Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

Model:

Huawei E160e Mobile Internet Modem

Huawei E169 Mobile Internet Modem

Website:

http://www.huawei.com/en/

1. Plug the Huawei E160 / E169 into an available USB Port.

2. Allow Finder to open a window containing the modem contents.

Select “Wireless Broadband” (see figure 1 below)

Figure 1

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

3. Right click on “Wireless Broadband”, select “Show Package Contents” (See figure 2

below)

Figure 2

4. A new window will open (or the current window may change) to display a folder called

“Contents” (See figure 3 below)

Figure 3

5. Open the “Contents” directory, this will offer multiple options (see Figure 4 below),

open “Resources” execute the package “Mobile_Drv_app.pkg”

Figure 4

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

6. Run through the Wireless Broadband Installation

a. “Welcome to the Wireless Broadband Installer”, click “Continue”

Figure 5

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

b. “Software License Agreement”, click “Continue”, if prompted to agree to the

terms and conditions, select “Agree” or “Ok”.

Figure 6

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

c. “Standard Install”, click “Install”

Figure 7

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

d. Approval to install, your Mac will request approval to install the application

input your “Administrator” credentials, then click “OK”

Figure 8

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

e. Installation will commence.

Figure 9

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

7. Installation will complete, click “Close” to close the install dialog window.

Figure 10

8. Once install has completed, navigate to “Finder” > “Applications”, execute “Wireless

Broadband” if requested enter the SP Code as: 357i4

Figure 11

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

9. Close the Wireless Broadband Application.

10.From the upper left hand corner of the screen select the “Apple” icon then “System

Preferences”.

Figure 12

Huawei E160e & E169 –Configuration (Mac OS 10.6, Snow Leopard)

Level 5

10 William St

Perth, WA, 6000

Ph: 1300 139 550

Fax: 1300 794 469

[email protected]m.au

www.highway1.com.au

Highway 1 (Aust) Pty. Ltd.

ACN: 066 394 509

ABN: 48 066 394 509

11.From the “System Preferences” dialog window, select “Network”

Figure 13
