Huawei U8220 Manuale utente
1
What's in the Box
Your phone box contains the following items:
•Mobile phone
•Battery
•Charger
•USB cable
•Headset
•Quick start guide
•Safty information
For more information about how to use your phone,
refer to the User Guide on the phone.
To read the User Guide, do as follows:
1. Connect your phone to a PC.
2. On the PC, choose Start > My Computer.
3. Double-click the Huawei logo, and then select User
Guide.
2
Getting to Know
Your Phone
113
Microphone
Home/BackMenu
Trackball
Send
Connectors on the top
Power
Speaker
Charge/Data port
Touch
screen
Earpiece
Secondary
camera
Volume
keys
Capture
End
microSD
card slot
Headset jack
Main camera
MENU
key
3
Before
Getting Started
Installing the SIM Card
Installing the microSD Card
Installing the Battery
1 2
1 2
1
2
1
3
2
4
Charging
the Battery
Before charging the battery, make sure that the battery has
been properly inserted into your mobile phone.
Connect your USB cable to your mobile phone, as shown
in a.
Connect the other end of the cable to the charger,
as shown in b.
Plug the charger into a power socket.
The phone starts charging, with the charging icon displayed
in animation on the screen.
5
Setting up
Your Phone
The first time you power on your mobile phone, the phone
displays a setup wizard to instruct you to set the phone,
including:
•Using the onscreen keyboard
•Setting up your accounts
•Other important settings
Powering On or Off Your Phone
•Press to power on your phone.
•Press and hold to open the Phone options menu.
Then touch Power off > OK to power off.
Setting up Your Phone
6
Your Canvas Screen
Display area
Interface switching buttons
Locking the Screen Unlocking the Screen
Notifications
bar
Canvas Screen View
• When your mobile
phone is on, press to
lock the screen.
• If you leave your
phone idle for a while,
the screen will lock
automatically.
Press the , or to
wake up the screen. Then
unlock it by doing any of the
following:
• Press the to unlock the
screen.
• Drag the lock icon from left
to right to unlock the screen.
MENU
key
MENU
key
7
Expand the Canvas
The Canvas is a desktop which you can freely define and
expand. You can do the following things on the Canvas
desktop:
•Expand your screen display in any
direction.
•Customize the Home screen.
•Create and arrange shortcuts.
•Create and arrange widgets.
•Create and arrange folders.
•Define and switch between
wallpapers.
8
Widgets
A widget works as a shortcut to let you preview or use an
application.
You can stick widgets on your desktop as icons or preview
windows.
Besides the default widgets installed on your phone, you can
also download more from Android Market.
9
Calling
Answering or Rejecting an Incoming Call
Answering:
Rejecting:
Touch to switch
among Phone,
Call log,Contacts,
and Favorites.
Touch to dial.
Touch to make a
voicemail.
Touch to erase
numbers.
Displays the
number you enter.
Touch to browser
all the matching
contacts.
Touch and hold to
enter +.
Dialer
Touch > Dialer to display the dialer.
• Press to answer the call.
• Drag to the right.
• Press to reject a call.
• Drag to the left.
10
Entering Text
•On the Canvas screen, press and hold the to show the
keyboard.
•Touch the space where you write text to show the keyboard.
•Press to hide the keyboard.
Touch and hold the space where you write your text until
the Edit text menu is displayed. Touch Input Method.
Using the Onscreen Keyboard
Switching the Input Method
Switching TouchPal Keyboard Layout
MENU
key
