Husqvarna 340iBT Manuale utente

340iBT

EN Operator's manual 2-21

Contents

Introduction..................................................................... 2

Safety..............................................................................3

Assembly...................................................................... 13

Operation...................................................................... 15

Maintenance................................................................. 17

Troubleshooting............................................................ 18

Transportation, storage and disposal........................... 18

Technical data.............................................................. 18

Accessories.................................................................. 20

EC Declaration of Conformity....................................... 21

Introduction

Product overview

1. Backpack harness

2. Display

3. Cruise control: Set the optimal air flow for your work

4. Start/stop button

5. Boost mode: Increase of airflow

6. Blower nozzle

7. Power trigger

8. Handle

9. Hex key

10. Operator's manual

Product description

The product is a battery backpack blower with an

electrical motor.

Work is constantly in progress to increase your safety

and efficiency during operation. Speak to your servicing

dealer for more information.

Intended use

Use the product to blow leaves and other unwanted

material from areas such as lawns, pathways and

asphalt roads.

21166 - 002 - 29.10.2019

Symbols on the product

Warning! The blower can be dangerous!

Careless or incorrect use can result in

serious or fatal injury to the operator or

others. It is extremely important that you

read and understand the contents of the

operator's manual. Please read the

operator's manual carefully and make sure

you understand the instructions before using

the machine.

Use approved eye protection.

Direct current.

Noise emissions to the environment

according to European Directive 2000/14/EC

and New South Wales legislation “Protection

of the Environment Operations (Noise

Control) Regulation 2017”. Noise emission

data can be found on the machine label and

in the Technical data chapter.

Symbols on the product or its packaging

indicate that this product cannot be handled

as domestic waste. This product must be

deposited at an appropriate recycling facility.

The product agrees with the applicable EC

directives.

Do not expose to rain.

Warning LED

Start/Stop button

Boost mode button

Cruise control button

The blower operator must ensure that

no people or animals come closer

than 15 meters. When several opera-

tors are working at the same site a

safety distance of at least 15 meters

must be in effect. The blower can for-

cibly throw objects that can bounce

back. This can result in serious eye

injuries if the recommended safety

equipment is not used.

yyyywwxxxxx The rating plate shows the serial

number. yyyy is the production year

and ww is the production week.

Product liability

As referred to in the product liability laws, we are not

liable for damages that our product causes if:

• the product is incorrectly repaired.

• the product is repaired with parts that are not from

the manufacturer or not approved by the

manufacturer.

• the product has an accessory that is not from the

manufacturer or not approved by the manufacturer.

• the product is not repaired at an approved service

center or by an approved authority.

Safety

Safety definitions

Warnings, cautions and notes

are used to point out specially

important parts of the manual.

WARNING: Used if there

is a risk of injury or death

for the operator or

bystanders if the

1166 - 002 - 29.10.2019 3

instructions in the

manual are not obeyed.

CAUTION: Used if there

is a risk of damage to the

product, other materials

or the adjacent area if

the instructions in the

manual are not obeyed.

Note: Used to give more

information that is necessary in

a given situation.

Introduction

WARNING: Read all

safety warnings and all

instructions. Failure to

follow the warnings and

instructions may result in

electric shock, fire and/or

serious injury.

General power tool safety

warnings

Check before starting

•Inspect the working area.

Remove all loose objects,

such as stones, broken glass,

nails, steel wire, string etc. that

could be thrown out.

•Always remove the battery to

prevent the machine being

started by accident. Always

disconnect the battery before

any maintenance on the

machine.

•Before using the machine and

after any impact, check for

signs of wear or damage and

repair as necessary.

•Only use original spare parts.

•The machine operator must

ensure that no people or

animals come closer than 15

metres while working. When

several operators are working

in the same area the safety

distance should be at least 15

metres.

•Do an overall inspection of the

machine before use, see

maintenance schedule.

•National or local regulations

may regulate the use. Comply

to given regulations.

Personal safety

•Stay alert, watch what you are

doing and use common sense

when operating a power tool.

Do not use a power tool while

you are tired or under the

influence of drugs, alcohol or

medication. A moment of

inattention while operating

power tools may result in

serious personal injury.

•Keep bystanders away.

41166 - 002 - 29.10.2019

•This appliance is not intended

for use by person (including

children) with reduced

physical, sensory or mental

capabilities, or lack of

experience and knowledge,

unless they have been given

supervision or instruction

concerning use of the

appliance by a person

responsible for their safety.

Children should be supervised

to ensure that they do not play

with the appliance.

•Never allow children or other

persons not trained in the use

of the machine and/or the

battery to use or service it.

Local laws may regulate the

age of the user.

•Keep unauthorised persons at

a distance. Children, animals,

onlookers and helpers should

be kept outside the safety

zone of 15 m (50 ft.). Stop the

machine immediately if

anyone approaches.

•Store the equipment in a

lockable area so that it is out

of reach of children and

unauthorized persons.

•Dress properly. Do not wear

loose clothing or jewellery.

Keep your hair, clothing and

gloves away from moving

parts. Loose clothes, jewellery

or long hair can be caught in

moving parts.

•Never use the machine if you

are tired, if you have drunk

alcohol, or if you are taking

medication that could affect

your vision, your judgement or

your coordination.

•Wear personal protective

equipment. See instructions

under the heading "Personal

protective equipment".

•Always remove the battery

when passing the machine to

another person.

•Keep in mind that it is you, the

operator that is responsible for

not exposing people or their

property to accidents or

hazards.

Power tool use and care

•Never use a machine that has

been modified in any way from

its original specification. Never

use the machine near

explosive or flammable

materials.

•Never use a machine that is

faulty. Carry out the safety

checks, maintenance and

service instructions described

in this manual. Some

maintenance and service

measures must be carried out

by trained and qualified

1166 - 002 - 29.10.2019 5

specialists. See instructions

under the heading

Maintenance.

•Only use original spare parts.

•Always ensure that ventilation

openings are kept clear of

debris.

•All covers, guards and handles

must be fitted before starting.

•Only use the machine in

daylight or in other well-lit

conditions.

•Never use the machine in bad

weather, for instance in fog, in

rain, damp or in wet locations,

strong winds, intense cold, risk

of lightning, etc. Extremely hot

weather may cause

overheating of the machine.

Operation in bad weather is

tiring and can lead to

dangerous conditions, for

instance slippery surfaces.

•If the machine starts vibrating

abnormally, stop the machine

and remove the battery.

•Walk, never run.

General safety instructions

WARNING: Read the

warning instructions that

follow before you use the

product.

•Incorrect or careless use of

the product can turn it into a

dangerous tool that can cause

serious or even fatal injury to

the operator or others. You

must read and understand the

contents of this operator's

manual.

•Under no circumstances may

the design of the product be

modified without the

permission of the

manufacturer. Never use a

product that has been

modified in any way from its

original specification and

always use original

accessories. Non-authorized

modifications and/or

accessories can result in

serious personal injury or the

death of the operator or

others. Your warranty may not

cover damage or liability

caused by the use of non-

authorized accessories or

replacement parts.

•This product produces an

electromagnetic field during

operation. This field may

under some circumstances

interfere with active or passive

medical implants. To reduce

the risk of serious or fatal

injury, we recommend persons

with medical implants to

consult their physician and the

61166 - 002 - 29.10.2019

medical implant manufacturer

before operating this product.

•Remove the battery from the

product during charging.

Safety instructions for operation

WARNING: Read the

warning instructions that

follow before you use the

product.

•If you encounter a situation

where you are uncertain how

to proceed you should ask an

expert. Contact your dealer or

your service workshop. Avoid

all usage which you consider

to be beyond your capability.

•Do not allow children to use or

be in the vicinity of the

product. Since the product is

easy to start, children may be

able to start it if they are not

kept under full surveillance.

This can mean a risk of

serious personal injury.

Disconnect the battery when

the product is not under close

supervision.

•Ensure that no people or

animals come closer than 15

meters (50 ft.) while you work.

When several operators are

working in the same area the

safety distance should be at

least 15 meters. Otherwise

there is a risk of serious

personal injury. Stop the

product immediately if anyone

approaches. Never swing the

product around without first

checking behind you to make

sure that no one is within the

safety zone.

•Make sure that you can move

and stand safely. Check the

area around you for possible

obstacles (roots, rocks,

branches, ditches, etcetera) in

case you have to move

suddenly. Take great care

when you work on sloping

ground.

•Keep a good balance and a

firm foothold at all times. Do

not overreach.

•Listen out for warning signals

or shouts when you wear

hearing protection. Always

remove your hearing

protection as soon as the

product stops.

•Show consideration to persons

in your surroundings by

avoiding using the product at

unsuitable times, such as late

in the evening or early in the

morning. Follow local

regulations and ordinances.

•Do not operate the product

near open windows.

1166 - 002 - 29.10.2019 7

•Use the product with the

lowest possible airflow. It is

seldom necessary to use full

airflow, and many work

procedures can be done at

half airflow. A lower airflow

means less noise and less

dust, and it is also easier to

keep control over the rubbish

collected together/moved.

•Use a rake or a brush to

release rubbish stuck to the

ground.

•Hold the opening of the blower

as close to the ground as

possible.

•Observe your surroundings.

Direct the product away from

persons, animals, play areas,

cars etc.

•Minimize the blowing time by

lightly wetting dusty areas or

using spray equipment.

•Be aware of the wind direction.

Work with the wind to make

your work easier.

•Stop the product and remove

the battery if the product starts

to vibrate abnormally.

•Using the product to move

large piles is time consuming

and creates unnecessary

noise.

•Clean up afterwards. Make

sure that you have not blown

rubbish into someone's

garden.

•Do not run with the product.

•The powerful currents of air

can move objects at such a

speed that they can bounce

back and cause serious eye

injuries.

•Do not direct the airflow

towards people or animals.

•Stop the motor before you

assemble or dismantle

accessories or other parts.

•Keep all parts of your body

away from hot surfaces.

•Never put the product down

when it is activated unless you

have it in clear sight.

81166 - 002 - 29.10.2019

•The product must not be used

while on a ladder or

scaffolding.

•Do not use the product unless

you are able to call for help in

case of an accident.

•Watch out for thrown objects.

Stones, rubbish, etc., can be

thrown up into the eyes

causing blindness or serious

injury.

•Use a residual-current device

(RCD) for increased security

when you charge the product.

A residual-current device is

fitted to protect operators in

case an electrical fault should

occur.

•This product is renowned for

its low vibration load.

Overexposure to vibration can

lead to circulatory damage or

nerve damage in people who

have impaired circulation.

Contact your doctor if you

experience symptoms of

overexposure to vibration.

Such symptoms include

numbness, loss of feeling,

tingling, pricking, pain, loss of

strength, changes in skin color

or condition. These symptoms

normally appear in the fingers,

hands or wrists.

•Only use the product for the

purpose it was intended for.

•It is not possible to cover

every conceivable situation

you can face. Always exercise

care and use your common

sense. Avoid all situations

which you consider to be

beyond your capability. If you

still feel uncertain about

operating procedures after

reading these instructions, you

should consult an expert

before continuing.

•The harness must always be

worn when working with the

product. Failure to do so

means you will be unable to

manoeuvre safely and this can

result in injury to yourself

and/or others.

Personal protective equipment

WARNING: Read the

warning instructions that

follow before you use the

product.

•Always use approved personal

protective equipment when

1166 - 002 - 29.10.2019 9

you use the product. Personal

protective equipment cannot

fully prevent injury but it

decreases the degree of injury

if an accident does occur. Let

your dealer help you select the

right equipment.

•Long term exposure to noise

can result in damaged

hearing. In general, battery

powered products are

relatively quiet but damage

can result from a combination

of noise level and long usage.

recommends that operators

use hearing protectors when

using products for a longer

coherent time of a day.

Continual and regular users

should have their hearing

checked regularly. Note that

hearing protectors limit the

ability to hear sounds and

warning signals.

•Use approved eye protection.

If you use a visor, you must

also use approved protective

goggles. Approved protective

goggles must comply with the

ANSI Z87.1 standard in the

USAs or EN 166 in EU

countries.

•Use clothing made of a strong

fabric. Always use heavy, long

pants and long sleeves. Do

not use loose clothing that can

catch on twigs and branches.

Do not wear jewelry, short

pants, sandals or go with bare

feet. Put your hair up safely

above shoulder level.

•Keep first aid equipment close

at hand.

•A breathing mask should be

used when there is a risk of

dust.

Safety devices on the product

WARNING: Read the

warning instructions that

follow before you use the

product.

•In this section the product’s

safety features, its purpose

10 1166 - 002 - 29.10.2019

Altri manuali per 340iBT

Indice

Altri manuali Husqvarna Soffiatore

Husqvarna

Husqvarna BA101 Manuale utente

Husqvarna

Husqvarna 320iB Manuale utente

Husqvarna

Husqvarna 340iBT Manuale di istruzioni

Husqvarna

Husqvarna 350BT Manuale utente

Husqvarna

Husqvarna 170BT Manuale utente

Husqvarna

Husqvarna 356BTX-series Manuale utente

Husqvarna

Husqvarna 525BX Manuale utente

Husqvarna

Husqvarna 525BX Manuale utente

Husqvarna

Husqvarna 150BT Manuale utente

Husqvarna

Husqvarna 350BT Manuale utente

Husqvarna

Husqvarna 1153191-26 Manuale utente

Husqvarna

Husqvarna 425 BVS Manuale utente

Husqvarna

Husqvarna BP152HV Manuale utente

Husqvarna

Husqvarna 130BT Manuale utente

Husqvarna

Husqvarna 320iB Manuale utente

Husqvarna

Husqvarna 125BT, 141B, 155B, 165BT Manuale utente

Husqvarna

Husqvarna 320iB Mark II Manuale utente

Husqvarna

Husqvarna 125BV x-series Manuale utente

Husqvarna

Husqvarna 560BTS Manuale utente

Husqvarna

Husqvarna 61COLLECTION SYSTEM Manuale del prodotto

Husqvarna

Husqvarna 150BT Mark II Manuale utente

Husqvarna

Husqvarna 115 09 83-95 Manuale utente

Husqvarna

Husqvarna 130BT Manuale utente

Husqvarna

Husqvarna 436LiB Manuale utente

Manuali Soffiatore popolari di altre marche

Weed Eater

Weed Eater VS2000BV Manuale utente

KRAUSMANN

KRAUSMANN U37020-00 Manuale utente

Bosch

Bosch ALB 36 LI Manuale utente

Cub Cadet

Cub Cadet HB425 Manuale utente

GreenWorks Pro

GreenWorks Pro BLB482 Manuale utente

ARIETE

ARIETE 2768 Manuale utente

NuTone

NuTone 331H Manuale utente

GÜDE

GÜDE GLB 200 18 Li-Ion Manuale utente

I.VA.CO.

I.VA.CO. SC Series Istruzioni operative

DeWalt

DeWalt DCE100 Manuale utente

Becker

Becker SV 7.330 Manuale utente

Metabo

Metabo AG 18 Pro Manuale utente

Desa

Desa GA3650TB Manuale utente

Echo

Echo Power Blower PB-230LN Manuale utente

Echo

Echo PB-413H Manuale utente

Black & Decker

Black & Decker BV3100 Manuale utente

Ryobi

Ryobi RY08570 Manuale utente

Haaga

Haaga 355 Manuale utente
