Huawei E156G Manuale utente

Published by Hutchison 3G UK Limited, trading as 3. All rights

in this publication are reserved and no part may be reproduced

without the prior written permission of the publisher.

company. Huawei Technologies Co., Ltd is the manufacturer

of the USB Modem and has provided the information

on its features and use set out in this user guide.

The contents are believed to be correct at the time of

going to press, but any information, products or services

mentioned may be modied, supplemented or withdrawn.

The provision of any products and services by Hutchison

3G UK Limited using Huawei USB Modem is subject

to 3’s customer terms (available at three.co.uk).

‘3’ and related images, logos and names referred

to in this publication are trademarks of the

Hutchison Whampoa group of companies.

This publication is printed on fully recyclable paper.

www.huawei.com

DD_0908_8131_E156GugB DD0822801 Sep08

0822801 E156G USB Modem UG.aw(B)1 1 25/9/08 10:02:41

User Guide.

Huawei E156G

0822801 E156G USB Modem UG.aw(B)2 2 25/9/08 10:02:55

and play.

Plug

0822801 E156G USB Modem UG.aw(B)3 3 25/9/08 10:03:03

No more wires, no more hassles, no more waiting for

a line to be installed.

Just plug your new USB modem into your laptop and

within ve minutes you’re on the web. You can even

swap your modem between computers and get your

broadband when you’re out and about.

Visit three.co.uk/broadband

Call Customer Services on 500 from your

3 mobile (0870 7330 320 from another phone).

Calls charged at your standard rate.

If you get stuck, just get in touch for help.

0822801 E156G USB Modem UG.aw(B)4 4 25/9/08 10:03:10

Ready?

First, double-check that:

1 You’re running either Windows 2000 / XP / Vista for a PC or OS X for a Mac.

2 Your computer or laptop meets or exceeds the minimum operating requirements

for your operating system (Windows or Mac OS X).

3 Your computer or laptop also has a display resolution of at least 800 x 600.

4 You have the log in details and any password needed to install software (business

users may need ‘administrator rights’).

5 Finally, if you have anti-virus protection or a firewall, you may need to switch

these off when installing your USB modem software or ‘allow’ installation.

0822801 E156G USB Modem UG.aw(B)5 5 25/9/08 10:03:10

Get set.

Slotting in your SIM

1 Remove the cap on the end of your USB modem.

2 Pull out the SIM card holder.

3 Insert your SIM card into the holder, as shown.

4 Place the SIM card holder (with the tted SIM) back in your USB modem, as shown.

1 2 3 4

0822801 E156G USB Modem UG.aw(B)6 6 25/9/08 10:03:10

Go.

All the clever bits and bobs you need (‘drivers’, if we’re getting technical) are already

loaded onto your USB modem. All you need to do is connect it to your laptop or computer

and follow the on-screen instructions.

You can connect your USB modem to your computer in two ways

1 Simply plug your USB modem into the USB port.

2 Use the cable supplied (this might improve performance in weaker network

coverage areas).

Once you’re connected, the light under the 3 logo on your USB modem will change

from green to blue.

Troubleshooting tip: You’ve switched your computer on. You’ve plugged

your dongle in. And now nothing is happening? Make sure you’ve given your

computer enough time to finish starting up before you insert your dongle.

0822801 E156G USB Modem UG.aw(B)7 7 25/9/08 10:03:12

Installing your software onto your PC

Once your USB modem is connected, you may have to wait a few minutes before anything

happens (about the time it takes a kettle to boil). Then:

> Read and accept the User Licence Agreement, if it pops up

> Follow the Wizard and the software will be installed automatically

(Don’t follow the Windows Driver Installation Wizard

if offered because that won’t fully install the software)

The software takes a few seconds or a few minutes to install, depending on your computer

(about the time it takes to drink a cup of tea or coffee).

Installing your software onto your Mac

Once your USB modem is connected, you should see a 3Connect icon on

your desktop. Click on it. Then:

> Open the 3Connect Installer software

> Read and accept the User Licence Agreement, if asked

> Enter your password or admin log in, if asked

The 3Connect software will be automatically installed in your Applications folder.

Troubleshooting tip: Your computer can’t detect

your dongle? Try inserting it into another free USB port.

0822801 E156G USB Modem UG.aw(B)8 8 25/9/08 10:03:12

Using your USB modem.

Once the software is installed, all you need to do each time you want to use your

USB modem is connect it and then wait for the following screen to appear. It should

take about 30 seconds and when it pops up click on Connect.

On Pay As You Go Mobile Broadband and need your 3 mobile number to top up?

No problem.

On a PC…

Select the My Account tab on screen and you’ll instantly see your 3 mobile number

(+4478 followed by 8 more digits, just like a regular mobile phone number).

On a Mac…

Select the Tools menu, then HSDPA / UMTS / GPRS Options, followed by

My Account to see your 3 mobile number (+4478 followed by 8 more digits,

just like a regular mobile phone number).

PC version Mac version

Troubleshooting tip: Won’t let you connect? Check to make sure you have

inserted your SIM card into your dongle correctly. See page 5 for details.

0822801 E156G USB Modem UG.aw(B)9 9 25/9/08 10:03:13

The network will show you if your connection is successful. Then you’re ready to start using

the internet, just like you would do on any other computer. To end your internet session,

just click on Disconnect.

What do the different colour lights on the USB modem mean?

lGreen Light You are connected to the GPRS/EDGE network (fast)

lBlue Light You are connected to the 3G network (faster)

lCyan Light You are connected to the HSDPA network (fastest)

Keep track of your usage on My3

> My3 is a free service where you can check your usage and spending, see what’s left,

buy Top-ups or Add-ons and convert Mobile Broadband Add-ons. It’s there to help

you, so well worth a look.

> You can get straight on to My3 by going to My Account and clicking Open on your

broadband software. Or visit three.co.uk/my3 anytime – even if you’re out of

credit – and use your 3 mobile number (you’ll nd this on the My Account tab) to log

in. You’ll need to register rst, which takes a few moments.

0822801 E156G USB Modem UG.aw(B)10 10 25/9/08 10:03:13
