HumanCentric 401-1022 Manuale utente

Model 401-1022, 401-1040

www.humancentric.com/patents

PARTS INCLUDED

© 2023 HumanCentric Ventures LLC www.humancentric.com

Desk Shelf

(A) Main Shelf (x1)

(B) Leg, No Notches (x1) (C) Leg, Right Notches (x1) (D) Leg, Left Notches (x1)

(H) Leveling Feet (x4)

(E) Lower Shelf (x1)

*Size will vary based on

Small / Medium / Large

Desk Shelf

*Not included in Small size

Desk Shelf

(G) Machine Screws or

Wood Screws (x4-6) (x4-6)

or

(F) 2.5mm Hex Key or

T15 Torx Key (x1)

or

Full product speciﬁcations: www.humancentric.com/401-1022; www.humancentric.com/401-1040;

Need help? Contact support: [email protected]

WARNING

To reduce the risk of injury to persons, read all important precautions and warnings listed below.

HumanCentric assumes no responsibility for personal injury or property damage sustained by or through

the use of this product:

1. Read all instructions carefully.

2. Incorrect installation may lead to damage or serious injury. Ensure the product is secured before use.

3. When placing this product on your desk, make sure it is sturdy enough to support the weight of the

stand and the items placed on it.

4. This product contains small items that can be choking hazard if swallowed. Keep these items away

from children.

© 2023 HumanCentric Ventures LLC www.humancentric.com

1.

Decide which side to assemble the shelf (for medium and large shelves only).

Lower shelf on right Lower shelf on left

B C D C D B

2.

Partially screw in the leg screws (G) into the pilot holes in the bottom of the shelf using the key (F).

Leave enough space to slide the legs under the screws.

© 2023 HumanCentric Ventures LLC www.humancentric.com

4.

Slide the leg keyholes onto the partially threaded screws. Conﬁrm the front of the legs are orientated

correctly with the front angled face of the shelf top.

Front

Angled

Faces

3.

Push the legs (C) and (D) onto the lower shelf.

E

C

D

Flange on bottom

© 2023 HumanCentric Ventures LLC www.humancentric.com

6.

Note: If desk surface is not level and causes the shelf to wobble, use the included bumpers (H)

to shim the legs where needed.

H

Lock the legs in place by tightening the screws until snug. Do not overtighten!

5.
