Huawei T202 Manuale utente
T202
GSM Dual Band Mobile Phone
Copyright © 2008 Huawei Technologies Co., Ltd.
and other Huawei trademarks are the trademarks or registered trademarks of Huawei Technologies Co., Ltd.
in the People’s Republic of China and certain other countries. All other trademarks mentioned in this manual are the
property of their respective holders. The information in this manual is subject to change without notice. Every effort
has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information,
and recommendations in this manual do not constitute the warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China
Tel: +86-755-28780808 Global Hotline: +86-755-28560808
1
Your Phone
Screen
Dial/Send Key
Number Keys
Navigation Keys
LeftSoftKey
Key
Microphone
Headset Jack
Right Soft Key
Earpiece
Charger Interface
End/Power Ke
y
Key
2
Keys and Functions
Press… To…
zMake or answer a call.
zView all call records in the standby mode.
zPower on or off the phone (by pressing
and holding this key).
zEnd a call or reject an incoming call.
zReturn to the standby mode.
Select the option displayed on the lower left
corner of the screen.
Select the option displayed on the lower
right corner of the screen.
zAccess the New screen for writing a new
message ( ), Messages ( ), the
Call History screen for writing a new
message ( ), and Alarm ( ).
zIncrease the volume ( or ) and
decrease the volume ( or ) during a
call.
3
Press… To…
–
zEnter numbers and characters.
zSpeed dial phone numbers in the standby
mode (by pressing and holding the 1-9
keys).
zSelect a submenu item labeled with the
corresponding number.
zEnter the * symbol.
zActivate or deactivate the Meeting profile
(by pressing and holding it) in the standby
mode.
zProvide different functions according to
the phone features being used.
zEnter the # symbol.
zLock the keypad in the standby mode (by
pressing and holding it).
zProvide different functions according to
the phone features being used.
4
Screen Icons
Icon Description Icon Description
Indicates the
signal strength. Indicates the battery
level.
The headset is
connected. The call is
transferred.
The Silent profile
is activated. An alarm clock is set.
The keypad is
locked.
Memory for saving
messages on the
phone is full.
The Custom
profile is
activated.
The battery power
level is extremely
low.
The Outdoor
profile is
activated. Unread SMS
The Meeting
profile is
activated. Unread voice mail
5
Menu Tree
1 Call Waiting
2 Call Forwarding
3 Call Barring
4 Network Select
1 Alarm1
2 Alarm2
3 Alarm3
Display
1 General
2 Meeting
3 Outdoor
4 Silent
1 Contacts
2 Add New
3 Speed Dials
4 Memory Status
1 Missed Calls
2 Answered Calls
3 Dialed Calls
1 Backlight
2 Contrast
Phone Book
Call History
STK
Network Service
Profiles
Alarm
You can consult
your service
provider for more
information about
this function.
Messages
Settings
1 Time&Date
2 Auto Keypad
Lock
3 Language
4 Security
5 Factory Reset
6 Version
1 Write
2 Inbox
3 Outbox
4 Drafts
5 Voicemail
6 Settings
7 Memory Status
6
Installing the SIM Card and Battery
Make sure that the golden area on the SIM card is facing
downwards and the cut-off edge is correctly aligned with
the card holder.
Removing the Battery and SIM Card
Make sure that your phone is powered off.
Charging the Battery
1. Connect the charger to the charger interface at the
bottom of your phone.
2. Connect the charger to an AC power socket.
3. During the charging process, the charging icon is in
animated status.
7
4. When the charging icon becomes static, the battery is
completely charged. Then you can disconnect the
charger from the AC power socket.
5. Disconnect the charger from the phone.
Using the Function Menu
1. In the standby mode, press (Menu) or to
display the main menu.
2. Press , , or to select a menu item.
3. Press (Select) or to display the selected
menu.
4. Display the submenu in either of the ways:
zPress , , or to scroll to a submenu
and press (Select) or to display the
selected submenu.
zPress the number key corresponding to the serial
number of a submenu to display the submenu.
5. Press (Back) to return to the previous menu or
quit the function menu.
Note When you start to charge a completely
discharged battery, the charging indicator may
appear on the screen several minutes later. You
can make and receive calls untill the indicator
appears.
8
6. Press to return to the standby mode.
Making a Call
1. In the standby mode, enter a phone number.
zTo make an international call, press twice to
enter the international long distance code of "+".
Then, enter the number to be dialed in the "country
code + region code + phone number" format.
zTo call a number with an extension, press three
times to insert "P".
2. Press to dial the number.
3. Press to end the call.
Note zWhen the phone is locked, enter the lock code to
unlock the phone first; otherwise, you can only
make emergency calls and answer calls.
zIn the standby mode, press to view all call
records. Select a record and press to dial.
zSelect a contact from the phonebook and press
to dial.
zSelect a message in the inbox and press to
dial.
9
Answering a Call
When there is an incoming call, you can press or
(Accept) to answer it; press (Reject) to
mute the ringtone; press to reject the call. If the
Any-key Answer function is enabled, you can press
any key except and to answer an incoming
call.
Activating the Loudspeaker
During a call, press (Menu) and select
handheld/free to activate or deactivate the loudspeaker
of your phone.
PIN and PUK
The personal identification number (PIN) protects your
SIM card from unauthorized use. The PIN unlocking key
(PUK) can unblock the blocked PIN. Both PIN and PUK
are delivered with the SIM card. For details, consult your
service provider.
If you enter wrong PINs for a specified number of times
consecutively, the phone asks you to enter the PUK
code.
If you enter wrong PUKs for a specified number of times
consecutively, the SIM card is invalid permanently.
Contact your service provider for a new card.
