Huawei Touch Manuale utente

Network cable

HUAWEI Touch

HUAWEI Touch

Quick Start Guide

Power adapter

Type-C cable

Cable

Connections

Appearance

Parts List

Power button: locks

or wakes up the

screen; turns the

Touch on or off.

Stand: adjusts the

screen angle.

Type-C port

PoE port

Kensington lock hole

•Connected to the Touch port on an endpoint and powered

through the Touch port.

•Connected to a switch through a network cable and powered

using the included power adapter.

•Connected to an endpoint over Wi-Fi and powered using the

included power adapter.

Network cable

Network cable

Type-C cable Power adapter

For the settings required for connecting the Touch to an endpoint, see the

configuration guide of the corresponding endpoint model.

Endpoint

Qualification Card,

Safety Precautions,

and Warranty Card

Type-C cable Power adapter

The following images are for reference only. Actual components may differ

in appearance.

HUAWEI Touch

Quick Start Guide

Copyright© Huawei Technologies Co., Ltd. All rights reserved.

HUAWEI Touch is a tablet used to operate Huawei's next-generation

endpoints. The Touch can be:

Touch port on an endpoint

Network port on a switch

HUAWEI Touch

Quick Start Guide

Copyright © Huawei Technologies Co., Ltd. All rights reserved.

Huawei Technologies Co., Ltd.

Huawei Industrial Base, Bantian, Longgang,

Shenzhen 518129, People's Republic of China

Date: 2018-09-30

Part number: 31509884

Issue: 03

http://www.huawei.com

OPEN SOURCE SOFTWARE NOTICE

On the touch panel, choose More > Settings > Open Source

Licenses and view details under Open Source Software Notice.
