Huawei HG658 Manuale utente

Modem Conguration Guide

HG658

Conguring in Layer2 PPPoE for Windows 8

IMPORTANT MESSAGE

Your modem has already been pre-conﬁgured, you do not need to follow each step of the set-up guide but should retain

this document in case you need to manually conﬁgure your equipment.

To conﬁgure your PC/Laptop with your wireless password including changing your wireless password, please

proceed to step 4.

Contents

1. Physical Connection

2. Network Conﬁguration

3. Conﬁguring Modem

4. Conﬁguring Wireless

5. Change of Password

1. PHYSICAL CONNECTION

Have your modem powered on and connected directly to your PC via Ethernet Cable before you begin, as these

instructions are based on wired Ethernet connection

1. Connect the Power port on the back of your modem to your power socket.

2. Connect the DSL port on the back of the modem to your telephone wall socket.

3. Connect your telephone handset to the Phone1 port on the back of your modem.

4. Connect your PC to any of the 4 LAN ports on the back of your modem.

2. NETWORK CONFIGURATION

PPPoE connection does not require you to have an IP address or DNS settings manually encoded on your network card.

PPPoE connection uses authentication to establish the Internet connection and once connected your modem will be

assigned an IP and DNS settings from TPG.

To begin, your PC needs to receive a private IP address from the modem. Most modems have DHCP enabled by default

that will take care of this.

HG658

Wi-Fi Modem

Telephone

Power Socket

Wall Socket

1 3 4

Modem Conguration Guide HG658

C. Click on Internet Protocol Version 4 (TCP/IPv4), and then click

Properties

3. CONFIGURING MODEM

A. Open your browser and in the address bar type

http://192.168.1.1 and press Enter

B. Enter admin for both the username and password and click Login.

If you have changed the login credentials, please enter the current

username and password for your modem interface.

D. Ensure “Obtain an IP address automatically” is selected

E. Ensure “Obtain DNS server address automatically” is selected

F. Click OK

To ensure your Network Card is ready for this, please follow the following steps:

A. Click Start -> Control Panel -> Network and Internet ->

Network and Sharing Center -> Change adapter settings

B. Right click on Local Area Connection and select Properties

Modem Conguration Guide HG658

4. CONFIGURING WIRELESS

Things you need to know before you begin:

By default the modem that you purchased from TPG is conﬁgured with the following wireless security settings:

SSID (name for the wireless connection): TPG-xxxx (xxxx is a random 4 digit alphanumeric code printed on the sticker

underneath your modem)

Authentication Type: WPA-PSK/WPA2-PSK

Encryption: TKIP/AES

Pre Shared Key: initially conﬁgured to be the same as your TPG password. You can enter your own text as an option.

C. You will see the screen shown on the right. Click Next.

F. Click Submit.

Quick Setup complete!

E. You can change your WiFi details or elect to

keep the default settings. The default WiFi SSID is

TPG-xxxx (xxxx is a random 4 digit alphanumeric

code printed on the sticker underneath your

modem). The WiFi password is set to your TPG

password by default. Click Next.

D. Enter your TPG username and password. Click Next.

Modem Conguration Guide

3. Find the SSID (network name) of your modem

and click Connect By default, the network name

should be TPG-xxxx (xxxx is a random 4 digit

alpha numeric code).

4. Select the Wi-Fi network you wish to connect to.

By default, the Wi-Fi access point name (SSID) is

TPG –xxxx (xxxx is a random 4 digit alphanumeric code)

5. Enter the network security key (Wi-Fi password)

and then click Next. By default, the network

security key is the same as your TPG Password

you use to log into Your Account.

2. Click Settings inside the Charms Bar.

HG658

5. CHANGE OF PASSWORD

For security purposes we highly recommend that you change your password if you are using your default or if you believe your

password security has been compromised. For password information, please visit www.tpg.com.au/support.

PLEASE NOTE:

Each time your modem is powered on, it will initialize this automated authentication process after which your modem will

receive a public IP address (ﬁxed or dynamic depending on your plan) and DNS settings from TPG.

13 14 23tpg.com.au/support

To use Wireless, ensure that you already have set up your wireless adapter.

1. Open the Charms Bar by moving your mouse pointer to the top corner of the screen and then moving your

mouse pointer down. If you have a touch screen, simply swipe from the right side of the screen to the left.
