valuable materials and protects human
health and the environment, improper handling, accidental
breakage, damage, and/or improper recycling at the end of its
life may be harmful for health and environment. For more
information about where and how to drop off your EEE waste,
please contact your local authorities, retailer or household
waste disposal service or visit the website http://
consumer.huawei.com/en/.
Reduction of hazardous substances
This device and its electrical accessories are compliant with
local applicable rules on the restriction of the use of certain
hazardous substances in electrical and electronic equipment,
such as EU REACH, RoHS and Batteries (where included)
regulations. For declarations of conformity about REACH and
RoHS, please visit our web site http://consumer.huawei.com/
certication.
EU regulatory conformance
Body worn operation
The device complies with RF specications when used near
your ear or at a distance of 0.50 cm from your body. Ensure
that the device accessories, such as a device case and device
6
holster, are not composed of metal components. Keep the
device away from your body to meet the distance requirement.
The highest SAR value reported for this device type when
tested at the ear is
PAR-LX1 0.76 W/kg
PAR-LX9 0.75 W/kg
PAR-LX1M 1.13 W/kg
PAR-TL20 0.99 W/kg
And when properly worn on the body is
PAR-LX1 1.19 W/kg
PAR-LX9 0.84 W/kg
PAR-LX1M 1.27 W/kg
PAR-TL20 1.11 W/kg
Statement
Hereby, Huawei Technologies Co., Ltd. declares that this device
PAR-LX1 / PAR-LX9 / PAR-LX1M / PAR-TL20 is in compliance
with the essential requirements and other relevant provisions
of Directive 2014/53/EU.
The most recent and valid version of the DoC (Declaration of
Conformity) can be viewed at http://consumer.huawei.com/
certication.
This device may be operated in all member states of the EU.
Observe national and local regulations where the device is
used.
This device may be restricted for use, depending on the local
network.
Restrictions in the 2.4 GHz band:
Norway: This subsection does not apply for the geographical
area within a radius of 20 km from the centre of Ny-Ålesund.
Restrictions in the 5 GHz band:
According to Article 10 (10) of Directive 2014/53/EU, the
packaging shows that this radio equipment will be subject to
some restrictions when placed on the market in Belgium (BE),
Bulgaria (BG), the Czech Republic (CZ), Denmark (DK),
Germany (DE), Estonia (EE), Ireland (IE), Greece (EL), Spain (ES),
France (FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia (LV),
Lithuania (LT), Luxembourg (LU), Hungary (HU), Malta (MT),
Netherlands (NL), Austria (AT), Poland (PL), Portugal (PT),
Romania (RO), Slovenia (SI), Slovakia (SK), Finland (FI), Sweden
(SE), the United Kingdom (UK), Turkey (TR), Norway (NO),
Switzerland (CH), Iceland (IS), and Liechtenstein (LI).
7
The WLAN function for this device is restricted to indoor use
only when operating in the 5150 to 5350 MHz frequency
range.
Frequency Bands and Power
(a) Frequency bands in which the radio equipment operates:
Some bands may not be available in all countries or all areas.
Please contact the local carrier for more details.
(b) Maximum radio-frequency power transmitted in the
frequency bands in which the radio equipment operates: The
maximum power for all bands is less than the highest limit
value specied in the related Harmonized Standard.
The frequency bands and transmitting power (radiated and/or
conducted) nominal limits applicable to this radio equipment
are as follows:
PAR-LX1 GSM 900:35dBm, GSM 1800:32dBm, WCDMA
900/2100:25.7dBm, LTE Band
1/3/7/8/20:25.7dBm, Wi-Fi 2.4G:20dBm,
Bluetooth:20dBm, Wi-Fi 5G:5150-5350MHz:
23dBm, 5470-5725MHz:30dBm,NFC: 42
dBuA/m at 10m
PAR-LX9 GSM 900:35dBm, GSM 1800:32dBm, WCDMA
900/2100:25.7dBm, LTE Band
1/3/7/8/28/38/40:25.7dBm, Wi-Fi 2.4G:20dBm,
Bluetooth:20dBm, Wi-Fi 5G:5150-5350MHz:
23dBm, 5470-5725MHz:30dBm
PAR-LX1M GSM 900:35dBm, GSM 1800:32dBm, WCDMA
900/2100:25.7dBm, LTE Band
1/3/7/8/20:25.7dBm, Wi-Fi 2.4G:20dBm,
Bluetooth:20dBm, Wi-Fi 5G:5150-5350MHz:
23dBm, 5470-5725MHz:30dBm
PAR-TL20 GSM 900:35dBm, GSM 1800:32dBm, WCDMA
900/2100:25.7dBm, LTE Band
1/3/7/8/34/38/40:25.7dBm, Wi-Fi 2.4G:20dBm,
Bluetooth:20dBm, Wi-Fi 5G:5150-5350MHz:
23dBm, 5470-5725MHz:30dBm
Accessories and Software Information
Some accessories are optional in certain countries or regions.
Optional accessories can be purchased from a licensed vendor
as required. The following accessories are recommended:
Adapters: HW-059200XHQ HW-090200XH0 (X represents the
different plug types used, which can be either C, U, J, E, B, A, I,
R, Z or K, depending on your region)
Batteries: HB386589ECW
8
Earphones: EMC309-001 MEMD1632B580C00
1311-3291-3.5mm-229
The product software version is PAR-LX1: PAR-LX1
8.2.0.103(SP3C900) / PAR-LX9: PAR-LX9
8.2.0.106(SP10C900) / PAR-LX1M: PAR-LX1M
8.2.0.103(C900) / PAR-TL20: PAR-TL20 8.2.0.107(SP1C900).
Software updates will be released by the manufacturer to x
bugs or enhance functions after the product has been
released. All software versions released by the manufacturer
have been veried and are still compliant with the related
rules.
All RF parameters (for example, frequency range and output
power) are not accessible to the user, and cannot be changed
by the user.
For the most recent information about accessories and
software, please see the DoC (Declaration of Conformity) at
http://consumer.huawei.com/certication.
ErP Product Information (only applies to PAR-
LX1)
Huawei Technologies Co., Ltd. hereby declares that its
products conform to the Energy-related Products Directive
(ErP) 2009/125/EC. For detailed ErP information and the user
manuals required by Commission Regulation, please visit:
http://consumer.huawei.com/en/certication.
FCC Regulatory Compliance (only applies to PAR-
LX9)
Body worn operation
The device complies with RF specications when used near
your ear or at a distance of 1.50 cm from your body. Ensure
that the device accessories, such as a device case and device
holster, are not composed of metal components. Keep the
device away from your body to meet the distance requirement.
Certication information (SAR)
This device is also designed to meet the requirements for
exposure to radio waves established by the Federal
Communications Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported to the FCC
for this device type complies with this limit.
The highest SAR value reported to the FCC for this device type
when using it at the ear is
PAR-LX9 1.07 W/kg
9
Questo manuale è adatto per i seguenti modelli
3
Indice
Altri manuali Huawei Telefono cellulare
Huawei
Huawei U8300 Manuale utente
Huawei
Huawei P60 Pro Manuale utente
Huawei
Huawei MYA-L11 Manuale utente
Huawei
Huawei ANA-LX4 Manuale utente
Huawei
Huawei Ascend Y300 Manuale utente
Huawei
Huawei ASCEND G620 Manuale utente
Huawei
Huawei M735 Manuale utente
Huawei
Huawei Y3 Lite Manuale utente
Huawei
Huawei Ascend G525 Manuale utente
Huawei
Huawei P10 LITE Manuale utente
Huawei
Huawei DiscoveryPhone Manuale utente
Huawei
Huawei Ascend II M865 Manuale utente
Huawei
Huawei U8150-B Manuale utente
Huawei
Huawei Ascend Mate7 Manuale utente
Huawei
Huawei FRL-L21 Manuale utente
Huawei
Huawei Ascend Y330-U08 Manuale utente
Huawei
Huawei Nova Plus Manuale utente
Huawei
Huawei P30 Pro Manuale utente
Huawei
Huawei U8500 Manuale utente
Huawei
Huawei C2828 Manuale utente
