Hunter 44132 Manuale utente

Owner’s Manual

Models

44127

44132

Form# 44067-01

20101013

English

5-2 Programmable

Weekdays-Weekends

I N S T A L L A T I O N

5 MINUTE

44067-01 • 10/13/2010

Table Of Contents

At A Glance

Know Your ermostat ....................................................3

Setup

Setting Day and Time .....................................................10

Scheduling

Scheduling Introduction ..................................................12

Setting Your Schedule .....................................................14

Temporary Temperature Change ..........................................18

Turning Oﬀ Scheduling ...................................................20

Save Away .................................................................22

Features

Alerts .....................................................................24

Menu Options ............................................................28

Additional Features .......................................................32

ermostat Assistance

Troubleshooting and Support .............................................33

Technical Support .........................................................35

Warranty

1 Year Guarantee ..........................................................36

Your thermostat has been pre-programmed from the factory with no programming

necessary. We recommend using these pre-programmed settings for a few days

before altering them as they offer maximum energy saving benets. If you

do decide to alter your programs, use the charts on page 13 to write out your

scheduled times and temperatures. After you have recorded your preferences,

follow the instructions on page 14 to alter your temperature settings.

There is no need to program the thermosat at the wall where it is mounted to!

Remove the thermostat from the backplate by gripping the sides rmly and pulling

it straight off. This allows you to program the thermostat in comfort.

After you have programmed your thermostat, no other setting changes are

necessary unless you wish to browse through the menu to see how you may

further adjust the independent settings of your thermostat to meet your lifestyle.

The features section starting on page 28 of this manual will describe these settings.

Most settings have been preset for optimal performance.

If you need any assistance with installion or setup of your new

Hunter Thermostat, please call us, our technical support staff is

ready to help!

USA: 1-888-830-1326

Canada: 1-866-268-1936

Hours of operation are from 7:00 am to 7:00 pm Monday - Friday and 8:00 am

to 5:00 pm on Saturday, Central Time. You may also contact us over the Internet

at:

www.hunterfan.com

3Know Your ermostat

At A Glance

44067-01 • 10/13/2010

At A Glance

1. Enters Schedule Setup for altering scheduled programs.

2. Sets the Save Away feature for when you will not be home during a regularly

programmed time.

3. Conrms completion of an action or returns you to the Home screen.

4. Allows access to the advanced features of the thermostat.

5. Moves you forward or backward while setting up features or schedules.

6. Adjusts time and temperature settings as well as moving up or down menu

lists.

7. Indicates whether the system is set to Heat, Cool, or Off.

8. Shows if the fan is set to Auto or On modes.

9. Allows you to switch between Heat, Cool, and Off modes.

10. Allows you to switch between fan Auto and On modes.

Know Your ermostat

At A Glance

Save

Away

Schedule

Back Done/

Home Menu Next

910

Know Your ermostat

44067-01 • 10/13/2010

1. Holds 2 “AA” Batteries.

2. HE/HG Switch - allows you to set your furnace to Gas/Oil or Electric, based

on the type of system you have.

3. Allows your thermostat to operate your HVAC system* properly by indicating

the system type that you have.

*Conventional System: Uses a condensing unit for cooling and a

separate furnace system for heating.

*Heat Pump System: Uses the condensing unit for both heating and

cooling.

NOTE: If you are unsure of your system type it may be necessary to

contact our technical support department at 1-888-830-1326, your HVAC

manufacturer, or a local HVAC technician to determine this. Improper

selection of your system type could cause the thermostat to not operate your

system properly.

At A Glance

Know Your ermostat

At A Glance

3Know Your ermostat

44067-01 • 10/13/2010

At A Glance

1. Shows the current day of the week or weekend.

2. Indicates the thermostat is running in schedule mode.

3. Will show when your heat pump or system is reporting a problem to the

thermostat.

4. Indicates the current room temperature.

5. C will display when in Celsius mode. Nothing will display when set to

Fahrenheit.

6. Flashes when the furnace lter should be checked for replacement.

7. On when the current schedule period is running.

8. Indicates the current active schedule period.

9. Low battery warning, replace the batteries in the thermostat.

10. Indicates the fan is running when displayed.

11. Shows the current mode of the fan, Auto or On.

12. Indicates the current time in am(A) or pm (P).

13. On when the current operating mode, heat or cool, is running.

14. Current operating mode, heat or cool.

15. Indicates the thermostat is running in save away mode.

16. Current Set temperature the thermostat is scheduled to run.

Know Your ermostat

At A Glance

Wed

Auto

Filter

10:05

At Home

Heat to

Know Your ermostat

44067-01 • 10/13/2010

Setup

Setting Day and Time

Once you install the batteries, the thermostat will prompt you to set the current

day and time.

1. You will notice that “Mon” will be ashing at the top left of your screen.

Use the or buttons to move to your current day of the week and press

the Next button to advance to the next step.

2. Use the or button to change between am(A) and pm(P). Choose Next

to advance.

3. Next you will select your current hour by using the or buttons. The

Next button advances you to the next step.

4. Set your minutes using the or and press Done/

Home to nish or Back if you

need to make a correction to a previous step.

5. When nished, the thermostat will show “Updated!” to conrm your

settings are saved.

6. Your thermostat will next prompt you to set your programming, see page

14 step 2 if you wish to alter your programs at this time.
